The system uses a 1 : 3 Acid : Water mix ratio (e.g. with a 20-litre drum add 15 litres water then 5 litres
acid). It is important to use this mix for the correct acid volume to be added.
Important Safety Instruction: When mixing acid with water, ALWAYS ADD ACID TO WATER. NEVER ADD
WATER TO ACID. Always wear the appropriate safety equipment specified by the acid supplier when
handling acid.
STEP 7: Pass this clear flexible PVC tube through the drum label and a 6.0 mm hole in the acid drum
vent cap. Connect the clear flexible PVC tube to the suction valve that is mounted to the drum weight,
using the tube nut to secure the tube. Before placing the tubing into the drum, measure the tubing
against the outside of the drum and measure the feed tubing so that there is sufficient tubing. Lower
the drum weight into the acid drum and screw on the drum cap.
STEP 8: Connect the pH Signal Cable with 5 Pin Plug to the SUPERPOOL Zenith Salt & Mineral Chlorinator
programming cable port. This is where the signal from the chlorinator comes from to turn the pH
controller ON & OFF.
STEP 9: Connect the piggy-back power cord to the AC socket outlet of the Zenith Salt & Mineral
Chlorinator and the pool pump plugs in to the other end of the piggy-back socket.
STEP 10: Start up your pool pump and check the system for any leaks. Repair any such issues.
STEP 11: Prime the acid feed lines and finalise run settings using the menus below.
10. NAVIGATING THE LCD pH MENUS ON YOUR SANITISER
As fresh water is added, or chlorine is produced, the pool pH will slowly increase. This can be offset by
adding small doses of acid to the pool automatically. This pH controller uses a maintenance free
algorithm that calculates the amount of acid per dose, which is needed to maintain the pH level.
Initially it is based on the size of your pool, but through your testing, it can smartly be adjusted to make
it truly near-maintenance free for you the owner.
NOTE: It is important that the system is initially adjusted based on pH result to suit your pool and that
pool pH is still checked regularly.
10.1 Accessing the pH Control Menu
These are the menus on the SUPERPOOL Zenith Salt & Mineral Chlorinator.
PROCEDURE
LCD DISPLAY
On the Zenith Chlorinator power pack press OK to access the Main Menu and
use the +/- buttons to scroll through the menu until the LCD reads 'pH Control
Mode' – press OK to enter this mode.
Winter/Blanket
pH Control Mode
[+]UP [-]DN [OK]ENTER
