- Page 1 USER MANUAL Omni Prep Multi Sample Homogenizer Version: F Date: September 2024 Document Number: 03-201 For research use only. Not for use in diagnostic procedures...
- Page 2 This product is warranted to be free from defects in material and workmanship for a period of ONE YEAR from the date of delivery. Revvity will repair or replace and return free of charge any part which is returned to its factory within said period, transportation prepaid by user, and which is found upon inspection to have been defective in materials or workmanship.
- Page 3 Copyright This manual is published by Revvity 935 Cobb Place Blvd, Kennesaw, GA 30144 USA. Copyright Revvity, Inc. All rights reserved, including but not limited to those rights to reproduce this publication or parts thereof. Reproduction of this publication or parts thereof, or the products it describes, by any means or in any form is expressly prohibited without the written permission of Revvity.
- Page 4 Table of Contents Table of Symbols ................................... 5 Specifications ..................................6 Site Requirements ................................. 6 System Overview .................................. 7 Unpacking the Omni Prep ..............................8 Loading Samples - Tube Holders ............................9 Loading Samples - Processing Rack ..........................10 Loading Ice Bath (Optional) ..............................11 Loading the Processing Rack ..............................
- Page 5 Table of Symbols Symbol Description Symbol Description Caution. Refer to the On (power). User documentation (IEC 60417-5007) (ISO 7000-0434B) Hazardous voltage; risk Off (power). of electric shock. (IEC 60417-5008) (IEC 60417-6042) Consult Instructions for Fuse. (IEC 60417-5016) Use. (ISO 7000-1641) Alternating current.
- Page 6 Specifications Part Number 06-021 Input Voltage 110-230V, 50/60 Hz Weight 21 lbs. (9.5 kg) Dimensions W: 15.7” (40 cm), D: 7.8” (20 cm), H: 11.8” (33 cm) Power Rating 150 Watts Power Connector IEC 60320 C13 Speed 500 - 30,000 rpm...
- Page 7 System Overview The Omni Prep Homogenizer is a variable speed, multi-sample homogenizer. The unit is powered by a 150 watt, 30,000 rpm belt-driven motor. It includes a built-in high efficiency speed control, a digital speed display, and a built-in timer. The system operates exclusively with Omni Tip™ Disposable Probes™ or specially de- signed Stainless Steel Probes.
- Page 8 Unpacking the Omni Prep 1. Open the box on 2. Remove the ac- the floor. Remove cessory box. the two rack boxes. (Package may con- tain one rack box depending on your order). 3. Lay the box down 4. Turn the box on one side.
- Page 9 CAUTION: DO NOT allow probes to touch the bottoms of the tubes. CAUTION: Only probes made by Revvity are compatible with the Omni Prep. Attempting to use other style processors will damage the unit and void all warranties.
- Page 10 Loading Samples - Processing Rack The processing rack has been engineered to allow the samples to be vertically oscillated relative to the probes during processing. 1. Load the tube holders, sample tubes, and disposable/stainless steel probes by following the steps (50 mL tubes shown). 2.
- Page 11 Loading Ice Bath (Optional) 1. Install the empty ice bath to the rack underneath the tube holders. 2. Lower the tube holders so that the tubes are at the desired depth relative to the ice bath. 3. Place the cooling agent (chilled water, ice, dry ice, etc.) into the bath. Loading the Processing Rack 1.
- Page 12 5. Clip the new fuse into the exposed side of the holder and reinstall into the power entry module. 6. Contact Revvity to obtain a new replacement fuse. Store the fuse in the casing on the enclosed side of the fuse holder.
- Page 13 • Contact Revvity about sealed tube operation. WARNING: Any service must be performed by a qualified service technician. This can be either an Revvity Technician or an end user resource. All parts need to be sourced from the Revvity service department.
- Page 14 Accessories and Consumables Part Number Description 06-220 Processing Rack for Omni Prep Homogenizer 06-209-02 Omni Prep Tube Holder, 1.5 mL - 2 mL 06-209-05 Omni Prep Tube Holder, 5 mL 06-209-15 Omni Prep Tube Holder, 15 mL 06-209-50 Omni Prep Tube Holder, 30 mL - 50 mL 06-207 Cooling Ice Tray for 1.5 mL - 5 mL Tubes 06-210...
- Page 15 Appendix This equipment is marked with the crossed-out wheeled bin symbol, to indicate that this equipment may not be disposed of as unsorted municipal waste. It’s your responsibility to correctly dispose of your equipment at life-cycle end, by handing it over to an authorized facility for separate collection and recycling of waste equipment.
- Page 16 Users should exercise caution when handling materials as they may present unknown hazards. Revvity shall not be liable for any damages or losses resulting from handling or contact with the product, as Revvity cannot control actual methods, volumes, or conditions of use. Users are responsible for ensuring the product’s suitability for their specific application.
