- Page 1 Rubidium Series TCC70XS Series TIMING SOLUTIONS Standalone Systems ATC_LTC to LTC Converter Rubidium XT and TCC70XS Application Note Revision: 2.3 February 7, 2024...
- Page 2 Page 2 RUB XT and TCC70XS Application: ATC_LTC to LTC Converter The following description walks you through the installation and the basic set-up process for your special application of an XT/XV Rubidium module. Video + ATC_LTC Input ATC_LTC Reader Read Jam-Sync Generator LTC Generator...
- Page 3 RUB XT and TCC70XS Application: ATC_LTC to LTC Converter Page 3 Step 1: Load Factory Settings: Preset a Basic Configuration Activate the Profile page and select: Profile: Factory Settings Click on the OK button. Step 2: Activate/Deactivate Functions Activate the “Functions” page and activate/deactivate as shown: •...
- Page 4 Page 4 RUB XT and TCC70XS Application: ATC_LTC to LTC Converter Step 3: ATC_LTC: Time Code Reader Configuration Activate the ANC Read page and select: Frame Rate: If you have always the same frame rate at the input (24/25/30/30 drop), please fix it accordingly.
- Page 5 RUB XT and TCC70XS Application: ATC_LTC to LTC Converter Page 5 Step 5: Set Sync Mode and Frame Rate of the Time Code Generator Activate the Generate page and select: Frame Rate: If you are working with one frame rate only, please fix it accordingly. Frame rate of time code output should be equal to the picture rate of the video signal.
- Page 6 Page 6 RUB XT and TCC70XS Application: ATC_LTC to LTC Converter Step 7: Configuration of the Video Channel Activate the Video page and select: System: Fix it according to your application. If you are working with different video formats, select “Auto”. Insert Enable: Check this box only in case you want to have a visible window inserted onto the video screen.
- Page 7 Contact Us U.S.A. Corporate Offices: Plura Broadcast, Inc. Ph: +1-602-944-1044 Sales@plurainc.com GERMANY Plura Europe GmbH Ph: +49-6725-918006-70 Sales@plurainc.com Plura MEA U.A.E. Ph: +971-50-715-9625 Sales@plurainc.com S. KOREA Plura Asia Ph: +82-10-6688-8826 Sales@plurainc.com...
