Programmable DC Power Supply

GPP-3610H/GPP-7250

User Manual

82PP372500EA1

ISO-9001 CERTIFIED MANUFACTURER

Need help?

Do you have a question about the GPP-7250 and is the answer not in the manual?

Questions and answers

Summary of Contents for GW Instek GPP-7250

Page 1 Programmable DC Power Supply GPP-3610H/GPP-7250 User Manual 82PP372500EA1 ISO-9001 CERTIFIED MANUFACTURER...
Page 2 Copyright Statement This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company. The information in this manual was correct at the time of printing. However, Good Will continues to improve products and reserves the rights to change specification, equipment, and maintenance procedures at any time without notice.
Page 3 Table of Contents Table of Contents Table of Contents ............. 3 SAFETY INSTRUCTIONS ..........6 Safety Symbols ............6 Safety Guidelines ............7 Power cord for the United Kingdom ......10 OVERVIEW ..............11 Introduction ............. 12 Key Features ............14 Front Panel ..............
Page 4 GPP-3610H/GPP-7250 User Manual Construct Templet ........... 49 Menu Tree ..............52 Save and Recall ............54 Delay Function ............57 Set Delay Output ............. 57 Set Group Parameter ..........60 Menu Tree ..............63 Save and Recall ............65 Monitor Function ............. 68 Set Monitor ..............
Page 5 Table of Contents Command List ............108 Measurement Instructions ........108 Display Functions ............ 108 Output Commands ..........108 Source and Load Commands ........109 Status Commands ........... 114 System Commands ..........115 System Related Commands ........116 IEEE488.2 Common Commands ......116 Command Details ..........
Page 6 GPP-3610H/GPP-7250 User Manual AFETY INSTRUCTIONS This chapter contains important safety instructions that you must follow during operation and storage. Read the following before any operation to insure your safety and to keep the instrument in the best possible condition. Safety Symbols These symbols may appear in the manual or on the instrument.
Page 7 SAFETY INSTRUCTIONS Safety Guidelines Do not place any heavy object on the unit. General  Guideline Avoid severe impact or rough handling that  leads to damaging the unit. CAUTION Do not discharge static electricity to the unit.  Do not block the cooling fan opening. ...
Page 8 GPP-3610H/GPP-7250 User Manual (Pollution Degree) EN 61010-1:2010 specifies  pollution degrees and their requirements as follows.Pollution refers to “addition of foreign matter, solid, liquid, or gaseous (ionized gases), that may produce a reduction of dielectric strength or surface resistivity”. The GPP Series falls under degree 2.
Page 9 SAFETY INSTRUCTIONS Disconnect the power cord before cleaningit . Cleaning the  power supply Use a soft cloth dampened in a solution of mild  detergent and water. Do not spray any liquid into it. Do not use chemicals containing harsh products ...
Page 10 GPP-3610H/GPP-7250 User Manual Power cord for the United Kingdom When using the power supply in the United Kingdom, make sure the power cord meets the following safety instructions. NOTE: This lead/appliance must only be wired by competent persons WARNING: THIS APPLIANCE MUST BE EARTHED...
Page 11 VERVIEW GPP- This chapter contains a brief introduction to 3610H/GPP-7250 including the main features and an overview of the front and rear panel. Use the Getting Started chapter on page 24 to start up instructions and how to setup the appropriate operation environment.
Page 12 GPP-3610H/GPP-7250 User Manual Introduction The GPP-3610H/GPP-7250 regulated DC Overview power supply series are adjustable, multifunctional work stations. The isolation degree, from output terminal to chassis or from output terminal to output terminal, is DC500V. It has additional Load function with 3 modes:...
Page 13 OVERVIEW It provides up to 4 display types, each of which Display Change can be well selected via setting. For details, see Function page 30. Under Source mode, user can customize a Output Waveform certain V/I sequential waveform output. Under Function Load mode, it is programmable for dynamic load (below 1Hz).
Page 14 GPP-3610H/GPP-7250 User Manual Key Features Multiple Outputs:  Features Constant voltage and constant current operation  (CV/CC). Low noise, thermostatically controlled fan.  Compact, lightweight, standard rack mount  comformity 3U, half Rack. 4.3 inch TFT display.  Digital panel control.
Page 15 OVERVIEW Overvoltage and overcurrent protection (OVP/  Protection OCP) Features Overtemperature protection (OTP).  Polarity Reverse Protection  Overload Protection (OPP in Load mode)  Remote Control RS-232 (standard)  Interface USB remote control. (standard)  Control I/O (standard)  LAN remote control (optional) ...
Page 16 GPP-3610H/GPP-7250 User Manual Front Panel Number Scroll wheel Arrow keys Power button Front output terminals Function keys USB host Display Display Interface (Take GPP-3610H model as example)
Page 17 OVERVIEW display Channel/ Voltage Status display Power Current display display OVP/OCP setting area setting Breathing light status, displayed in yellow and Channel no. orange alternating. Display the channel state Channel status Power supply: green or red Load Mode: orange Displays the output voltage with up to 6 digits Voltmeter of resolution.
Page 18 GPP-3610H/GPP-7250 User Manual Display the set function/remote control interface Status Indicator : Current channel : The status of OTP protection mode : The status of USB flash drive connected : USB remotely disconnected : USB remotely connected : The status of control I/O connected...
Page 19 OVERVIEW Scroll wheel is used to set each Scroll wheel & parameter value, whilst arrow Arrow keys keys are used for parameter, menu selection and voltage/current fine adjustment. It is used to switch or operate the displayed waveforms under diagram display mode.
Page 20 GPP-3610H/GPP-7250 User Manual Terminals Power output terminal or load terminal input terminal Ground terminal GND terminal...
Page 21 OVERVIEW Rear Panel Rear Output Po LAN Port Alternate Input Switch GPIB Port AC Input Socket & Line Fuse RS-232 Port Control I/O Heat Sink USB Port Terminals AC voltage selection: Alternate input switch 100V/120V/220V/230V ±10%, frequency 50/60Hz The AC input accepts AC input 100V/120V/220V/230V socket and...
Page 22 GPP-3610H/GPP-7250 User Manual USB device port for remote USB port control. See page 90 for details. GPIB slave port for remote GPIB port control. Abides to IEEE488.2 (SCPI) protocol. See page 96 for details. LAN port for remote LAN port control.
Page 23 OVERVIEW Constant Voltage/Constant Current Crossover Characteristics The unit will switch automatically between Background constant voltage and constant current according to changes in the load. When the load current is less than the current CV mode setting, the unit operates in constant voltage mode, changing the current level according to the load but maintaining the set voltage level until the current reaches the set current level.
Page 24 GPP-3610H/GPP-7250 User Manual ETTING STARTED This chapter describes the start up procedures and the preparation that is necessary before operating the power supply. Load Connection ............26 Select front/rear panel output ........28 Turning the Output On/Off ........29...
Page 25 GETTING STARTED Start Up Before the power is turned on, Checking the AC Voltage confirm that the input power supply meets the following conditions: 100V/120V/220V/230V ±10%， 50/60Hz The fuse is a slow-blow fuse. Connecting the AC power 6.3A(220V/230V),12A(100V/120V）， cord Confirm that the fuse is of the correct type and rating before connecting the power cord.
Page 26 GPP-3610H/GPP-7250 User Manual Load Connection Recommen Model Specification Usage ded Cables GTL-104A Front panel terminal Use the GTL-104A cables for Front panel wiring the front panel source connections. Rear panel Self distribution wire: wiring + / - need to be equipped with...
Page 27 GETTING STARTED...
Page 28 GPP-3610H/GPP-7250 User Manual Select front/rear panel output 1. Double click the system button Panel Operation 2. Press F1 (front) key to select front panel output, or press F2 (rear) key to select rear panel output. 3. You can see the switching output panel results from the corresponding display interface.
Page 29 GETTING STARTED Turning the Output On/Off Press the Output key to Panel Operation turn the output on. The Output key will light- up when the output is When the output is turned on, pressing the Output key again will turn the output off. Refer to page 108 for more details on remote Command Set commands chapter.
Page 30 GPP-3610H/GPP-7250 User Manual ASIC OPERATION This chapter describes how to set various functions. Display Change ............31 Source Function ............34 Output Mode ............39 Load Function ............41 Sequence Function ........... 45 Set Sequence Output ..........45 Set Group Parameter ..........48 Construct Templet ...........
Page 31 BASIC OPERATION Display Change Display Area Channel/status Work status area Read back area Parameter Setting area Function keys area 1. Under the Source interface: Warning There is a setting area (V/I/OVP/OCP) and read back status area (V/I/W). 2. Under the Load interface: It is basically equivalent to Sourece interface with additional Load and OPP status displays.
Page 32 GPP-3610H/GPP-7250 User Manual Diverse display screens In order to offer diverse information display to meet requirements from different users, the GPP provide several selections of different display screens as follows: Type Display screens Nomarl Type1 Type2 Wave- Type3 form Type4 *Type's selection: Advance key ->F1(Display) key->F1(Normal) key...
Page 33 BASIC OPERATION The introduction to Type 3 display  a represents the currently edited channel.  b indicates the adjustable items of reference point for voltage/current/power respectively. The one with a red triangular arrow is the active item to adjust, which can be toggled through the directional button on the panel.
Page 34 GPP-3610H/GPP-7250 User Manual Source Function The channel is equipped with basic power Description functions and able to display both settings and read back value of V/I as well as output status Parameter Vset The range is as the following: description 0.000V-36.500V (GPP-3610H)
Page 35 BASIC OPERATION (a) Input digit with number pad (0- 9,.) and press unit key F1(V) or F2(mV) to confirm: Input 6.543V: (b) Step input: Press the left or right arrow buttons to select high and low level that require fine-tune (underline below the corresponding number value), and scroll the...
Page 36 GPP-3610H/GPP-7250 User Manual (b) Step input: Press the left or right arrow buttons to select high and low level that require fine tune (underline below the corresponding number value), and scroll the scroll wheel to increase or decrease setting value.
Page 37 BASIC OPERATION (b) Step input: Press the left or right arrow buttons to select high and low level that require fine tune (underline below the corresponding number value), and scroll the scroll wheel to increase or decrease setting value. Press F3 key to enter the Protect menu.
Page 38 GPP-3610H/GPP-7250 User Manual CAUTION: There’s no proper sequence between turning on OVP/OCP functions and setting OVP/OCP value. Either step input or number pad input is applicable for setting parameter value. Output ON/OFF control. Operation ON/OFF Output is open when output lights up;...
Page 39 BASIC OPERATION Output Mode Setting and output, etc. Description Front panel connection Load Rear panel with sense connection Load Voltage/Cur 0.000V-36.000V (GPP-3610H) rent Rating 0.000V-72.000V (GPP-7250) 0.0000A-10.0000A (GPP-3610H) 0.0000A-5.0000A (GPP-7250)
Page 40 GPP-3610H/GPP-7250 User Manual For setting opertation of parameter, refer to Setting page 34. Press ON/OFF key or command. Output...
Page 41 Description Mode) to enter the Load mode. LCD will display the status Set rating range of voltage value Vset under Load mode: 0.000V-36.500V (GPP-3610H) 0.000V-72.500V (GPP-7250) Set rating range of current value Iset under Load mode: 0.0000A-10.2000A (GPP-3610H) 0.0000A-5.2000A (GPP-7250)
Page 42 GPP-3610H/GPP-7250 User Manual Set rating range of resistance value Rset under Load mode: 1Ω-1000Ω OPP:Fixed 100W, non-revisable Others OVP/OCP: indentical to Source Press F4 or F5 button for operating Parameter Vset the corresponding (CV) mode setting followed by F1 button (Vset). The...
Page 43 BASIC OPERATION current setting area on LCD will be activated and appears (red font color with the underline indicator). (a) number pad (0-9,.) input; press unit button F1 (A) or F2 (mA) button to confirm: Input 1.543A: (b) Step input: Press the left or right arrow buttons to select high and low level that...
Page 44 GPP-3610H/GPP-7250 User Manual (b) Step input: Press the left or right arrow buttons to select high and low level that require fine tune (underline below the corresponding number value), and scroll the scroll wheel to increase or decrease setting value.
Page 45 BASIC OPERATION Sequence Function This function can be used for practical Description applications when different voltage waveforms are required to be output. Users can edit the output waveform according to their needs. The amplitude range of the output waveform is the output voltage range of power supply.
Page 46 GPP-3610H/GPP-7250 User Manual NOT exceed 2048 for Start+Groups. There’re 2 statuses after the End State necessary Group and Cycle are executed: output termination or being hold with the last step. Press the Advance key on control Parameter Cycles panel. Select F2 (Sequence) function.
Page 47 BASIC OPERATION then press the F1 (Done) button to confirm; or use arrow keys along with scroll wheel to complete the setting. Under the Sequence function, press End State F1 (Set) button followed by selecting F4 (End State), and 2 statuses Last/Output off will appear in turn on LCD .
Page 48 GPP-3610H/GPP-7250 User Manual Set Group Parameter Each Group consists of Voltage, Current and Description Time. Therefore, properly confirm parameter of each group is correct before setting Sequence output. Group number. Maximum 2047 Parameter Voltage setting of each group. Description Voltage Current Current setting of each group.
Page 49 BASIC OPERATION Under the Sequence function, press Current F2 (Edit) button followed by selecting F4 (Current). The setting on LCD is activated and appears in red font color . Use number pad to set the parameters directly and then press the F1 (A) or F2 (mA) button to confirm;...
Page 50 GPP-3610H/GPP-7250 User Manual Exp Fall. Set the max. value of waveform voltage/current Value Set the min. value of waveform voltage/current Value Set the initial group number of Start waveform. Maximum: 2037 Select the required points. Range: 10- Points 2047 Invert the selected waveform...
Page 51 BASIC OPERATION Press the F4 (Min Value) button. The setting on LCD will be activated and Value appears in red front color. Use number pad to set the parameters directly and then press the F1 (V/A) or the F2 (mV/mA) button to confirm;...
Page 52 GPP-3610H/GPP-7250 User Manual the parameters directly and then press the F1 (Done) to confirm; or use arrow keys along with scroll wheel to complete the setting. Press the F4 (Inverted) button. On Inverted (inverted) and Off (non- inverted) appear on LCD in turn.
Page 53 BASIC OPERATION Advance Sequence Edit Templet Memory SEQ.On Return Cycles Object Type Restart Done Done Type *.CSV Sync Return PageUp Sine *.SEQ PageDown Pulse Return Ramp Start Time StairUp NewFile SEQ.Off Done Second More Return Last (Stair Dn) Save Return Next (Stair UpDn) Return...
Page 54 GPP-3610H/GPP-7250 User Manual Save and Recall GPP models can save and recall the Sequence Description data from internal 10 groups or flash drive. Avaialble for *.CSV or *.SEQ Parameter Type file type Description New File Avaialble for creating new *.CSV or *.SEQ file type...
Page 55 BASIC OPERATION 3. Rotate the scroll wheel (Encode) to select target file. 4. Press F3 (Save) button to save the settings of Sequence into the corresponding file. 5.Press the F4 (Recall) button to recall the Sequence file of list to the current sequence settings when necessary.
Page 56 GPP-3610H/GPP-7250 User Manual 5. Press F3 (Save) button to save the settings of Sequence into the corresponding file. 6. Press the F4 (Recall) button to recall the Sequence file of list to the current sequence settings when necessary.
Page 57 BASIC OPERATION Delay Function It is necessary to output a series of pulse in real Description applications. This function is available when voltage is constant. Output waveform can be edited per user’s preference. The amplitude range of the output waveform is the output voltage range of power supply.
Page 58 GPP-3610H/GPP-7250 User Manual The number to be executed. It can Groups NOT exceed 2048 for Start+Groups. There’re 3 statuses after the End State necessary Group and Cycle are executed: output termination or output on or being hold with the last step.
Page 59 BASIC OPERATION Under the Delay function, press the Groups F1 (Set) button followed by selecting the F3 (Groups), the setting on LDC will be activated and appears in red font . Use number pad for direct setting followed by pressing F1 (Done) key to confirm; or use arrow keys along with scroll wheel to complete setting.
Page 60 GPP-3610H/GPP-7250 User Manual button will become "Delay OFF", which can perform the function of closing Delay . In Delay ON, the F1 (Restart) button appears, it means that start from the first. If the channel has been in Output Warning ON before Delay function, the status remains unchanged until Delay.On...
Page 61 BASIC OPERATION setting time interval of neighboring Group. Under the Delay function, press the Parameter Setting F2 (Edit) button followed by selecting the F1 (No.). The setting on LCD is activated and appears in red font color . Use number pad to set the parameters directly and then press the F1 (Done) button to confirm;...
Page 62 GPP-3610H/GPP-7250 User Manual F2 (Edit) button followed by selecting F4 (Pattern), and then set up via F1 (01Patt) and F2 (10Patt). The live setting result appears on the LCD. Under the Delay function, press the Time Set F2 (Edit) button followed by...
Page 63 BASIC OPERATION Menu Tree Description User is able to well understand the overall functions of Delay via menu tree, which is put in proper order by layer. The Return key is used for back to the parent menu. See the construction below: Level1------------ Advance Level2------------ Delay...
Page 64 GPP-3610H/GPP-7250 User Manual Advance Delay Edit Stop Memory Delay On Return Cycles None Type Restart Done Done Voltage *.CSV Sync Return PageUp Define *.DLY PageDown Delay.Off Return Start State Return NewFile Return Done Return Current Save Inverted Define Last Recall...
Page 65 BASIC OPERATION Save and Recall Description GPP models can save and recall the Delay data from internal 10 groups or flash drive. Avaialble for *.CSV or *.DLY file type Parameter Type Description Avaialble for creating new *.CSV or New File *.DLY file type Save the delay data to the specified Save...
Page 66 GPP-3610H/GPP-7250 User Manual 3. Rotate the scroll wheel (Encode) to select target file. 4. Press F3 (Save) button to save the settings of Delay into the corresponding file. 5. Press the F4 (Recall) button to recall the Delay file of list to the current sequence settings when necessary.
Page 67 BASIC OPERATION 5. Press F3 (Save) button to save the settings of Delay into the corresponding file. 6. Press the F4 (Recall) button to recall the Delay file of list to the current sequence settings when necessary.
Page 68 GPP-3610H/GPP-7250 User Manual Monitor Function In order to have well understanding of the Description channel under long-term output, the GPP series has the additional live monitor function, which helps guarantee load status of client via halting operation based on certain preset conditions.
Page 69 BASIC OPERATION panel. Select the F4 (Monitor) Setting function followed by pressing the F1 (Voltage) button to enter the voltage setting. 1. Press the F1 (Set) button. The setting on LCD is activated and appears in red font color. Use number pad to set the parameters directly;...
Page 70 GPP-3610H/GPP-7250 User Manual conditions. Press the Advance key on control Power panel. Select the F4 (Monitor) function followed by pressing the F3 (Power) button to enter the power setting. 1. Press the F1 (Set) button. The setting on LCD is activated and appears in red font color.
Page 71 BASIC OPERATION Recorder Function Description In order to have well understanding of the channel under long-term output, the GPP series has the additional live record function, which saves file via media for further analysis later. Set Recorder Set period of each recorded. Parameter Period Description...
Page 72 GPP-3610H/GPP-7250 User Manual setting of recorded period. The setting on LCD is activated and appears in red font color. Use number pad to set the parameters directly and then press the F1 (s) button to confirm; or use arrow keys along with scroll wheel to complete the setting.
Page 73 BASIC OPERATION Also rotate the scroll wheel (Encode) to enter the flash drive when necessary. Press F3 (Save) button to save the temporary data into the corresponding file. Press F4 (Recall) button to save the record data of file into the temporary storage for further saving into flash drive later.
Page 74 GPP-3610H/GPP-7250 User Manual External I/O Control The GPP series models Description provides user with a programmable external trigger port, which is used to dock certain functions control. It can turn each Data Line Function (D0,D1,D2,D3,D4) into input signal respectively to have command of the following four functions: 1.
Page 75 BASIC OPERATION The control circuit of each port is illustrated Schematic diagram as the diagram below (D1 for example) for control signal I/O port Electrical characteristics ≤0.3V Input Low Level DC Voltage ≥3.3V High Level DC Voltage ≤0.3V Output Low Level DC Voltage ≥3.3V High Level Voltage ≤0.6mA...
Page 76 GPP-3610H/GPP-7250 User Manual F5 (More) under Input Mode setting: Operation Result Function Type Select trigger type: F1(RiseEdge), F2 (FallEdge), F3 (Hi-Level), F4 (Lo-Level), , F5(States Input) * "States Input" equivalent to edge trigger (RiseEdge + FallEdge) Set result after trigger response:...
Page 77 BASIC OPERATION Press the F1 (Data Line) button. Select required data line from D0 through D4: F1(D0), F2(D1) , F3(D2) , F4(D3) , F5(D4). Press the F2 (Enable) button to set this terminal as input or output function. This button enables Enable or Disenable to be selected in turn.
Page 78 GPP-3610H/GPP-7250 User Manual ILE OPERATION Restore Factory Default Settings ......82...
Page 79 FILE OPERATION Save/Recall System provides user with 4 different files, each of Description which has 10 groups including parameter setting *.set, use record *.rec, sequence output *.seq and delay output *.dly. Note: Both file folder and name in flash drive are limited within 8 characters.
Page 80 GPP-3610H/GPP-7250 User Manual Press the right arrow button to enter the file group. Rotate the scroll wheel (Encode) and stop at the file in need Press the F3 (Save) button to have the settings of current model saved into the corresponding file.
Page 81 FILE OPERATION Refer to page 73 for chapter of Memory operation of Recorded Record. file operation *.REC Note: *.REC file can be edited in PC by the specified format (*.CSV or *.REC) and imported, via flash drive, into PC. In the System Setting menu, the interface parameter settings area shows Power On.
Page 82 GPP-3610H/GPP-7250 User Manual Restore Factory Default Settings There’s a group of Default value, the non- Description modifiable factory default setting. User is able to restore Default or proceed to Preset operation from Power On under System. Press the System button to enter the interface...
Page 83 错误!使用“开始”选项卡将標題 1 应用于要在此处显示的文字。 YSTEM SETTINGS System Information ..........84 System Settings ............85 Firmware Upgrading ..........87 Description of Using Flash Drive ......88...
Page 84 GPP-3610H/GPP-7250 User Manual System Information The picture below shows complete system System information. If the selected model is without ports Information (GPIB, LAN), the corresponding info will disappear. GPIB Press the System button on the panel to show the Check screen as above.
Page 85 SYSTEM SETTINGS System Settings Description It can be used to perform system operations for machine. Remote control and relevant Setting Interface information data output setting Power On Power on initial state setting Language menu language setting BackLight Adjust the LCD brightness. Beeper Sets when the buzzer is turn on.
Page 86 GPP-3610H/GPP-7250 User Manual In the System menu, press the F3 (Setting) Backlight button followed by selecting the F2 (Backlight) brightness adjustment to adjust backlight brightness. There are three brightness levels: High, Middle, and Low. Select from pressing the F1 (Low) or F2 (Middle) or F3 (High) button.
Page 87 Firmware Upgrading When system is failure, request by customer GW When to Instek. When the system fails, firmware can Upgrade Firmware requested by GW Instek customers. Firmware file Supplied by GW Instek Upgrade Requirement After plugging in flash drive, the corresponding Operation symbol appears in the status bar.
Page 88 GPP-3610H/GPP-7250 User Manual Description of Using Flash Drive It can be used when upgrading the software Description upgrades, screenshot operation and importing or exporting files. Flash drive only support USB2.0/USB3.0,FAT32 file system,16G MAX. Insert flash driver into the USB Host port.
Page 89 SYSTEM SETTINGS The files of Sequence (*.SEQ), Recorder Exporting the (*.REC), Delay (*.DLY), etc within machine can Sequence data be, in addition to individual format, converted to *.CSV file format for easy check and edit in PC by user. For more details, refer to page 79.
Page 90 GPP-3610H/GPP-7250 User Manual EMOTE CONTROL RS-232 ..............93 USB ................95 GPIB ................. 96 LAN ................98 Command Syntax ........... 104 Command List ............108 Measurement Instructions ........108 Display Functions ............ 108 Output Commands ..........108 Source and Load Commands ........109 Status Commands ...........
Page 91 REMOTE CONTROL Enable Registers ............184 Status Byte Register ..........184 Standard Event Register .......... 186 Status Byte Register Commands......187 Standard Event Register Commands ...... 188 Other Status Register Commands ......190...
Page 92 GPP-3610H/GPP-7250 User Manual Connection Usage This chapter describes how to set and enable port, as well as all the required preparations prior to operation. The GPP series has 2 standard remote control Port type ports (RS-232, USB), and 2 optional ports (GPIB, LAN).
Page 93 REMOTE CONTROL RS-232 The GPP series models can be remotely Description controlled by RS-232 connection. Rear panel RS-232 Interface port 2--->Digital Receiver 3--->Digital Transmitter 5--->Ground terminal Under power-off state, connect RS-232 cable Connection and select RS-232 port in the Interface. The message USB232 will appear gray in the status bar when connection, and turns to white color while the first command connects succesfully.
Page 94 Perform the following query: Function check *IDN? The unit will return the manufacturer, model, serial number and software version. GW INSTEK, GPP-3610H, SN: xxxxxxxx, Vx.xx Disable Remote Control Mode Send a remote command Local from the PC.  Long-press the F6 (unlock) key on the front ...
Page 95 REMOTE CONTROL GPP can be connected via USB using the USB Description Communications Device (CDC) class. Rear panel USB device port. Interface Install the USB driver provided by suppiler in Installing the Driver Select USB port in the Interface after connecting the USB cable.
Page 96 Perform the following query: Function Check *IDN? The unit will return the manufacturer, model, serial number and software version. GW INSTEK, GPP-3610H, SN: xxxxxxxxx, Vx.xx Send a remote command from the PC  Disabling Remote Long-press the F6 (unlock) key on the front ...
Page 97 REMOTE CONTROL Rear panel GPIB port. Interface Select GPIB port in the Interface Connection after connecting the GPIB cable. The message GPIB will appear gray in the status bar when connection, and turns to white color while the first command connects succesfully.
Page 98 GPP-3610H/GPP-7250 User Manual When using the LAN port, the relevant Description parameters are supposed to be set earlier. Select LAN port in the Interface after Connection connecting the LAN cable. The message LAN will appear gray in the status bar when connection, and turns to white color while the first command connects succesfully.
Page 99 REMOTE CONTROL D. press the F4 (Host Name) button to manually input. The Name area will be activated and become red color after setting. The default first letter is A, and can be changed to other string by rotating scroll wheel Encoder (A, B...Z, a, b...z, 1, 2...9, 0, - in clockwise sequence).
Page 100 GPP-3610H/GPP-7250 User Manual F. return to the Manual configuration menu and repeat manually configuring NetMask. Press the F2 (NetMask) button to manually input data. The set content will be activated to become red color. Input required data and confirm by pressing the F1 (Done) button. Press the F5 (Clear) button to clear and input again if error occurs.
Page 101 REMOTE CONTROL A. Press the System button to enter the system DHCP interface followed by pressing the F1 (Interface) button to configure port parameter. B. Press the F4 (LAN) button to configure internet port parameter. C. Press the F1 (Config) button to configure relevant parameter.
Page 102 GPP-3610H/GPP-7250 User Manual 2. Click on “Browser Web Control” to execute commands through the browser, as shown below. 3. Press the “View & Modify Configuration” icon to enter the Modify Config menu, as shown below.
Page 103 REMOTE CONTROL 4. Click “Modify Config” to enter the network configuration setting menu, as shown below. Use the mouse to click on “Save and Restart” to change the remote settings for the GPP series. Click “Undo Edits” to cancel all the edited Note settings.
Page 104 GPP-3610H/GPP-7250 User Manual Command Syntax The commands that are used with the GPP meet IEEE488.2 and SCPI standards. SCPI Commands Overview Command Format SCPI is an ASCII based command language designed for test and measurement instruments. SCPI commands uses a hierarchical structure (tree system), and is divided into different subsystems.
Page 105 REMOTE CONTROL Symbol Description SCPI commands have the following conventional symbols. These symbols are not commands but are used to describe the command parameters. 1. Curly Brackets { } Curly Bracket enclose command string parameters, for example: {OFF|ON} 2. Vertical Bars | Vertical bars are used to separate one or more optional parameters.
Page 106 GPP-3610H/GPP-7250 User Manual Parameter Types The commands have a number of different parameter categories. How the parameters are set depend on the parameter categories. 1. Boolean Commands parameter that have to states “OFF” and “ON”, for example, DISPlay:FOCUs {ON|OFF}. “ON” will turn on the focus display function, while “OFF”...
Page 107 REMOTE CONTROL 5. ASCII Strings ASCII string parameters must use a combination of ASCII characters in a string. For example: For the command: MODE <name>, <name> must be an ASCII string. Command Abbreviations The syntax for SCPI commands contains a combination of upper and lower case letters.
Page 108 GPP-3610H/GPP-7250 User Manual Command List Measurement Instructions :MEASure[1]:<function>? Page 118 Page 118 :MEASure[1]:ALL? Page 118 VOUT<X>? Page 119 IOUT<X>? Display Functions Page 120 :DISPlay:ENABle :DISPlay:ENABle? Page 120 Page 120 :DISPlay:BRIGhtness <NRf> :DISPlay:BRIGhtness? Page 120 Page 121 :DISPlay:TYPE {1|2|3|4} Page 121...
Page 109 REMOTE CONTROL :OUTPut[1]:OCP:STATe Page 124 Page 124 :OUTPut[1]:OCP:STATe? Page 125 :OUTPut[1]:OCP:TRIGger? :OUTPut[1]:OCP <value> Page 125 Page 125 :OUTPut[1]:OCP? Source and Load Commands :SOURce[1]:CURRent <NRf> Page 126 Page 126 ISET<X>:<NR2> Page 126 :SOURce[1]:CURRent? Page 126 ISET<X>? Page 126 :SOURce[1]:CURRent[:LIMit]:STATe? :SOURce[1]:VOLTage <NRf> Page 127 VSET<X>:<NR2>...
Page 110 GPP-3610H/GPP-7250 User Manual :DELAy[1]: ENDState {ON|OFF|LAST} Page 131 Page 131 :DELAy[1]: ENDState? Page 131 :DELAy[1]:GROUPs <NRf> :DELAy[1]:GROUPs? Page 132 Page 132 :DELAy[1]:PARAmeter <No>,{ON|OFF},<time> :DELAy[1]:PARAmeter? <No>,<cecount> Page 132 Page 133 :DELAy[1]: RESTart Page 133 :DELAy[1]:STARt <value> Page 134 :DELAy[1]:STARt? Page 134...
Page 111 REMOTE CONTROL :MONItor[1]:POWER:CONDition {<P|>P|=P|NONE} Page 139 Page 140 :MONItor[1]:POWER:CONDition? :MONItor[1]:POWER[:VALue] Page 140 {<value>|MINimum|MAXimum} Page 140 :MONItor[1]:POWER[:VALue]? Page 140 :MONItor[1][:STATe] {ON|OFF} :MONItor[1][:STATe]? Page 141 :MONItor[1]:STOPway {OUTOFF|ALARM Page 141 |BEEPER},{ON|OFF} :MONItor[1]:STOPway? Page 141 :MONItor[1]:VOLTage:CONDition Page 141 {<V|>V|=V|NONE},{AND|OR|NONE} :MONItor[1]:VOLTage:CONDition? Page 142 :MONItor[1]:VOLTage[:VALue] Page 142 {<value>|MINimum|MAXimum} :MONItor[1]:VOLTage[:VALue]? Page 142...
Page 112 GPP-3610H/GPP-7250 User Manual :SEQUence[1]:ENDState {OFF|LAST} Page 147 Page 147 :SEQUence[1]:ENDState? Page 147 :SEQUence[1]:GROUPs <value> :SEQUence[1]:GROUPs? Page 147 Page 148 :SEQUence[1]:PARAmeter<No>,<volt>,<curr>,<time> :SEQUence[1]:PARAmeter? <No>,<count> Page 148 Page 149 :SEQUence[1]:RESTart Page 149 :SEQUence[1]:STARt <value> Page 150 :SEQUence[1]:STARt? Page 150 :SEQUence[1][:STATe] {ON|OFF} Page 150...
Page 113 REMOTE CONTROL :SEQUence[1]:TEMPlet:RISERate? Page 155 Page 155 :SEQUence[1]:TEMPlet:SELect {SINE|PULSE|RAMP|UP|DN|UPDN|RISE|FALL} Page 155 :SEQUence[1]:TEMPlet:SELect? Page 155 :SEQUence[1]:TEMPlet:SYMMetry <value> Page 156 :SEQUence[1]:TEMPlet:SYMMetry? :SEQUence[1]:TEMPlet:WIDTh <value> Page 156 Page 156 :SEQUence[1]:TEMPlet:WIDTh? :SEQUence[1]:TEMPlet:STARt <value> Page 156 :SEQUence[1]:TEMPlet:STARt? Page 156 :SEQUence[1]:MEMory:SAVE {0,1,2,3,4,5,6,7,8,9} Page 157 :SEQUence[1]:MEMory:LOAD {0,1,2,3,4,5,6,7,8,9} Page 157 :SEQUence[1]:USB:SAVE <dest>...
Page 114 GPP-3610H/GPP-7250 User Manual >C|<C|=C|>P|<P|=P|AUTO} ,<value> Page 163 :TRIGger:OUT:CONDition? {D0|D1|D2|D3|D4} :TRIGger:OUT[:ENABle] {D0|D1|D2|D3|D4}, Page 163 {ON|OFF} Page 163 :TRIGger:OUT[:ENABle]? {D0|D1|D2|D3|D4} :TRIGger:OUT:POLArity {D0|D1|D2|D3|D4}, Page 163 {POSItive|NEGAtive} Page 164 :TRIGger:OUT:POLArity? {D0|D1|D2|D3|D4} Page 164 :TRIGger:OUT:SOURce {D0|D1|D2|D3|D4}, {CH1} :TRIGger:OUT:SOURce? {D0|D1|D2|D3|D4} Page 164 :TRIGger:OUT:STATe [D0|D1|D2|D3|D4,] {ON|OFF} Page 165...
Page 115 REMOTE CONTROL :STATus:QUEue:ENABle <list> Page 169 Page 170 :STATus:QUEue:ENABle? Page 170 :STATus:QUEue:DISable <list> :STATus:QUEue:DISable? Page 170 Page 170 :STATus:QUEue:CLEar System Commands :SYSTem:VERSion? Page 172 Page 172 :SYSTem:ERRor? Page 172 ERR? Page 173 :SYSTem:CLEar Page 173 :SYSTem:POSetup <name> :SYSTem:POSetup? Page 173 :SYSTem:COMMunicate:LAN:DHCP[:STATe] ...
Page 116 GPP-3610H/GPP-7250 User Manual :SYSTem:BEEPer:STATe? Page 177 Page 177 :SYSTem:LOCal Page 177 LOCAL :SYSTem:INTerface [USB|RS232|GPIB|LAN] Page 177 Page 178 :SYSTem:LANGuage [CHINese|ENGlish] :SYSTem:LANGuage? Page 178 Page 178 :SYSTem:BAUDrate:USB [9600|19200|38400|57600|115200] :SYSTem:BAUDrate:USB? Page 178 Page 178 :SYSTem:BAUDrate:RS232 [9600|19200|38400|57600|115200] :SYSTem:BAUDrate:RS232? Page 178 Page 179 BAUD<NR1>...
Page 117 REMOTE CONTROL *ESR? Page 188 Page 190 *CLS Page 190 *OPC *OPC? Page 190...
Page 118 GPP-3610H/GPP-7250 User Manual Command Details When using commands to select a specific channel, [1] stands for CH1, [2] stands for CH2. "1" can be omitted when you want to select CH1 as it is selected by default. However if you wish to select CH2, "2"...
Page 119 REMOTE CONTROL Command IOUT<X>? Function Returns the actual output current. Description Example IOUT1? Returns the output current.
Page 120 GPP-3610H/GPP-7250 User Manual Display Commands Command :DISPlay:ENABle Function Turn the LCD display on or off. Description 0/OFF: Turns the display off. 1/ON: Turns the display on. Example :DISPlay:ENABle ON Turns the LCD display on. Command :DISPlay:ENABle? Function Queries the state of the display.
Page 121 REMOTE CONTROL Return Low: The brightness is low, Middle: The brightness is low, High: The brightness is low. Example :DISPlay:BRIGhtness? Returns the brightness of the display. Command :DISPlay:TYPE {1|2|3|4} Function Sets the display screens. For details, see page 32. Example :DISPlay:TYPE 4 Sets the display screens of TYPE4.
Page 122 GPP-3610H/GPP-7250 User Manual Output Commands Command :OUTPut[1][:STATe] Function Turns the output on or off. Description 0/OFF: Turn off the output 1/ON: Turn on the output Example :OUTPut1:STATe ON Turns on the output. Command :OUTPut[1][:STATe]? Function Queries the output state.
Page 123 REMOTE CONTROL Command ROUTe:TERMinals Function Query front or rear terminal output. Return FRONt: Output from front terminal. Output from rear terminal. REAR: Example ROUTe:TERMinals Command :OUTPut[1]:OVP:STATe Function Turns OVP protection on/off. Description 0/OFF:Turns OVP off. 1/ON:Turns OVP on. Example :OUTPut:OVP:STATe ON Turn on OVP.
Page 124 GPP-3610H/GPP-7250 User Manual Example :OUTPut:OVP:TRIGer? Return whether the OVP protection function has been triggered. Command :OUTPut[1]:OVP <value> Function Sets the OVP level. Description <value> Refer to the specification sheet on page 200 for value. Example :OUTPut:OVP 10.5 Sets the OVP voltage to 10.5V .
Page 125 REMOTE CONTROL Command :OUTPut[1]:OCP:TRIGer? Function Query whether the OCP protection function has been triggered. Return 0/OFF: The channel OCP protection is not triggered. 1/ON: The channel OCP protection has been triggered. Example :OUTPut:OCP:TRIGer? Return whether the OCP protection function has been triggered.
Page 126 GPP-3610H/GPP-7250 User Manual Source and Load Commands Command :SOURce[1]:CURRent <NRf> Function Sets the current level. 0.0000- MAX value (Refer to the Description <NRf> specification sheet for MAX value). Example :SOURce:CURRent 1.0005 Sets the current level to 1.0005A. Command ISET<X>:<NR2> Function Sets the current level.
Page 127 REMOTE CONTROL Function Queries the current limit state. Return 0: The current limit has not been reached. 1:The current limit has been reached. Example :SOURce:CURRent:STATe? Return the current limit state. At output off or Load Mode,The return value of is Note Command :SOURce[1]:VOLTage <...
Page 128 GPP-3610H/GPP-7250 User Manual Function Returns the output voltage setting. Description X ：=1 Example VSET1? Returns output voltage setting. Command :SOURce[1]:RESistor < NRf > Function Set the resistor value. Description 1-1000 Example :SOURce:RESistor 1000 Set the resistor value as 1000Ω. Command...
Page 129 REMOTE CONTROL Command :LOAD[1]:CC {ON|OFF}[,FAST] Function Sets Load CC mode. [FAST]: In order to protect the function switching Description device” relay”, it is necessary to wait until the voltage and current drop to zero under normal conditions. When FAST is enabled, this factor will not be considered, but it is easy to damage the “relay”, so it is recommended to use it with caution.
Page 130 GPP-3610H/GPP-7250 User Manual Function Queries the Load CR level. Description <NRf> 1-1000 Example :LOAD:RESistor? Return the Load CR level . Command :LOAD:DISPlay {Low|Middle|High} Function In load mode, set the minimum voltage value that can be displayed. The factory default is high. Below this value, it will display “--.----“.
Page 131 REMOTE CONTROL Command :DELAy[1]:CYCLEs? Function Queries the cycle number of Delay. Example :DELAy:CYCLEs? Return to I or N, <value> (For example: N,100). Command :DELAy[1]:ENDState {ON|OFF|LAST} Function Sets the termination state of Delay. Description ON|OFF|LAST ON: output enabled. OFF: output disabled. LAST: stay at the last group of output state.
Page 132 GPP-3610H/GPP-7250 User Manual Example :DELAy:GROUPs 100 Sets the output number of Delay as 100. Command :DELAy[1]:GROUPs? Function Queries the output number of Delay. Example :DELAy:GROUPs? Return the output number of Delay. Command :DELAy[1]:PARAmeter <No>,{ON|OFF},<time> Function Sets the delay parameter of Delay.
Page 133 REMOTE CONTROL Function Queries the delay parameter of the specified groups of Delay. Returns to a string initiating from #. Data head is to describe data length information starting from #. For example, ##9000000017, the later 9 digits (000000017) following the initial 9 indicate length of data flow (17 bytes).
Page 134 GPP-3610H/GPP-7250 User Manual Command :DELAy[1]:STARt? Function Queries the sequence number for initial execution of delay output. Example :DELAy:STARt? Returns the initial sequence number of sequence output. Command :DELAy[1][:STATe] {ON|OFF} Function Enable or disable the delay output function. Description {ON|OFF} Output state of the group.
Page 135 REMOTE CONTROL Command :DELAy[1]:STATe: GENErate? Queries the currently used pattern of the Function automatically generated state. Example :DELAy:STATe:GENE? Queries the currently used pattern of the automatically generated state. :DELAy[1]:STOP Command {NONE|<V|>V|=V|<C|>C|=C|<P|>P|=P}[,<v alue>] Function Sets the stop condition of delay. Description NONE: Sets stop condition type as “NONE”.
Page 136 GPP-3610H/GPP-7250 User Manual Command :DELAy[1]:TIME:GENErate {FIX|INC|DEC}[,<value0>[,<value1>]] Function Sets the method of automatically generated time and the corresponding parameter of delay. Description <value0> The duration of “ON” state. <value1> The duration of “OFF” state. FIX (fixed time) sets <value0> and <value1> time, which ragne from 1s to 300s.
Page 137 REMOTE CONTROL Example :DELAy:TIME:GENE? Queries the method of automatically generated time for delay and the corresponding parameter. Return a string with format consisting of the method of automatically generated time, <value0>,<value1>. :DELAy[1]:MEMory:SAVE Command {0|1|2|3|4|5|6|7|8|9} Saves the delayed file to the designated location of Function internal storage.
Page 138 GPP-3610H/GPP-7250 User Manual Parameter <dest> indicates the designated location of external storage with file format in either usb:\<name>.CSV or usb:\<name>.DLY. The file name spans up to the max. 8 alphanumeric characters. .CSV/.DLY represents the suffix of file name. Storage location can not be designated when delay function is enabled.
Page 139 REMOTE CONTROL Example :MONItor:CURRent:CONDition <C,AND Sets the current monitor condition for monitor as <current, and the logical pattern as “and”. Command :MONItor[1]:CURRent:CONDition? Function Queries the current monitor condition for monitor. Example :MONItor:CURRent:CONDition? Queries the current monitor condition for monitor. Returns to the current monitor condition and logical pattern.
Page 140 GPP-3610H/GPP-7250 User Manual Description {<P|>P|NONE} Sets power monitor condition as “ <P”(<power),“ >P”(>power) , “=P”(=power)or “NONE”(none-monitored power). Example :MONItor:POWER:CONDition <P Sets the power monitor condition of monitor as <power. Command :MONItor[1]:POWER:CONDition? Function Queries the power monitor condition of current monitor.
Page 141 REMOTE CONTROL Example :MONItor ON Enable monitor. Command :MONItor[1][:STATe]? Function Queries whether the current monitor is On or Off. Example :MONItor? Queries whether the current monitor is On or Off. Returns to ON or OFF. Command :MONItor[1]:STOPway {OUTOFF|ALARM |BEEPER},{ON|OFF} Function Sets the stop method of monitor.
Page 142 GPP-3610H/GPP-7250 User Manual Description {<V|>V|=V|NONE} Sets voltage monitor condition as “ <V”(<voltage),“ >V”(>voltage) , “=V”(=voltage)or “ NONE”(none-monitored voltage). {AND|OR|NONE} Practical monitor condition is the logical composition of voltage, current and power. ,”AND ” (and), “OR” (or), “ NONE”(none- logical pattern) .
Page 143 REMOTE CONTROL Example :MONItor:VOLTage? Queries the voltage monitor value for the current monitor. Command :RECOrder[1]:PATH? Function Queries the save location of recorded file. Example :RECOrder:PATH? Queries the save location of recorded file. Command :RECOrder[1]:MEMory{0|1|2|3|4|5|6|7|8|9} Function Save the recorded file to the internal storage with specified saving location.
Page 144 GPP-3610H/GPP-7250 User Manual Example :RECOrder:USB usb:\R001.CSV Save the recorded file with specified name ” R001.CSV” to the external storage.To set record period and saving location is Not permitted when recorder is enabled. Therefore, preset required saving location prior to enabling recorder.
Page 145 REMOTE CONTROL Function Enable or disable recorder. When recorder is enabled, it is Not allowed to set record period and saving location and instrument will sample and save output based on the interval of currently set recorded period. During recording, please ensure that the output of the channel is turned on.
Page 146 GPP-3610H/GPP-7250 User Manual Example :RECOrder:GROUPs? Returns the group number of recorder. Command :RECOrder[1]:ENABle {ON|OFF} Function Sets the channel recorder ON or OFF. Example :RECOrder:ENABle ON Enables recorder. Command :RECOrder[1]:ENABle? Function Queries the state of channel recorder. Return ON: Recorder is Enable.
Page 147 REMOTE CONTROL Command :SEQUence[1]:ENDState {OFF|LAST} Function Sets terminate state of sequence. {OFF|LAST} Output disabled (OFF): instrument Description automatically disable output when output is complete. The last group (LAST): instrument stays at the output state of the last group when output is complete.
Page 148 GPP-3610H/GPP-7250 User Manual Example :SEQUence:GROUPs? Queries the output group number of the sequence. Returns to an integer between 1 to 2048. Command :SEQUence[1]:PARAmeter<No>,<volt>,<curr>,<ti me> Function Sets the parameter of the specified group. Description < No > is the serial number of sequence parameter of the specified group, integer, 0 to 2047.
Page 149 REMOTE CONTROL Function Queries the specified several groups of sequence parameter. Returns to a string initiating from #. Data head is to describe data length information starting from #. For example, ##9000000037, the later 9 digits (000000037) following the initial 9 indicate length of data flow (37 bytes).
Page 150 GPP-3610H/GPP-7250 User Manual Function Sets the sequence number for initial execution. <value>: Integer 0 - 2047 Example :SEQUence:STARt 10 Sets the sequence output to start from the group 11th. Command :SEQUence[1]:STARt? Function Queries the sequence number for initial execution of the channel sequence output.
Page 151 REMOTE CONTROL Command :SEQUence[1]:TEMPlet:CONSTruct Sends the command. Instrument builds, based on Function the actively selected templet and set the sequence parameter. Example :SEQUence:TEMPlet:CONSTruct Set build sequence output according to the selected template and set parameters.. Command :SEQUence[1]:TEMPlet:FALLRate <value> Function Sets the falling degree of ExpFall. Description <value>...
Page 152 GPP-3610H/GPP-7250 User Manual Command :SEQUence[1]:TEMPlet:INTErval? Function Queries the active time interval. Example :SEQUence:TEMPlet:INTErval? Queries the active time interval. Returns to an integer between 1 to 300. Command :SEQUence[1]:TEMPlet:INVErt {ON|OFF} Function Enable or disable invert function of the active selected templet.
Page 153 REMOTE CONTROL Description When voltage is the object to edit, it is the maximum voltage to be set. When current is the object to edit, it is the maximum current to be set. When templet type is Pulse, the command is to set low level value.
Page 154 GPP-3610H/GPP-7250 User Manual Example :SEQUence:TEMPlet:MINValue? Returns to the minimum voltage or current value of the active selected templet. Command :SEQUence[1]:TEMPlet:OBJect {V|C} Function Selects the object to be edited by the active templet. V|C : Selects the object to be edited as voltage V or Description current C.
Page 155 REMOTE CONTROL Command :SEQUence[1]:TEMPlet:RISERate <value> Function Sets the rising degree of ExpRise. Description <value> Ranges from 0 to 10. Example :SEQUence:TEMPlet:RISERate 10 Sets the rising degree of ExpRise as 10. Command :SEQUence[1]:TEMPlet:RISERate? Function Queries the rising degree of the actively set ExpRise.
Page 156 GPP-3610H/GPP-7250 User Manual Example :SEQUence:TEMPlet:SYMMetry 50 Sets the symmetry of RAMP as 50%. Command :SEQUence[1]:TEMPlet:SYMMetry? Function Queries the symmetry of the actively set RAMP. Example :SEQUence:TEMPlet:SYMMetry? Returns the symmetry of the actively set RAMP. Command :SEQUence[1]:TEMPlet:WIDTh <value> Function Sets the pulse width of Pulse.
Page 157 REMOTE CONTROL Example :SEQUence:TEMPlet:STARt? Returns to the initial number of sequence output templet. Command :SEQUence[1]:MEMory:SAVE {0|1|2|3|4|5|6|7|8|9} Function Saves the channel sequence output file to the designated location of internal storage. {0|1|2|3|4|5|6|7|8|9} represent the storage locations of 10 files within the internal storage individually.
Page 158 GPP-3610H/GPP-7250 User Manual Function Saves the channel sequence output file to the designated location of external storage. <dest> indicates the designated location of external storage with file format in either usb:\<name>.CSV or usb:\<name>.SEQ. The file name spans up to the max. 8 alphanumeric characters.
Page 159 REMOTE CONTROL Example :TRIGger:IN? D0 Returns the state of the trigger input function of the D0 data line. Command :TRIGger:IN:RESPonse{D0|D1|D2|D3|D4},{ON| OFF||TOGGLE|POWER|CV|CC|CR } Function Sets the output response from the trigger input of the specified data line. Description ON|OFF||TOGGLE|POWER|CV|CC|CR } Enable output (ON): when the input signal of the specified data line meets the trigger condition, enable the channel output Disable output (OFF): when the input signal of the...
Page 160 GPP-3610H/GPP-7250 User Manual Command :TRIGger:IN:RESPonse? {D0|D1|D2|D3|D4} Queries the output response from the trigger input Function of the specified data line. Example :TRIGger:IN:RESPonse? D0 Returns the output reponse of the trigger input of the queried D0 data line. Command :TRIGger:IN:SENSitivity {D0|D1|D2|D3|D4},{LOW|MID|HIGH}...
Page 161 REMOTE CONTROL Command :TRIGger:IN:SOURce?{D0|D1|D2|D3|D4} Function Queries the trigger input of the specified data line. :TRIGger:IN:SOURce? D0 Example Returns the the trigger input of D0 data line. Command :TRIGger:IN:TYPE {D0|D1|D2|D3|D4},{RISE|FALL|HIGH|LOW|S TATE } Sets the trigger type from the trigger input of the Function specified data line.
Page 162 GPP-3610H/GPP-7250 User Manual Function Sets the trigger condition from the trigger output of the specified data line. Description OUTOFF|OUTON|>V|<V|=V|>C|<C|=C|>P|< P|=P|AUTO When OUTOFF, OUTON or AUTO is selected, parameter <value> will be omitted. Input trigger: disable output(OUTOFF) and enable output (OUTON), both of which indicate to disable or enable respectively the trigger when the specified controlled channel output.
Page 163 REMOTE CONTROL Example :TRIGger:OUT:CONDition D0,>V,10 Sets the trigger condition from the trigger output of D0 data line as output voltage>10V. Command :TRIGger:OUT:CONDition? {D0|D1|D2|D3|D4} Queries the trigger condition from the trigger Function output of the specified data line. Example :TRIGger:OUT:CONDition? D0 Returns the trigger condition from the trigger output of D0 data line.
Page 164 GPP-3610H/GPP-7250 User Manual Function Sets the polarity of the output signal from the trigger output of the specified data line. Description POSItive|NEGAtive Positive polarity (POSItive): when trigger condition is met, it will output the actively specified output signal. Negative polarity (NEGAtive) when trigger condition is met, it will invert and then output the actively specified output signal.
Page 165 REMOTE CONTROL Example :TRIGger:OUT:SOURce? D0 Returns the channel from the trigger output of D0 data line. Command :TRIGger:OUT:STATe [D0|D1|D2|D3|D4,] {ON|OFF} Function Set the data line trigger output state on or off. :TRIGger:OUT:STATe D0,ON Example Set the data line D0 trigger output state on. Command :TRIGger:OUT:STATe? [D0|D1|D2|D3|D4] Function...
Page 166 GPP-3610H/GPP-7250 User Manual Function Clears the operation event enable registers, the measurement event enable registers and the questionable event register, The unit will then return to the default settings status. Example :STATus:PRESet Command :STATus:OPERation[:EVENt]? Function Read the operation event register.
Page 167 REMOTE CONTROL Example :STATus:OPERation:ENABle? Read the contents of the operation enable status register. Command :STATus:MEASurement[:EVENt]? Function Reads the measurement event status register. Example :STATus:MEASurement? Reads the contents of the measurement event status register. Command :STATus:MEASurement:ENABle <NRf> Function Program the measurement enable status register. Description <NRf>...
Page 168 GPP-3610H/GPP-7250 User Manual Command :STATus:MEASurement:ENABle? Function Read the measurement enable status register. Example :STATus:MEASurement:ENABle? Read the contents of the measurement enable status register. Command :STATus:MEASurement:CONDition? Function Read the measurement condition status register. Example :STATus:MEASurement:CONDition? Read the contents of the measurement condition status register.
Page 169 REMOTE CONTROL Example :STATus:QUEStionable:ENABle 256 Sets the CAL bit. Command :STATus:QUEStionable:ENABle? Function Read the questionable enable status register. Example :STATus:QUEStionable:ENABle? Read the contents of the questionable enable status register. Command :STATus:QUEue[:NEXT]? Function Read the next message in the error queue. Example :STATus:QUEue? Read the next error message.
Page 170 GPP-3610H/GPP-7250 User Manual Command :STATus:QUEue:ENABle? Function Read the error and status messages that have been enabled. Example :STATus:QUEue:ENABle? Returns the contents of the enabled error and status messages. Command :STATus:QUEue:DISable <list> Function Specifies which messages will not be placed in the error queue.
Page 171 REMOTE CONTROL Example :STATus:QUEue:CLEar Empty all the messages from the error queue.
Page 172 GPP-3610H/GPP-7250 User Manual System Commands Command :SYSTem:VERSion? Function Query the SCPI version. Example :SYSTem:VERSion? Query the SCPI version. Command :SYSTem:ERRor? Function Read and clear the last error and from the error queue. Example :SYSTem:ERRor? Read and clear the last error and from the error queue.
Page 173 REMOTE CONTROL Command :SYSTem:CLEar Function Clear the error messages. Example :SYSTem:CLEar Clears the error queue. Command :SYSTem:POSetup <name> Function Set the power on configuration. Description <name> RST: Machine default settings. Last: Machine last settings. Example :SYSTem:POSetup RST Set the power on configuration to RST. Command :SYSTem:POSetup? Function...
Page 174 GPP-3610H/GPP-7250 User Manual Function Query the DHCP status. Example :SYSTem:COMMunicate:LAN:DHCP? Query the DHCP state. :SYSTem:COMMunicate:LAN:IPADdress Command <IPaddress> Function Sets the IP address. <IP ASCII string, within the range of 1.0.0.0 Description address> to 223.255.255.255 (excluding 127.nnn.nnn.nnn). Note: This command is only applicable if for the manual IP mode.
Page 175 REMOTE CONTROL Example :SYSTem:COMM:LAN:SMAS 255.255.255.0 Sets the subnet mask to 255.255.255.0. Command :SYSTem:COMMunicate:LAN:SMASk? Function Query the subnet mask. Example :SYSTem:COMMunicate:LAN:SMASk? Query the subnet mask. Command :SYSTem:COMMunicate:LAN:GATEway <IPaddress> Function Sets the gateway IP address. Description <IP address> ASCII string, within the range of 1.0.0.0 to 223.255.255.255 (excluding 127.nnn.nnn.nnn).
Page 176 GPP-3610H/GPP-7250 User Manual Example :SYSTem:COMMunicate:LAN:MANualip ON Enables a manual IP address to be set. Command :SYSTem:COMMunicate:LAN:MANualip[:STATe]? Queries whether manual IP addressing has been Function enabled or disabled. Example :SYSTem:COMMunicate:LAN:MANualip? Queries the status of the manual IP addressing. Command :SYSTem:COMMunicate:LAN:APPLy When this command is executed, all the LAN Function settings are applied.
Page 177 REMOTE CONTROL Example :SYSTem:BEEPer:STATe OFF Turns the buzzer off. Command BEEP<Boolean> Function Turn the buzzer on or off. <Boolean> 0:off, 1:on Example BEEP1 Turns on the beeper Command :SYSTem:BEEPer:STATe? Function Queries the buzzer status. Example :SYSTem:BEEPer:STATe? Queries the buzzer status. Command :SYSTem:LOCal Function...
Page 178 GPP-3610H/GPP-7250 User Manual Example :SYSTem:INTerface USB Sets the interface type to USB. Command :SYSTem:LANGuage [CHINese|ENGlish] Function Sets the syetem language. Example :SYSTem:LANGuage ENGlish Sets the syetem lanuage to English. Command :SYSTem:LANGuage? Function Query the syetem lanuage. Example :SYSTem:LANGuage? Command :SYSTem:BAUDrate:USB...
Page 179 REMOTE CONTROL Function Query the RS232 baud rate. Example :SYSTem:BAUDrate:RS232? Command BAUD<NR1> Function Sets the baud rate to 9600 / 57600 / 115200. <NR1> 0: 115200bps, 1: 57600bps, 2: 9600bps Example BAUD0 Sets the baud rate to 115200bps Note It functions only when RS232 or USB is connected. Command HELP? Function...
Page 180 GPP-3610H/GPP-7250 User Manual Return ISET<x>:<NR2> Sets the value of current. parameters VSET<x>:<NR2> Sets the value of voltage. ISET<x>? Return the value of current. VSET<x>? Return the value of voltage. IOUT<x>? Returns actual output current， VOUT<x>? Returns actual output voltage. TRACK<NR1> Sets the output of the power supply working on independent or tracking mode.
Page 181 Example *IDN? Returns the GPP identification: GW INSTEK,GPP-3610H,XXXXXXXXX,V1.00 GW INSTEK: Manufacturer, GPP-3610H: Model name, XXXXXXXXX: Serial number, V1.00: version number. Command *RST Function Resets the unit to RST default conditions.
Page 182 GPP-3610H/GPP-7250 User Manual Function Save the current setup to the selected save location. Description <NR1> : 0–9, Corresponding to STATE00-STATE09. SAV1 Stores the setting in memory 1(STATE01). Command *RCL <NRf> Function Recall the selected save setting from memory. Description <NRf>: 0 - 9 , Corresponding to STATE00-STATE09.
Page 183 REMOTE CONTROL *Note: URQ indicates that the "Lock" key on the panel has been used. (Entering lock from unlock or Entering unlock from lock).
Page 184 GPP-3610H/GPP-7250 User Manual Event Registers The operation, measurement and questionable status register groups all have event registers. The event registers are read only registers that reflect the status of the unit. Individual bits in the event registers are latched (set) when a corresponding event occurs and will remain latched even if the corresponding event changes, as long as the event bit is still set.
Page 185 REMOTE CONTROL Bit Definition for the Status Byte Register Bit number Decimal Definition value Not used, returns “0” 0 Not used Not used, returns “0” 1 Not used Indicates that one or more errors 2 Error Queue are stored in the error queue. One or more bits are set in the 3 Questionable questionable data register (for...
Page 186 GPP-3610H/GPP-7250 User Manual In general it is best to use the Operation Complete Bit (bit 0) in the standard event register to check to see if an operation/command has completed. After executing the *OPC command, the OPC bit will be set to 1. If a command or query is placed in the output...
Page 187 REMOTE CONTROL 4 Execution An execution error. Error 5 Command A command syntax error. Error 6 Not used Not used, return 0. 7 Power On This bit is set if the power supply has been reset from the last time you read the event register.
Page 188 GPP-3610H/GPP-7250 User Manual Example *SRE? Returns “7”, which are the contents of the service request enable register. Command *STB? Query the status byte register. This is the same as Function performing a serial poll, however the master summary bit (MSS, bit 6) will not be cleared by the *STB command.
Page 189 REMOTE CONTROL Function Queries the standard event register. It returns a binary-weighted decimal value in the range of 0~255. Example *ESR? It returns 65, as the ESER is set as 0100 0001.
Page 190 GPP-3610H/GPP-7250 User Manual Other Status Register Commands Command *CLS Clears the status byte summary registers and the Function all event registers. Example *CLS Clears all the event registers, which include Standard event registers, Operation event registers, Measurement event registers, Questionable event registers.
Page 191 APPENDIX PPENDIX Replacing the Fuse Remove the power cord and then take out the Steps box using a small screw driver. The fuse is stored in the housing. T6.3A/250V（220V/230V） Rating  T12A/250V（100V/120V） ...
Page 192 30 minutes, within +20° C-+30°C. Power Mode Output Independent 0 - 36.000V , 0 - 10.0000A (GPP-3610H) Rating 0 - 72.000V , 0 - 5.0000A (GPP-7250) Voltage Line regulation ≤ 0.01% + 3mV ≤ 0.01% + 5mV Load regulation Ripple &...
Page 193 1-72.50V (GPP-7250) Current 0-10.200A (GPP-3610H) 0-5.200A (GPP-7250) Power 0-100.00W CV Mode 1.500V - 36.50V (GPP-3610H) 1.500V - 72.50V (GPP-7250) ≤±(0.1% + 30mV) Setting/Readba ck accuracy Resolution 10mV CC Mode 0 - 10.200A (GPP-3610H) 0 - 5.200A (GPP-7250) Setting/Readba ≤±(0.3% + 10mA)
Page 194 GPP-3610H/GPP-7250 User Manual Storage TEMPERATURE: -10˚C ~ 70˚C HUMIDITY: ≤70% Environment Power input AC 100V/120V/220V/230V±10%, 50/60Hz consumption 900VA,680W Accessories CD User manual x1, Quick Start manual x1, Power Code x1 Test lead: GTL-104A x1 (Europe) Test lead: GTL-204A x1, GTL-201A x1...
Page 195 APPENDIX Declaration of Conformity GOOD WILL INSTRUMENT CO., LTD. declare that the CE marking mentioned product satisfies all the technical relations application to the product within the scope of council: Directive: EMC; LVD; WEEE; RoHS The product is in conformity with the following standards or other normative documents: ◎...
Page 196 GPP-3610H/GPP-7250 User Manual GOOD WILL INSTRUMENT EURO B.V. De Run 5427A, 5504DG Veldhoven, The Netherlands Tel: +31(0)40-2557790 Fax: +31(0)40-2541194 Email: sales@gw-instek.eu...
