IN231000375V01_UK
A61-052V00
60
MIN
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
ASSEMBLY INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the A61-052V00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SPORTNOW A61-052V00

  • Page 1 IN231000375V01_UK A61-052V00 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTIONS...
  • Page 5 HARDWARE...
  • Page 7 To build the first part of this assembly you will need:Lower Pole (6) Wheels (10) Base (11) Axle (1A&1B) Insert the Axles (1A) into the Wheels (10). Align one of the Wheels (10) into the slots on the Base (11), using the help of another person take the Lower Pole (6) and place into the front of the Base.
  • Page 8 Take the Middle Pole (5) and slot over the Lower Pole (6), ensuring the screw holes are aligned. Secure into place using the Bolts (D), tighten to secure. Take the Backboard Frame (3) and the Goal Ring (7), align them with the holes on the Backboard (8) and fix with Bolts (E)
  • Page 9 Secure the Backboard Frame (3) to the Backboard with Bolts (F). Then fix the Top Pole (4) to the backboard with Bolts (C) Attach Net (9) to the Goal Ring (7) as shown in Fig A. Fig A...
  • Page 10 This step suggest to use two persons assemble together. With a person holding the bottom part, and another person take the assembled backboard. Align the Top Pole (4) into the Middle Pole (5) and secure with Bolts D. With a person holding the basketball stand, fill the Base (11) with water or sand.
