STREET WISE SWBAR9R Instructions

Triple Stun
Contact Probes
LED Flashlight

RECHARGING

1. The rechargeable batteries are already installed. The unit cannot be opened, as this will void the warranty.
2. We recommend charging the stun baton before it is used. Simply plug the charging cord into the bottom of the
unit and into a standard outlet. The red light on the bottom of the handle will illuminate while the charging cord is
plugged in. Note that the red light does not turn off or change color when fully charged. Simply charge for 8
hours then unplug it from the charging cord. IMPORTANT: do not charge for more than 8 hours at a time.
Overcharging can damage the unit and void the warranty. When used infrequently the unit will need to be
recharged for 8 hours every 60 days. If the flashlight is used frequently or if the electrical current becomes
Noticeably weaker, the unit will need to be recharged.

USING THE FLASHLIGHT

1. Slide the ON/OFF Switch on the bottom of the handle to the ON position.
2. Slide the Function Selector and Light Mode Switch up to the middle position.
3. The flashlight will come on in either the Hi, Low, or Strobe Mode.
4. If you want to change to another light mode move the Switch down to the bottom position then back up to the
middle position.
5. To turn the light off move the Function Selector & Light Mode Switch to the bottom position or turn the ON/Off
Switch to the OFF position. Note: Turning this switch back on will also change the light mode.

TESTING THE STUN GUN

We recommend test firing the stun gun and becoming familiar with its operation before you need to use it to defend
yourself. (WARNING: Do not test fire the stun gun for more than 1 second as this will damage the unit and void the
Warranty.)
1. Slide the ON/OFF Switch (located on the bottom of the unit) to the ON position.
2. Slide the Function Selector and Light Mode Switch up to the top position.
3. Press the Stun Activation Button to test fire the unit. Do not hold down the button for more than 1 second. You
will see and hear a charge fire across the top of the unit between the test probes.
4. IMPORTANT: Slide the ON/OFF Switch on the bottom of the unit to the OFF position when you have finished
test firing.
SWBAR9R Instructions
Stun Activation Button
Function Selector
and Light Mode
Switch
Stun
Warning Light
On/Off Switch
(Not Shown)
Charging Light
Indicator
(Not Shown)
Rev 5/9/2018
