Test Probes
Contact Probes
LED Flashlight
Important: The Disable Pin (attached to the wrist strap) must be inserted into the bottom of the unit in order for the
stun to operate. The alarm and light will both function without the Disable Pin inserted.
Charging the Batteries
The rechargeable batteries are already installed. The unit cannot be opened, as this could damage the
1.
unit and will void the warranty.
Before use, the stun gun will need to be charged for 3-4 hours.
2.
Using the included USB charging cord, plug the USB end into the charging port on the stun gun and the
3.
other end into your USB charging device (computer, wall or block charger, or car plug).
Using the Flashlight
1.
Slide the Safety/Function Switch located on the side of the unit up to the top position to turn on the LED
Flashlight. **Be careful**, if the Disable Pin is inserted into the bottom of the unit, the stun will work if the
Stun Activation Button is pressed.
2.
Slide the Safety/Function Switch back down to the middle position to turn off the light.
Testing the Stun Gun (WARNING: Do not test fire the stun gun for more than 1 second as this will damage the unit
and void the warranty.)
1.
Insert the disable pin (attached to the wrist strap) into the bottom of the unit.
2.
Slide the Safety/Function Switch (located on the side of the unit) up to the top position. The flashlight
will come on and the Stun Warning Light will illuminate.
3.
Press the Stun Activation Button located on the side of the unit to test the stun gun. You will both see
and hear an electrical charge fire across the top of the unit between the Test Probes. When test firing
the unit, do not hold the button down for more than 1 second.
4
Slide the Safety/Function Switch back down to the middle position to turn the safety back on
SWTD89 Series
Instruction Manual
Stun Warning Light
Stun Activation Button
Safety/Function Switch
Light/Stun OFF
Safety/Function Switch
Alarm
Charging Port
(not shown)
Disable Pin (not
shown)
Revised 12/15/2023
Advertisement
Related Manuals for STREET WISE SWTD89 Series
Summary of Contents for STREET WISE SWTD89 Series
- Page 1 Safety/Function Switch SWTD89 Series Instruction Manual Light/Stun OFF Alarm Charging Port Test Probes (not shown) Contact Probes Disable Pin (not shown) LED Flashlight Safety/Function Switch Stun Warning Light Stun Activation Button Important: The Disable Pin (attached to the wrist strap) must be inserted into the bottom of the unit in order for the stun to operate.
- Page 2 Using the Alarm Slide the Safety/Function Switch located on the side of the unit down to the bottom position. The alarm will come on. Slide the switch back to the middle position to turn the alarm off. Using this product in Self Defense When carrying this unit, we recommend using the Wrist Strap.
