STREET WISE SMS16BK Instruction Manual

Stun Activation Button
Test Probes
LED Flashlight
Contact Probes
CHARGING THE BATTERIES
1. The rechargeable batteries are already installed. The unit cannot be opened, as this will void the warranty.
2. Before use, the stun gun will need to be charged for 8 hours. Insert the included charging cord into the
bottom of the unit and the other end into your block charger (not included) then plug into a standard outlet.
The Charging Indicator Light will come on while charging.
IMPORTANT: Do not charge for more than 8 hours at a time. Overcharging can damage the unit and
void the warranty. Under normal use the unit will need to be recharged for 8 hours every 60 days. If the
LED Flashlight is used frequently or if the electrical charge produced by the stun gun becomes noticeably
weaker, the unit will need to be recharged.
USING THE FLASHLIGHT
Slide the Safety Switch located on the side of the unit up to the middle position to turn on the LED
1.
Flashlight.
2. Slide the Safety Switch down to turn off the light.
TESTING THE STUN GUN
(WARNING: Do not test fire the stun gun for more than 1 second as this will damage the unit and void the warranty.)
1. Slide the Safety Switch located on the side of the unit up to the top position to turn off the safety. The Stun
Warning Light above the Safety Switch will illuminate.
2. Press the Stun Activation Button on the side of the unit (above the Safety Switch) to test the stun
gun. You will see and hear an electrical charge fire across the top of the unit between the Test Probes.
3. When test firing the unit, do not hold the button down for more than 1 second. Slide the Safety Switch
down to the bottom position to turn the safety back on. The Stun Warning Light will turn off.
SMS16BK/PK
Instruction Manual
Stun Warning Light
Safety Switch
USB Charging Port
Charging Light
Bottom View
Key Ring
Rev 11/27/2018
