Summary of Contents for Envisiontec 3Dent
- Page 1 Instruction Manual Original Instructions 3Dent™ Keep for further reference! EnvisionTEC GmbH Brüsseler Str. 51 45968 Gladbeck Germany...
- Page 3 3Dent™ Table of Contents Table of Contents Identification ......................5 Introduction ....................... 6 Warranty ........................6 Copyright ........................7 Trademarks ........................ 7 History of Changes ....................8 Health and Safety Notes ................9 Safety Signs and Safety Regulations .............. 9 1.1.1...
- Page 4 3Dent™ Table of Contents Delivery ......................20 Positioning ....................20 Construction of the 3Dent machine ............21 Overview ....................... 21 Integrated Computer ..................21 Build Platform ....................22 PSA ......................22 Actuator ......................23 Laser Unit ..................... 23 Material Identification Module ............... 24 Material Vat with Heating Function ...............
- Page 5 3Dent™ Identification Identification Manufacturer address EnvisionTEC GmbH EnvisionTEC, Inc. Brüsseler Straße 51 15162 S. Commerce Dr. 45968 Gladbeck Dearborn, MI 48120 Deutschland www.envisiontec.com 3Dent_Manual_Version 1.4_EN, Version 1.4, 2019-03-21 Page 5 of 44...
- Page 6 In case any material defects or errors occur despite correct usage, EnvisionTEC® offers a warranty period limited to one year starting from the moment the customer is supplied with the goods for the 3Dent™ system and respective accessories. The obligation of EnvisionTEC® is limited to repairing or replacing defective machine parts.
- Page 7 These operating instructions must be treated confidentially. They should only be used by authorized personnel. They may only be entrusted or made available to third parties with the prior written consent of EnvisionTEC GmbH, EnvisionTEC Inc. or authorized distributors. All documents are protected within the sense of copyright law.
- Page 8 3Dent™ History of Changes Formatting Element Example and bold letters. Keys that you want to press individually or <Ctrl>+<S> together are in angle brackets. ipconfig -all User input are displayed in a different font. Tips for operation are marked with an icon.
- Page 9 3Dent™ Health and Safety Notes Health and Safety Notes WARNING! Risk of injury! • Use the machine for the intended purposes only. • Do not carry out changes or modifications to the machine. • Follow the instructions in this manual.
- Page 10 3Dent™ Health and Safety Notes 1.1.1 Representation of Safety Symbols Safety instructions are indicated by a pictogram and a signal word. The signal word describes the severity of the risk. Pictogram Signal Word Description Indicates a hazardous situation which, if not DANGER avoided, will result in death or serious injury.
- Page 11 3Dent™ Health and Safety Notes 1.1.3 Mandatory Action Signs Use protective Use protective Use protective Use protective hand wear footwear goggles clothing Owner’s Responsibilities The machine has been produced for commercial use. Therefore, it lies within the owner‘s responsibility to ensure that all general safety regulations and codes of practice as well as the safety measures described in this manual are observed at all times.
- Page 12 3Dent™ Health and Safety Notes • Exceeding the technical values specified for normal operation • Operating the machine with damaged machine parts or electric cables • Unauthorized modifications and changes to the machine For any damage resulting from misuse: • The machine owner bears the sole responsibility, •...
- Page 13 3Dent™ Health and Safety Notes Particular hazards can be caused by: • Incomplete covers or broken parts • Improper assembly, incorrect wiring, defective parts etc. 1.5.2 Mechanical hazards • Risk of injury from hand crushing caused by automatically moving machine parts inside the upper machine compartment.
- Page 14 3Dent™ Health and Safety Notes Particular hazards can be caused by: • Setting an inappropriate temperature: The material may overheat. Overheated material may cause the release of toxic gases/vapors and burnings. Do not change the resin temperature set by the service technician.
- Page 15 3Dent™ Health and Safety Notes Risks when handling photopolymers WARNING! Risk of injury! The use of the photopolymers intended for the machine may cause risks to the health and safety of the operator or third persons. In order to ensure a safe handling of the photopolymers, the following hazard and precautionary statements must be observed.
- Page 16 Also make sure that the relevant material safety data sheets supplied with the photopolymers are observed. Those components of the photopolymers delivered by EnvisionTEC that have been classified as hazardous do not have a threshold limit value (TLV). Therefore, it is not necessary to give concrete instructions concerning the TLV.
- Page 17 3Dent™ Health and Safety Notes • First aid measures and medical attendance. 1.7.1 Shutdown in Case of an Emergency In case of an emergency, immediately press the power on/emergency stop button. This will deactivate the laser and stop all machine movements.
- Page 18 3Dent™ Health and Safety Notes 1.10 Personal Protective Equipment IMPORTANT When working with photopolymers, observe the instructions regarding personal protective equipment in the relevant material safety data sheets supplied. For reasons of accident prevention, make sure that all operators wear suitable protective clothing: •...
- Page 19 • Room must allow heat generated from the system to dissipate at 0.03 m³/min airflow. • Make sure that the extraction is sufficient. EnvisionTEC recommends an air change of 25 m³/h per m² effective surface of the laboratory as described in EN 13779.
- Page 20 Delivery Delivery The 3Dent system has been packed carefully prior to shipping, in order to practically rule out the possibility of damage to the machine if transported properly. If you notice any external damage to the packaging upon delivery, indicate this damage to the transportation company immediately and ask them to sign a damage report.
- Page 21 Construction of the 3Dent machine Construction of the 3Dent machine Different from other Rapid Prototyping systems, the 3Dent system does not use a projector but a laser unit for the curing of resins. Beside a much longer life cycle of the light source, this technique has the advantage of a minimized preparation phase for a build job and provides a more accurate processing.
- Page 22 3Dent™ Construction of the 3Dent machine Build Platform The 3Dent uses a removable granite build platform. The use of a removable platform allows for an easier cleaning and prevents remains of cured material to fall into the liquid resin. Figure 1: Granite build platform...
- Page 23 • Always use the supplied eye protection. The laser unit in the 3Dent machine consists of a rail-mounted laser head which is moved in x and y-direction by two independent control modules. Using a multi-cavity laser diode with an orthogonal mirror spinning at 20,000 rpm, the light is reflected through the spinning drum and goes through a series of optical elements, thereby focusing the light onto the surface of the photo polymer.
- Page 24 Laser beams focused through optical instruments increase the chance of eye hazard. Material Identification Module The 3Dent has a Material Identification Module (MIM) installed, that will help you monitor the material consumption at any time.
- Page 25 3Dent™ Starter Kit Starter Kit The scope of delivery of the 3Dent system includes a starter kit containing useful tools for the operation and cleaning of the machine. Contents of the Starter Kit • Hardware Manual • Perfactory Software Suite and appropriate User Manual •...
- Page 26 3Dent™ Putting into Operation Putting into Operation IMPORTANT Putting the machine into operation with increased voltage applied will damage the unit. • Always apply the voltage indicated on the rating plate. • The machine will be factory-set with the correct voltage in accordance with the country of delivery.
- Page 27 Consequently, the two units have to be connected through a network to be able to transfer the prepared job files to the 3Dent system. Alternatively you can use a USB stick to transfer the build job files to the machine.
- Page 28 3Dent™ Normal Operation Normal Operation Standard Procedures 7.1.1 Opening and Closing the PSA To open and close the PSA assembly, do the following: Unlock the PSA frame by lifting the locking lever up. Then lift up the PSA frame and use the latch at the top of the machine to secure it in the upper position.
- Page 29 3Dent™ Normal Operation 12. Reinstall the build platform into its frame and secure it with its brackets. 7.1.3 Cleaning the PSA After accomplishing the build job, clean the PSA using the provided squeegee. After that, check, whether any residues of cured material remain on the surface of the stretched film.
- Page 30 Normal Operation The material vat has a capacity of about 15kg. This makes the vat one of the heaviest parts of the 3Dent system that can decisively influence the machine’s balance. The positioning of the material vat as well as the initial filling will be carried out by the service technician during the machine installation.
- Page 31 Processing a Build Job The creation of a build job is carried out with the EnvisionTEC Software Suite. The application should not be installed on the Ultra 3SP machine, but on an individual computer.
- Page 32 3Dent™ Normal Operation Follow the next steps to start the job: 1. Open the 3SP Control application. 2. Make sure that there are no material residues on the PSA, build platform or platform frame. If you find any remains of cured resin, clean the build platform and PSA (see chapter Cleaning the Build Platform and Cleaning the PSA).
- Page 33 3Dent™ Normal Operation After completion of a build job, please take the following steps: 1. Open the PSA and lock it in the upper position, see chapter Opening and Closing the PSA. 2. Elevate the build platform out of the resin.
- Page 34 3Dent™ Regular Checkings Regular Checkings When your machine is delivered, it is thoroughly installed and calibrated by an authorized service technician. However, due to the high strain and pressure values the system is exposed to, the alignment of the components may be affected after a certain operating time.
- Page 35 3Dent™ Regular Checkings Take the following steps to check the PSA’s orientation. 1. Take out the material vat. 2. Clean the build platform and the PSA. 3. Start the 3SP Control application, close and lock the PSA. 4. Connect the machine with [Connect].
- Page 36 3Dent™ Regular Checkings parallel to the build platform. 9. Finally tighten the small Allen screws (2). 8.2.2 Determining the Initial Build Position of the Build Platform After a realignment of the PSA, it is necessary to control the first layer thickness by adjusting the gap between the PSA and the build platform at its home position.
- Page 37 3Dent™ Annex: Troubleshooting Annex: Troubleshooting Problem Potential Cause Remedy The parts on the upper The Laser Center Make sure the correct value for or bottom side of the Shift is not set the Laser Center Shift is set build platform are not correctly.
- Page 38 3Dent™ Annex: Troubleshooting Problem Potential Cause Remedy All build parts show The laser power has Please contact your customer undercuring or dropped. service. The laser head will delamination. have to be cleaned. The laser might as well be defective. Parts built on one side of...
- Page 39 3Dent™ Annex: Troubleshooting Problem Potential Cause Remedy Perfactory Software Suite manual). The recommended value can be found in the respective safety data sheet for the material used. A few seconds after The communication Reset the 3SP board at the starting a job, the motion between the 3SP back side of the machine.
- Page 40 3Dent™ Annex: Troubleshooting Problem Potential Cause Remedy The build parameters Check whether you are using are not correct. the right buildstyle (see Perfactory Software Suite manual). The laser power is not If none of the other measures correct. solves the problem, there might be a problem with the laser power.
- Page 41 3Dent™ Annex: Troubleshooting Problem Potential Cause Remedy controller of 3SP whether the build platform can Control is still be moved without error again. connected. The laser assembly The rails might need to Grease the rails. makes some unusual be lubricated.
- Page 42 3Dent™ Annex: Troubleshooting Problem Potential Cause Remedy After clicking [Home], The material bottle is Make sure there is resin in the the machine starts empty. bottle. pumping and won’t stop. The material tag has Check the Material Info field in run out.
- Page 43 3Dent™ Annex: Troubleshooting Problem Potential Cause Remedy click. The file Load the correct file communication.dll communication.dll for your has not been loaded machine. correctly. The driver is missing or Check the motion controller at corrupted. the rear of the machine. If you see a blinking red light, the motion controller is not loaded.
- Page 44 3Dent™ Annex: Troubleshooting Problem Potential Cause Remedy cannot be operated. Reconnect the monitor and check whether the problem is solved. If this measure was not successful, please contact your customer service to have your monitor replaced. Windows does not load...
