Summary of Contents for SPORTNOW A61-046V00

  • Page 1 IN230800234V01_IT A61-046V00 60MIN IMPORTANTE - CONSERVARE QUESTE INFORMAZIONI PER CONSULTARLE IN SEGUITO: LEGGERE ATTENTAMENTE ISTRUZIONI DI ASSEMBLAGGIO...
  • Page 4: Regolazione Dell'altezza

    Regolazione dell'altezza Come mostrato nella figura, utilizzare le viti ‘F1’, ‘F2’ e ‘F3’ per regolare l’altezza del prodot-...
  • Page 5 Tappo della base da riempire con acqua Copertura superiore del tubo M8x35mm M8x110mm M8x16mm M8x20mm M8x90mm M10x85mm...
  • Page 6 Come mostrato nella figura a destra, se ci sono sbavature o deformazioni all'attacco del tubo, è possibile utilizzare un pezzo di cartone o una tavola di legno. Basta posizionarlo sotto il tubo inferiore e picchi- ettarlo contro sezione ristretta del tubo. Come mostrato nella figura a sinistra, inserire la parte superiore ristretta del tubo (Y) nella parte inferiore del tubo...
  • Page 7 Come mostrato nella figura, utilizzare le combinazioni di viti (B1 e B4) per collegare i cestelli (J e M) e la staffa a baionetta (K). Nota: Le due combinazioni di viti a molla (B4, B5, B6 e B7) devono essere collegate ai due fori sul cestello. Come mostrato in figura, utilizzare le combinazioni di viti (C1 e C2) per fissare l'estremità...
  • Page 8 Come mostrato nella figura, utilizzare combinazioni di viti (F1, F2 e F3) per fissare l'estremità superiore del tubo superiore (W) al centro della staffa a baionetta (K). Inserire il tubo superiore installato (W) nel tubo centrale (X), quindi utiliz- zare due viti (F) per fissare il tubo centrale e il tubo superiore.
  • Page 9 Come mostrato, montare la rete (L) sul cerchio (J). Sabbia Tappo dell'acqua Acqua Se il prodotto non viene spostato molto, utilizzare sabbia, non acqua, nella base per evitare il congelamento e danni. Nota: Non è possibile estrarre la sabbia una volta che è...
  • Page 10: Assembly Instruction

    IN230800234V01_EN A61-046V00 60MIN IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTION -10-...
  • Page 11 -11-...
  • Page 12 -12-...
  • Page 13: Height Adjustment

    Height adjustment As shown in the figure, use the screws ‘F1’, ‘F2’ and ‘F3’ to adjust the product’s height. -13-...
  • Page 14 Upper pipe cover Base water cover M8x35mm M8x110mm M8x16mm M8x20mm M8x90mm M10x85mm -14-...
  • Page 15 As shown in the right figure, if there are any burrs or defor- mations at the pipe connec- tion, you can use a piece of cardboard wooden board. Simply place beneath the lower pipe and tap it against the narrowed section of the pipe.
  • Page 16 As shown in the figure, use the screw combinations (B1 and B4) to connect the bas- kets (J and M) and the claw-shaped bracket (K). Note: The two spring-loaded screw combinations (B4, B5, B6 and B7) must be connected to the two holes on the basket. As shown in the figure, use the screw combinations (C1 and C2) to fix the upper end of the claw-shaped bracket (K) to the rear of the backboard (M), then tighten the screws.
  • Page 17 As shown in the figure, use screw combinations (F1, F2 and F3) to fix the upper end of the upper tube (W) in the middle of the claw-shaped bracket (K). Insert the installed upper pipe (W) into the middle pipe (X), then use two screws (F) to secure the middle pipe and upper pipe.
  • Page 18 Install Net (L) on Rim (J) as shown. Sand Water Cap Water If you are not moving the product a lot, use sand, not water, in the base to avoid freez- ing and damage. Note: You cannot empty the sand once it is in the base. -18-...
  • Page 19 -19-...
