Deltech PYRAMID Series Instruction Manual page 14

DIMENSIONS / WEIGHTS
Model 100
A 37.56
B 25.62
C 1.63
D 23.62
E 17.62
F 19.62
G 9.58
H 14.96
I 28.54
J 25.02
K 0.31
L
Inlet/Outlet 1
Connections
Weights 251
(lbs)
NOTE: Dimensions and Weights are for reference only. Request certified drawings for construction purposes.
0.25-NPT DRAIN CONNECTION
MODEL 750 ONLY
BACK VIEW
14
125 150
37.56 37.56
25.62 25.62
1.63 1.63
23.62 23.62
17.62 17.62
19.62 19.62
9.58 9.58
14.96 14.96
28.54 28.54
25.02 25.02
0.31 0.31
1 1
273 279
"B"
"A"
2.500
FRONT VIEW
"D"
BOTTOM VIEW
Dimensions
(inches)
200 250 300
38.60 38.60 45.38
32.15 32.15 32.15
1.88 1.88 2.63
30.15 30.15 30.15
30.15 30.15 30.15
32.15 32.15 32.15
7.64 7.64 13.51
15.80 15.80 21.82
30.19 30.19 29.98
26.04 26.04 25.74
0.31 0.31 0.31
1-1/2 1-1/2 1-1/2
425 463 527
"C"
Ø1.00 (25mm) ELECTRICAL ENTRY
MODELS 200-750
Ø.750 (19mm) RS-232 ACCESS
MODELS 200-750
"I" "J"
CONDENSER AIR FLOW
Ø"K" MOUNTING HOLE
4-PLACES TYP.
"E" "F"
400 500 600
45.38 58.06 58.06
32.15 32.15 32.15
2.63 2.77 2.77
30.15 30.15 30.15
30.15 39.62 39.62
32.15 41.62 41.62
16.25 20.44 20.44
25.68 27.79 27.79
36.89 49.06 49.06
32.82 44.78 44.78
0.31 0.63 0.63
2 2-1/2 2-1/2
571 684 691
"H"
"G"
"L" - I/O CONNECTIONS
A
0.25-NPT DRAIN CONNECTION
MODELS 100-150
6-FT (1.8 Meters) POWER CORD
MODELS 100-150 (115 VOLT)
ELECTRICAL ENTRY
MODELS 100-150 (230 VOLT)
0.25-NPT DRAIN CONNECTION
MODELS 200-600
RIGHT SIDE VIEW
DETAIL A
750
58.06
32.15
2.77
30.15
39.62
41.62
20.44
27.79
49.06
44.78
0.63
2-1/2
734
