Summary of Contents for Evotech ESTR-0817
- Page 1 EVOTECH Trentino h t t p s : / / w w w . i n s t a g r a m . c o m / e v o t e c h i t a l y / h t t p : / / w w w .
- Page 2 Motorcycle Ducati Monster 1200R - 2016...
- Page 3 User Manual License plate ESTR-0817...
- Page 5 Livello di coltà: MEDIO Di culty level: MEDIUM Schwierigkeitsgrad: MITTEL Nivei de di cultad: MEDIO Niveau de di culté: MOYEN...
- Page 6 Tail Tidy ESTR-0817 Warning: Before proceeding with the assembling of the product, Evotech specifies that the user is liable for any incorrect installation of the product or its improper use. We suggest the assembling of the kit to qualified staff.
- Page 7 1. Rotate the key clockwise to unblock the seat. 2. Remove the seat. 3. At this stage the undertail will be as showed in the picture.
- Page 8 4. Remove now the screws of your undertail. First the one near the tank. 5. Than remove the one placed under the passenger’s seat. 6. Stand under your bike and remove the last two screws.
- Page 9 7. Remove the undertail. 8. Be care don’t touch the others cables. Connectors of the license plate holder are under it on the left. 2 - Indicators (gray). 1 - License plate light (white). 1- Rear light (white, don’t remove it). 9.
- Page 10 10. Remove the 4 fixing screws of the original tail tidy. WARNING! Removing the last screw the OEM tail tidy may fall. 11/12. Once you removed the undertail, remove the rubber spacers.
- Page 11 13. Now the bike’s tail is ready and you can fit the new bracket of evotech kit ESTR-0817. 14/15. Place the rubber spacers you have just removed on the new evotech kit.
- Page 12 16/17. Image of how the new tail tidy kit is made of. 18. Assemble and fix the new license plate holder with the four screws you removed before from the original kit.
- Page 13 19. Remake the wiring. 20. Warning: the images of the tail tidy could be different from yours, don’t worry. 21. You will find a cylindrical pin in the new kit. Screw it as showed in the picture. WARNING! DON’T EXCEED WITH THE TIGHTENING CYLINDRICAL PIN!
- Page 14 23. As you can see from the picture, you need the pin only to centrate the hexagonal black spacer included in the screws kit. Evotech is not liable for any damages caused by a too heavy tightening of it. 24. The thin cylindrical pin included in the kit is suitable to hide the reflector’s cable.
- Page 15 25. Reflector’s cable and use the pin to block as illustrated. 26. Bring the two hexagonal spacers and assemble them as showed in the first pages. 27. Fix plate’s support EPR-000 through the screws included in the kit. Be care about cylindrical degrees control.
- Page 16 28. The cylindrical pin must be placed inside the hole you find on the left of EPR-000 and verify to match it with the hole on the new ESTR-0317 bracket. The cylindrical pin will allow you to get a 30° angle to the vertical line of the ground-level, in accordance with the law.
- Page 17 29/30. Reassemble now the undertail using same screws. Remember to check all lighting devices work. 31. Now your ESTR-0817 is ready.
- Page 18 Illustrative photos of the tail tidy.
- Page 19 Illustrative photos of the tail tidy.
- Page 20 Optional NOT included: - Support Reflector ELT-013. - Reflector ELT-002. - Tail tidy light ELT-001. - Indicator F-01 or F-04.
