™ OWNERS MANUAL Model No. 45-0324 ATV MOUNTED 125 LB. BROADCAST SPREADER CAUTION: Read Rules for Safe Operation and Instructions Carefully • Assembly • Operation • Maintenance • Repair Parts the fastest way to purchase parts www.speedepart.com PRINTED IN USA... -
Page 2: Rules For Safe Operation
Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when operating equipment. • Read this owners manual before attempting to assemble or operate the spreader. •... -
Page 3: Hardware Package
QTY. QTY. QTY. DESCRIPTION DESCRIPTION DESCRIPTION Hex Bolt, 5/16" x 2" Hex Bolt, 5/16" x 2" Hex Bolt, 5/16" x 1" Hex Bolt, 5/16" x 1" Hex Bolt, 1/4" x 3/4" Hex Bolt, 1/4" x 3/4" Carriage, 5/16" x 1" Carriage, 5/16"... - Page 4 TOOLS REQUIRED FOR ASSEMBLY (1) Pliers (2) 7/16" Wrenches (2) 1/2" Wrenches (2) 9/16" Wrenches REMOVAL OF PARTS FROM CARTON Remove all parts and hardware packages from the carton. Lay out all parts and hardware and identify using the illustrations on pages 2 and 3.
- Page 5 6. Attach the extension brackets to the legs of the spreader frame. Use two 5/16" x 2" hex bolts and 5/16" nylock nuts per bracket. Tighten. See fi gure 4. 5/16" x 2" HEX BOLT 5/16" NYLOCK NUT FIGURE 4 If you are using extension brackets: 7.
- Page 6 motor shaft. Slide it up against the motor. 13. Assemble the impeller coupler onto the motor shaft and secure it with a 1/8" x 1-1/4" cotter pin. Spread the ends of the pin around the coupler. See fi gure 8. 1/8"...
- Page 7 spreader using the 5/16" x 1" carriage bolt, a mounting clamp and a plastic knob. See fi gure 11. NOTE: You can also attach to the rear rack if you use a 5/16" x 1-3/4" carriage bolt. If you attach to the rear rack, you can loosely pre-assemble the clamp, bolt and knob to the fl...
-
Page 8: Operation
HOW TO USE YOUR SPREADER SETTING THE FLOW CONTROL 1. Slide the Adjustable stop to the desired setting. 2. Move the Flow Control Lever forward until it snaps into the Adjustable Stop, locking the lever at the desired setting. See fi gure 14. FLOW CONTROL LEVER ADJUSTABLE STOP FIGURE 14... -
Page 9: Maintenance
13. Disconnect the spreader from the vehicle battery by unplugging the short wire harness from the long wire harness. The short wire harness may be left permanently attached to the battery. 14. Remove the fl ow control from the rear rack of the vehicle if it is attached there. - Page 10 125 LB. BROADCAST SPREADER MODEL 45-0324 30, 51...
- Page 11 125 LB. BROADCAST SPREADER MODEL 45-0324 REF. REF. REF. REF. PART PART PART PART QTY. QTY. QTY. QTY. 48915 48915 48915 48915 Hopper Hopper Hopper Hopper 48402 48402 48402 48402 Plastic Plug Plastic Plug Plastic Plug Plastic Plug 45164 45164...
- Page 12 REPAIR PARTS Agri-Fab, Inc. 303 West Raymond Sullivan, IL. 61951 217-728-8388 www.agri-fab.com © 2004 Agri-Fab, Inc.
