1. SAFETY
Important Warnings: This manual contains valuable information about the installation, operation, and
safe use of this product. This information should be given to the owner and/or operator of this
equipment. When installing and using this electrical equipment, basic safety precautions should
always be followed. Failure to follow safety warnings and instructions in this manual can result in severe
injury and/or damage to your equipment. Read and follow all warning notices and instructions which
are included in this manual.
The pH controller case contains live components internally. There is a danger of electric shock if

opened. If the power cord is damaged then it should be replaced by the manufacturer, their
agent or similar qualified person, to avoid a hazard.
The product shall be installed by a qualified person in accordance with AS/NZS 3000 wiring rules.

The pH controller should be installed in the correct pool zone and connected to supply via a power

outlet that is protected by a residual current device (RCD) having a rated residual operating
current not exceeding 30 mA. The power outlet should have a degree of protection suitable for
the pool zone.
To reduce the risk of injury, do not permit people with lack of experience and knowledge to use

this appliance unless they have been given supervision or instruction concerning use of the
appliance.
To reduce the risk of accidents or incidents, service on the unit should only be performed by a

qualified pool service professional, after disconnecting it from the mains power supply.
During the installation check the following:

•
•
•
•
•
Important Safety Instruction: When mixing acid with water, ALWAYS ADD ACID TO WATER. NEVER ADD
WATER TO ACID. Always wear the appropriate safety equipment specified by the acid supplier when
handling acid.
The system uses a 1 : 3 Acid : Water mix ratio (e.g. with a 20-litre drum add 15 litres water then 5 litres
acid). It is important to use this mix for the correct acid volume to be added.
DO NOT PLUG IN IF CARTON IS WET.
Should you require further information visit www.superpool.net.au
That the injector point pressure is lower than 150 kPa (to ensure optimum flow).
That the peristaltic pump's acrylic front cover is correctly fitted.
That the suction tube is securely fitted in the acid container, with weight touching
the bottom and the drum label is fitted on the outside of the container.
That the suction tube is fitted to the left side and the injector tube to the right.
That the injector valve o'ring is fitted between the valve and the CLEAR faucet
tee and the BLACK lock nut is securely fastened.
When using the Zenith pH Controller:
• Observe all applicable local, state, and federal safety regulations.
Take proper precautions with prescribed environmental and operational
•
conditions.
Consider chemical compatibility with all wetted materials.
•
