ASSEMBLY INSTRUCTIONS
SKU: FET
Description
Dimension
Product
Cube Size
(TABLETOP)
Cube Size
(PEDESTAL)
FERRIS 48" ROUND DINING TABLE
: FERRIS 48" ROUND DINING TABLE
: Ø48"x30"H
: 50.3"x50.3"x4.7"
: 24.9"x24.9"x12.7"
- 1 -
175 Southbelt Industrial Dr,
Houston, TX 77047
Email:sales@eastwestfurniture.net
NW: 41.8 LBS
GW: 48.4 LBS
NW: 27.5 LBS
GW: 31.9 LBS
Advertisement
Related Manuals for East West Furniture FERRIS FET
Summary of Contents for East West Furniture FERRIS FET
- Page 1 ASSEMBLY INSTRUCTIONS SKU: FET 175 Southbelt Industrial Dr, Houston, TX 77047 Email:sales@eastwestfurniture.net Description : FERRIS 48” ROUND DINING TABLE Dimension : Ø48”x30”H Product Cube Size : 50.3”x50.3”x4.7” NW: 41.8 LBS (TABLETOP) GW: 48.4 LBS Cube Size : 24.9”x24.9”x12.7” NW: 27.5 LBS (PEDESTAL) GW: 31.9 LBS FERRIS 48”...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take the time to read and follow the assembly instructions carefully. Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment. Please separate, identify, and count all parts and metal hardware.
- Page 3 STEP 1 Attach the Foot Flatfrom (D) to the Pedestal (B) with long bolt (1) and washer (4), (5). Tighten with Allen key (8). STEP 2 Put the Cross piece (C) on top of the Pedestal (B), and attach with medium bolts (2), washers (6), (7). Tighten with Allen key (8).
- Page 4 STEP 3 Carefully place the Cross piece (from Step 3) on bottom side of the table top (A), attach with short bolts (3). Tighten with Allen key (8) STEP 4 Flip the table and put on flat ground. Complete the assembly FERRIS 48”...
