STREET WISE SWLC21 Series Instruction Manual

1. Contact Probes
2. Test Probes
3. LED Flashlight
4. Stun Warning Light
5. Safety/Function Switch:
Off • Light/Stun • Alarm
6. Squeeze-N-Stun Trigger
7. Built-In Charger
8. Charging Indicator Light
9. Disable Pin
10. Wrist Strap
Important: The Disable Pin (attached to the wrist strap) must be inserted into the bottom of the unit in order for the
stun to operate. The alarm and light will both function without the Safety Pin inserted.

Charging the Batteries

The rechargeable batteries are already installed. The unit cannot be opened, as this will void the warranty.
1.
Before use, the stun gun will need to be charged for 8 hours. Insert the slide-out plug on the bottom of the
2.
unit into a standard outlet. The Charging Indicator Light (#8) will come on while charging.
IMPORTANT: Do not charge for more than 8 hours at a time. Overcharging can damage the unit and
void the warranty. Under normal use the unit will need to be recharged for 8 hours every 60 days. If the
LED Flashlight is used frequently or if the electrical charge produced by the stun gun becomes noticeably
weaker, the unit will need to be recharged.

Using the Flashlight

Slide the Safety/Function Switch located on the side of the unit up to the middle position to turn on the
1.
LED Flashlight.
2. Slide the Safety/Function Switch down to turn off the light.
Testing the Stun Gun (WARNING: Do not test fire the stun gun for more than 1 second as this will damage the unit
and void the warranty.)
1. Insert the disable pin (attached to the wrist strap) into the bottom of the unit.
Slide the Safety/Function Switch (#5) located on the side of the unit up to the middle position. The
2.
flashlight will come on and the Stun Warning Light (#4) will illuminate.
Press the Squeeze-N-Stun Trigger (#6) located on the side of the unit to test the stun gun. You will both
3.
see and hear an electrical charge fire across the top of the unit between the Contact Probes. When test
firing the unit, do not hold the button down for more than 1 second.
4 When testing is complete, slide the Safety/Function Switch all the way down to the bottom position to turn
the safety back on.
SWLC21 Series
Instruction Manual
4
1
2
3
5
6
7
8
9
10
Revised 10/18/2016
