- Page 1 USER MANUAL Bead Ruptor 24™ Bead Mill Homogenizer Version: F Date: October 2024 Document Number: 03-241C For research use only. Not for use in diagnostic procedures...
- Page 2 This product is warranted to be free from defects in material and workmanship for a period of ONE YEAR from the date of delivery. Revvity will repair or replace and return free of charge any part which is returned to its factory within said period, transportation prepaid by user, and which is found upon inspection to have been defective in materials or workmanship.
- Page 3 Copyright This manual is published by Revvity 935 Cobb Place Blvd, Kennesaw, GA 30144 USA. Copyright Revvity, Inc. All rights reserved, including but not limited to those rights to reproduce this publication or parts thereof. Reproduction of this publication or parts thereof, or the products it describes, by any means or in any form is expressly prohibited without the written permission of Revvity.
-
Page 4: Table Of Contents
Table of Contents Table of Symbols ................................... 5 Specifications ..................................6 Site Requirements ................................. 6 System Overview .................................. 7 Voltage Selection .................................. 7 Loading Sample Tubes ................................. 8 General Operation ................................10 Getting Started ..................................10 Language Setting ................................... 10 Programming Mode ................................ -
Page 5: Table Of Symbols
Table of Symbols Symbol Description Symbol Description Caution. Refer to the On (power). User documentation (IEC 60417-5007) (ISO 7000-0434B) Hazardous voltage; risk Off (power). of electric shock. (IEC 60417-5008) (IEC 60417-6042) Consult Instructions for Fuse. (IEC 60417-5016) Use. (ISO 7000-1641) Alternating current. -
Page 6: Specifications
Specifications Part Number 19-070 Input Voltage 100-230V, 50/60 Hz Weight 65 lbs. (29 kg) Dimensions W: 17” (43.2 cm), D: 15” (38.1 cm), H: 13” (33 cm) Input Current 10A max Power Connector IEC 60320 C13 Fuse 6 x 30 mm / 4A max Overvoltage Category II Pollution Degree Altitude... -
Page 7: System Overview
2. Drive Hub 6. Touch Screen 3. Tube Carriage 7. 115/220V Fuse 4. Finger Plate 8. ON/OFF Switch The Bead Ruptor 24 consists of the following: Description Quantity Bead Ruptor 24 2 mL Finger Plate Power Cords (US, EU, UK, AU) -
Page 8: Loading Sample Tubes
Loading Sample Tubes 1. Fill tubes with material to be 2. Load Tubes into the Tube Carriage homogenized. Plate (See Figure 1). 3. Place the Finger Plate on to the 4. Turn handle clockwise until tight. Tube Carriage Plate. - Page 9 A minimum of four tubes must be loaded in the tube carriage to en- sure balance during processing. Positions 1, 7, 13 and 19 must be loaded first, then fill in remaining positions. 5. Close the lid until the locking 6.
-
Page 10: General Operation
General Operation Getting Started 1. Menu 6. Settings 2. Method Name 7. Edit Menu 3. Tube Setting 8. Processing Chamber Temperature 4. Speed 9. Run / Pause 5. Number of Cycles 10. Tube Speed Limit 11. Time Setting 12. Time Interval or Dwell Between Cycles Language Setting •... -
Page 11: Programming Mode
Programming Mode • Select Protocols • Use search to find existing protocols • Press + to Create new Method Manual Programming • Select homogenization parameter • Adjust the parameter using • Press OK to save the parameter Parameter Operating Range Speed 0.8 m/s to 8 m/s Time... -
Page 12: Run Time
Run Time Stop Run Button Total Run Time Run Time Indicator Save Method 1. Select the Options Menu 2. Select “Edit Title” in the Options Menu. - Page 13 3. Enter a new title for the protocol and then press Ok. 4. An asterisk after the title indicates that the Method has not been saved. Open the Options Menu and select “Save”. 5. In the confirmation popup window, select “Save”. A further popup confirms the Method saved suc- cessfully.
-
Page 14: Troubleshooting
Reduce processing time or speed. or pressure inside tubes WARNING: Any service must be performed by a qualified service technician. This can be either an Revvity Technician or an end user resource. All parts need to be sourced from the Revvity service department. -
Page 15: Appendix
Appendix This equipment is marked with the crossed-out wheeled bin symbol, to indicate that this equipment may not be disposed of as unsorted municipal waste. It’s your responsibility to correctly dispose of your equipment at life-cycle end, by handing it over to an authorized facility for separate collection and recycling of waste equipment. - Page 16 Users should exercise caution when handling materials as they may present unknown hazards. Revvity shall not be liable for any damages or losses resulting from handling or contact with the product, as Revvity cannot control actual methods, volumes, or conditions of use. Users are responsible for ensuring the product’s suitability for their specific application.
