PGR5
15.2+ SEER2 2-Stage Packaged Air Conditioner and Single Stage Gas Furnace
Ultra Low NOx System
with R-410A Refrigerant
Single and Three Phase
2-5 Nominal Tons (Sizes 24-60)
IMPORTANT: Effective January 1, 2015, all split system and packaged
air conditioners must be installed pursuant to applicable regional
efficiency standards issued by the Department of Energy.
NOTE:
Read the entire instruction manual before starting the
installation.
NOTE:
Installer: Make sure the Owner's Manual and Service
Instructions are left with the unit after installation.
Table of Contents
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Receiving and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Identify Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Inspect Shipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Roof Curb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Slab Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Rigging/Lifting of Unit (See
Configuring Units for Downflow (Vertical) Discharge . . . . . . 11
High-Voltage Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Special Procedures for 208-v Operation . . . . . . . . . . . . . . . . . . 13
Control Voltage Connections . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Standard Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Heat Anticipator Setting (Electro-Mechanical Thermostats only)13
Transformer Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pre-Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Check Heating Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Check Gas Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Adjust Gas Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Airflow and Temperature Rise . . . . . . . . . . . . . . . . . . . . . . . . . 22
Heating Sequence of Operation (Ultra Low NOx Single and Three
Phase Models). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Limit Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Burner Thermal Switch (Ultra Low NOx) . . . . . . . . . . . . . . . . 22
Checking Cooling Control Operation . . . . . . . . . . . . . . . . . . . . 22
Checking and Adjusting Refrigerant Charge . . . . . . . . . . . . . . 23
Indoor Airflow and Airflow Adjustments . . . . . . . . . . . . . . . . 23
Cooling Sequence of Operation . . . . . . . . . . . . . . . . . . . . . . . . 24
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Indoor Blower and Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Induced Draft (combustion air) Blower Assembly. . . . . . . . . . 35
Flue Gas Passageways . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Limit Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Burner Ignition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Ultra Low NOx Burner Baffle Inspection/Cleaning (See
36
Installation Instructions
Fig.
6) . . . . . . . . . . . . . . . . . . . . . . 4
Fig.
Outdoor Coil, Indoor Coil, and Condensate Drain Pan . . . . . . 37
Outdoor Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Electrical Controls and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . 37
Refrigerant Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Gas Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Evaporator Airflow. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
R-410A Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Metering Device (Thermostatic Expansion Valve ) . . . . . . . . . 38
Pressure Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Loss of Charge Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
High-Pressure Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Copeland Scroll Compressor R-410A Refrigerant). . . . . . . . . 38
Refrigerant System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Start-up Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Fig. 1 – Unit PGR5 Ultra Low NOx
Improper installation, adjustment, alteration, service maintenance, or use
can cause explosion, fire, electrical shock, or other conditions which
may cause death, personal injury, or property damage. Consult a
qualified installer, service agency, or your distributor or branch for
information or assistance. The qualified installer or agency must use
factory-authorized kits or accessories when modifying this product.
Refer to the individual instructions packaged with the kits or accessories
when installing.
Follow all safety codes. Wear safety glasses, protective clothing, and
work gloves. Have a fire extinguisher available. Read these instructions
thoroughly and follow all warnings or cautions included in literature and
attached to the unit. consult local building codes, the current editions of
the National Fuel Gas Code (NFGC) NFPA 54/ANSI Z223.1, and the
National Electrical Code (NEC) NFPA 70.
21.)
