OPERATOR'S MANUAL
MANUAL DE OPERADOR
MANUEL DE L'UTILISATEUR
Electric Spreader
Épandeur électrique
Esparcidor eléctrico
45-0460
CAUTION: INSTALLATION OF A FRONT WEIGHT KIT ON YOUR MOWER
IS REQUIRED BEFORE USING THIS PRODUCT. CONTACT YOUR LOCAL
AUTHORIZED TRACTOR DEALER FOR MORE INFORMATION.
PRECAUCIÓN: SE REQUIERE QUE INSTALE UN KIT DE CONTRAPESO
FRONTAL EN SU CORTACÉSPED ANTES DE USAR ESTE PRODUCTO.
PARA OBTENER MÁS INFORMACIÓN, COMUNÍQUESE CON EL
DISTRIBUIDOR AUTORIZADO DE TRACTORES.
ATTENTION: IL EST OBLIGATOIRE D'INSTALLER UN KIT DE MASSES
D'ALOURDISSEMENT SUR LA TONDEUSE AVANT D'UTILISER CET
ARTICLE. CONTACTEZ VOTRE CONCESSIONNAIRE DE TRACTEURS
DE VOTRE RÉGION POUR PLUS D'INFORMATION.
PRINTED IN U.S.A.
FORM NO. 40977 (08/25/08)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 45-0460 and is the answer not in the manual?

Questions and answers

Summary of Contents for Agri-Fab 45-0460

  • Page 1 MANUEL DE L’UTILISATEUR Electric Spreader Épandeur électrique Esparcidor eléctrico 45-0460 CAUTION: INSTALLATION OF A FRONT WEIGHT KIT ON YOUR MOWER IS REQUIRED BEFORE USING THIS PRODUCT. CONTACT YOUR LOCAL AUTHORIZED TRACTOR DEALER FOR MORE INFORMATION. PRECAUCIÓN: SE REQUIERE QUE INSTALE UN KIT DE CONTRAPESO FRONTAL EN SU CORTACÉSPED ANTES DE USAR ESTE PRODUCTO.
  • Page 2: Rules For Safe Operation

    RULES FOR SAFE OPERATION Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when operating equipment. • Read this owners manual before attempting to assemble or operate the spreader.
  • Page 3 KEY QTY. DESCRIPTION Hex Bolt, 5/16 x 2" Hex Bolt, 5/16 x 1" Hex Bolt, 1/4 x 3/4" Nylock Nut, 1/4" Nylock Nut, 5/16" Nylon Washer Flat Washer, 1/4" Flat Washer, 5/16" SHOWN FULL SIZE NOT SHOWN FULL SIZE KEY QTY. DESCRIPTION Spacer, .31 x .56 x .36"...
  • Page 4: Tools Required For Assembly

    ASSEMBLY INSTRUCTIONS TOOLS REQUIRED FOR ASSEMBLY (1) Pliers (2) 7/16" Wrenches (2) 1/2" Wrenches CAUTION: PARTS OF TRACTOR MAY BE HOT! MAKE SURE ENGINE AND MUFFLER ARE COOL BEFORE INSTALLING SPREADER! Turn the spreader upside down as shown in figure 1. Assemble two angle brackets and two 1/4" nylock nuts onto the ends of the longer bolts already assembled to the frame tube.
  • Page 5 Place screen down into hopper. the clips in bottom of hopper at this time. See figure 6. Place motor assembly down into hopper, inserting end of spreader shaft into impeller coupler. Secure it with a 1/8" x 1-1/4" cotter pin, spreading ends of pin around coupler. See figure 5. Fasten motor mount bracket to hopper using four 5/16" x 1" hex bolts, 5/16" flat washers, nylon washers and 5/16"...
  • Page 6: Wiring Instructions

    Assemble two 5/16 x 2" hex bolts, four spacers and two 5/16" nylock nuts to either the top or next to top holes in the hopper tubes. Slide the hopper tubes into the mounting bracket. See figure 9. 5/16 x 2" HEX BOLT SPACER 5/16"...
  • Page 7: Operation

    OPERATION HOW TO USE YOUR SPREADER SETTING THE FLOW CONTROL Slide the Adjustable stop to the desired setting. Move the Flow Control Lever forward until it snaps into the Adjustable Stop, locking the lever at the desired setting. See figure 12. FLOW CONTROL LEVER ADJUSTABLE STOP FIGURE 12 STARTING THE SPREADER...
  • Page 8: Maintenance

    USE EXTREME CAUTION when removing spreader from tractor! A falling spreader can cause injury! REMOVING THE SPREADER Disconnect the spreader from the vehicle battery by unplugging the short wire harness from the long wire harness. The short wire harness may be left permanently attached to the battery.
  • Page 9 REGLAS PARA UNA OPERACION SEGURA Todo equipo energizado puede causar lesiones si se opera en forma inapropiada o si el usuario no entiende a cabalidad la forma de operar la unidad. Sea cauteloso en todo momento cuando esté operando esta clase de equipo. •...
  • Page 10 MOSTRADOS A TAMAÑO REAL NO MOSTRADOS A TAMAÑO REAL REF. CANTIDAD DESCRIPCION Perno Hexagonal de 5/16" x 2" Perno Hexagonal de 5/16" x 1" Perno Hexagonal de 1/4" x 3/4" Tuerca de Cierre de Nylon de 1/4" Tuerca de Cierre de Nylon de 5/16" Arandela de Nylon Arandela Plana de 1/4"...
  • Page 11: Instrucciones De Armado

    INSTRUCCIONES DE ARMADO HERRAMIENTAS NECESARIAS PARA EL ARMADO (1) Alicates (2) Llaves de Tuercas de 7/16" (2) Llaves de Tuercas de 1/2" PRECAUCION: ¡PARTES DEL TRACTOR PUEDEN ESTAR CALIENTES! ¡VERIFIQUE QUE EL MOTOR Y EL SILENCIADOR ESTAN FRIOS ANTES DE COMENZAR LA INSTALACIÓN DEL ESPARCIDOR ELECTRICO! Voltee la tolva del esparcidor eléctrico boca abajo como se muestra en la figura 1.
  • Page 12: Instrucciones De Cableado

    INSTRUCCIONES DE CABLEADO Cuando el esparcidor eléctrico está apropiadamente conectado, el motor del esparcidor y el impulsor girarán en la dirección de las manecillas de reloj cuando se observa la unidad desde arriba. Mueva la palanca del mecanismo de control de flujo del esparcidor a la posición “OFF" de manera que el interruptor “ON-OFF"...
  • Page 13 OPERACION USO DEL ESPARCIDOR GRADUACIÓN DEL CONTROL DE FLUJO Mueva el Elemento Ajustable de Parada a la graduación que se desea. Mueva la Palanca del mecanismo de Control de Flujo hacia adelante hasta que encaje en el Elemento Ajustable de Parada, asegurando la Palanca en la graduación deseada.
  • Page 14: Mantenimiento

    Realice la operación de remover el esparcidor del tractor con ¡EXTREMADO CUIDADO! ¡El dejar caer el esparcidor puede ocasionar lesiones! REMOCIÓN DEL ESPARCIDOR Desconecte el esparcidor de la batería del vehículo, desenchufando el arnés de cables cortos del arnés de cables largos.
  • Page 15: Consignes De Sécurité

    Tout appareil mécanique ou motorisé risque de provoquer des blessures si ce dernier n'est pas utilisé correctement ou si l'utilisateur ne sait pas comment l'utiliser. Faites preuve de prudence à tout moment lorsque vous utilisez un appareil mécanique ou motorisé. •...
  • Page 16 KEY QTY. DESCRIPT Boulon hexagonal, 5/16 x 2 po. Boulon hexagonal, 5/16 x 1 po. Boulon hexagonal, 1/4 x 3/4 po. Écrou à frein élastique, 1/4 po. Écrou à frein élastique, 5/16 po. Rondelle en nylon Rondelle plate, 1/4 po. Rondelle plate, 5/16 po.
  • Page 17: Directives D'assemblage

    DIRECTIVES D’ASSEMBLAGE OUTILS REQUIS POUR L’ASSEMBLAGE (1) Pinces (2) Clés à molette de 7/16 po. (11 mm) (2) Clés à molette de 1/2 po. (13 mm) ATTENTION: LES PIÈCES DU TRACTEUR RISQUENT D'ÊTRE TRÈS CHAUDES ! S’ASSURER QUE LE MOTEUR ET LE SILENCIEUX SONT FROIDS AU TOUCHER AVANT D’INSTALLER L’ÉPANDEUR ! Placez l'épandeur à...
  • Page 18 INSTRUCTIONS DE CÂBLAGE Lorsque l’épandeur est correctement raccordé, le moteur et l’agitateur fonctionneront dans le sens des aiguilles d’une montre si vu de dessus Placez le levier de réglage de débit sur “Off" (arrêt) afin que l'interrupteur "ON-OFF" (marche/arrêt) se trouve également à l’arrêt. Raccordez le petit faisceau de câblage (avec fusible) à la batterie du véhicule en raccordant le fil rouge à la borne positive de la batterie et le fil marron à la borne négative de la batterie. Le faisceau de câblage peut être raccordé en permanence à...
  • Page 19 FONCTIONNEMENT COMMENT UTILISER L’ÉPANDEUR RÉGLAGE DE LA COMMANDE DE DÉBIT Glissez la butée d’arrêt réglable sur la position désirée. Déplacez le levier de commande de débit vers l’avant jusqu’à ce qu’il s’imbrique dans la butée réglable en verrouillant le levier à la position désirée. Reportez-vous à l’illustration 12. BUTÉE D’ARRÊT RÉGLABLE FLOW CONTROL LEVER LEVIER DE COMMANDE...
  • Page 20: Entretien

    FAITES PREUVE D’EXTRÊME PRUDENCE lor- sque vous retirez l’épandeur du tracteur. Veillez à ne pas le laisser tomber car vous risquez de vous blesser. RETIRER L’ÉPANDEUR Débranchez l’épandeur de la batterie du véhicule en débranchant le petit faisceau de câblage du long faisceau de câblage.
  • Page 21 NOTES...
  • Page 22 REPAIR PARTS FOR 45-0460 SPREADER...
  • Page 23 REPAIR PARTS FOR 45-0460 SPREADER PART NO 48915 Hopper 48402 1/4" Plug 45164 Hex Bolt, 1/4-20 x 2-1/4" 46699 Hex Bolt, 1/4-20 x 2" 1543-69 Nylon Washer 43088 1/4" Washer 47189 Nylock Nut, 1/4" 25672 Clip 25118 Flow Slide 44285...
  • Page 24 Agri-Fab, Inc. Unauthorized uses and/or reproductions of this manual will subject such unauthorized user to civil and criminal penalties as provided by the United States Copyright Laws.
