w w w . t h e - m s p a . c o m
F-MO062W/82W Mono
F-DU062W
EN
QUESTIONS? PROBLEMS?MISSING PARTS?
For FAQ, Manuals, Videos or Spare Parts, please visit
www.the-mspa.com/support
PLEASE DO NOT RETURN THE PRODUCT TO THE STORE
Due to MSpa's continuous product improvement process, MSpa reserves the right to change the specifications and appearance of its
products, which may result in updates to the instruction manual without prior notice.
Owner's Manual
Duet
F-NA062W Naval
F-TU062W Tuscany
Advertisement
Related Manuals for mspa Duet F-DU062W
Summary of Contents for mspa Duet F-DU062W
- Page 1 PLEASE DO NOT RETURN THE PRODUCT TO THE STORE Due to MSpa's continuous product improvement process, MSpa reserves the right to change the specifications and appearance of its products, which may result in updates to the instruction manual without prior notice.
- Page 2 To guide you in your initial MSpa experience, we are pleased to present you with this instruction manual. Please read this manual carefully before using the product for the first time. We are delighted to welcome you to the MSpa family, and look forward to sharing with you the full spectrum of our expertise.
- Page 3 SAFETY PRECAUTIONS For your own safety and that of your product, please make sure to follow the safety precautions below. Failure to follow the instructions may result in serious injury, property damage or death. Improper installation or operation will void the warranty. PLEASE ENSURE THAT YOU READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS KEEP THIS MANUAL FOR FUTURE REFERENCE DANGER...
- Page 4 ● Do not use the spa if it is damaged on delivery and/or if it malfunctions in any way. ● Contact the MSpa service center for further instructions. ● Keep all pets away from the spa to avoid any damage.
- Page 5 ● The spa contains a UVC emitter. To replace or repair the UVC emitter, contact a professional operator.It’s strictly forbidden for users to replace the UVC emitter. Unintended use of the appliance or damage to the housing may result in the escape of dangerous UVC radiation. UVC radiation, even in small doses, may cause harm to the eyes and skin.
- Page 6 Warning: The appliance's water protection levels vary across different product zones, as shown in the following diagram. (The installation regulations comply with IEC 60364-7-702.) 2.5 m Zone 2 Zone 1 Zone 2 2.5 m Zone 0 Zone 0 1.5 m 2.0 m 2.0 m 1.5 m...
- Page 7 SPECIFICATIONS BUBBLE SPA Model No. Seating Water Outside Shape Inside Dimensions Height Weight Temp Increasing Rate Capacity Capacity Dimensions / Code F-MO062W Mono F-NA062W 930 L Round Ø1.73 m (68”) Ø1.63 m (64”) 0.65m (26”) 37 kg (81.6 lbs) 1.5-2.0 °C/h Naval (245 Gal.) F-DU062W...
- Page 8 The drawings are for reference only. Actual products may vary. Not to scale. Use accessories exclusively provided by MSpa for safety reasons. When ordering parts, be sure to quote the MSpa model number and description. PRODUCT OVERVIEW Packaging content – TUSCANY REF.
- Page 9 FIRST USE AND SETUP PREPARATION Site preparation and requirements ● The spa can be installed indoors or outdoors in around 10 minutes by one or more persons. For household use only. ● The spa must be set up on a flat, smooth and supporting surface that is able to bear the maximum load of the filled spa with the listed maximum number of occupants.
- Page 10 NOTE: Lay out all the parts on the ground and make sure they are all accounted for. For missing or damaged parts contact the appropriate MSpa after-sales service center.
- Page 11 Inflating the Spa Air Bladder 1. Open the inflation valve and insert the inflation hose into the valve. 2. Slide the pump piston up and down to inflate until it is firm to the touch but not hard. 3. Disconnect the inflation hose from the valve, then close and push in the inflation valve. NOTE: If you need to add some air to the spa tub wall or air bladder after they have been set up, please see the “Inflating the spa tub wall”...
- Page 12 SPA SETUP: TUSCANY ASSEMBLY - TUSCANY Spa Tub Assembly 1. Take out the foam mat and spread it over the cleared area. 2. Place the ‘open-end panel’ towards the corner where you intend to install your external control box. 3. Connect two panel pieces together by sliding a corner beam between them and then do the same with the remaining panels. 4.
- Page 13 1-3. Install the Contorl Box 1. Ensure all the rubber sealing rings are in place. 2. Connect the control box to the spa by lining up the numbers (1 to 1, 2 to 2 and 3 to 3). Securely hand-tighten the connectors. NOTE: Do not use tools to tighten.
- Page 14 Lock Unlock ALL-IN-ONE CONTROL PANEL LED display Heater Button Filter Button Timer Button Bubble Button - Adjust the bubble level by pressing the button (L1:300W, L2: 500W, L3:720W) UVC Button Ozonator Button Down Button Up Button LED display °C °F Once powered-up, press the RESET on the PRCD.
- Page 15 BUBBLE MASSAGE BUBBLE button to turn the function on; hold down the BUBBLE button for 3 seconds to turn the function off. Press the BUBBLE BUBBLE (500W). Press the BUBBLE button to switch The bubble setting can be adjusted to three different levels. The default setting is at level 2 the setting to level 3 (720W).
- Page 16 WATER MAINTENANCE AND CHEMICALS CAUTION: ALWAYS ENSURE THE SPA IS UNPLUGGED BEFORE BEGINNING ANY MAINTENANCE WORK TO AVOID THE RISK OF INJURY OR DEATH. FILTER CARTRIDGE MAINTENANCE 1. Inspect and clean the filter cartridge gently after each use. Follow the steps below: NOTE: Change the filter cartridge every 3-5 days, or if the filter cartridge remains soiled and discolored.
- Page 17 Water Treatment: ● It is good practice with an existing spa to keep all air jets open and valves closed to allow chemically treated water to flush through all pipework. ● Always follow the chemical manufacturer’s directions, and the health and hazard warning. ●...
- Page 18 Cleaning The Spa Tub If dirt is visible in the water or if the water becomes cloudy and the correct water chemistry does not clear it up, change the water and clean the spa tub. See the “Spa tub drainage” section on how to drain the spa. While empty, clean and/or replace the filter cartridge. Use a sponge and mild soap solution to wipe away any soil or stains on the inside of the spa wall.
- Page 19 How to fix a leaking valve (MONO / NAVAL / DUET) A. Try to tighten the valve 1. Inflate your spa to the max air pressure 2. Insert your valve wrench into the valve and turn the wrench clockwise to tighten the valve onto the spa B.
- Page 20 Clean the parts and tubes that the water goes through 1. Add more water to the minimum line F1 shows 15s after pressing FILTER, HEATING or UVC 2. Clean the parts and tubes that water goes through 3. Contact local MSpa Service Center...
- Page 21 SPA LEAKING Drainage valve is not closed completely Close the drainage valve. Contact the MSpa Service Center, if spa is still leaking Water leaks from the spa pool body Repair the leaking hole/split with the repair kit material...
- Page 22 Where the cost of repairs or replacement is not covered by this warranty, MSpa will advise the owners and the cost shall be charged to the owner.
