w w w . t h e - m s p a . c o m

F-MO062W/82W Mono

QUESTIONS? PROBLEMS?MISSING PARTS?

For FAQ, Manuals, Videos or Spare Parts, please visit

www.the-mspa.com/support

PLEASE DO NOT RETURN THE PRODUCT TO THE STORE

Due to MSpa's continuous product improvement process, MSpa reserves the right to change the specifications and appearance of its

products, which may result in updates to the instruction manual without prior notice.

Owner's Manual

F-DU062W Duet

F-TU062W Tuscany

Need help?

Do you have a question about the F-MO062W Mono and is the answer not in the manual?

Questions and answers

Summary of Contents for mspa F-MO062W Mono

Page 1 PLEASE DO NOT RETURN THE PRODUCT TO THE STORE Due to MSpa's continuous product improvement process, MSpa reserves the right to change the specifications and appearance of its products, which may result in updates to the instruction manual without prior notice.
Page 2 To guide you in your initial MSpa experience, we are pleased to present you with this instruction manual. Please read this manual carefully before using the product for the first time. We are delighted to welcome you to the MSpa family, and look forward to sharing with you the full spectrum of our expertise.
Page 3 SAFETY PRECAUTIONS For your own safety and that of your product, please make sure to follow the safety precautions below. Failure to follow the instructions may result in serious injury, property damage or death. Improper installation or operation will void the warranty. PLEASE ENSURE THAT YOU READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS KEEP THIS MANUAL FOR FUTURE REFERENCE DANGER...
Page 4 ● Do not use the spa if it is damaged on delivery and/or if it malfunctions in any way. ● Contact the MSpa service center for further instructions. ● Keep all pets away from the spa to avoid any damage.
Page 5 ● Do not add bath oil or bath salt to the spa water. ● NEVER PUT HEAD UNDER WATER. ● Avoid swallowing the spa water. ● The spa contains a UVC emitter. To replace or repair the UVC emitter, contact a professional operator.It’s strictly forbidden for users to replace the UVC emitter.
Page 6 Warning: The appliance's water protection levels vary across different product zones, as shown in the following diagram. (The installation regulations comply with IEC 60364-7-702.) 2.5 m Zone 2 Zone 1 Zone 2 2.5 m Zone 0 Zone 0 1.5 m 2.0 m 2.0 m 1.5 m...
Page 7 SPECIFICATIONS BUBBLE SPA Model No. Seating Water Shape Outside Dimensions Inside Dimensions Height Weight Temp Increasing Rate Capacity Capacity / Code F-MO062W Mono 930 L Round Ø1.73 m (68”) Ø1.63 m (64”) 0.65m (26”) 37 kg (81.6 lbs) 1.5-2.0 °C/h F-DU062W (245 Gal.) DUET...
Page 8 The drawings are for reference only. Actual products may vary. Not to scale. Use accessories exclusively provided by MSpa for safety reasons. When ordering parts, be sure to quote the MSpa model number and description. PRODUCT OVERVIEW Packaging content – TUSCANY REF.
Page 9 FIRST USE AND SETUP PREPARATION Site preparation and requirements ● The spa can be installed indoors or outdoors in around 10 minutes by one or more persons. For household use only. ● The spa must be set up on a flat, smooth and supporting surface that is able to bear the maximum load of the filled spa with the listed maximum number of occupants.
Page 10 NOTE: Lay out all the parts on the ground and make sure they are all accounted for. For missing or damaged parts contact the appropriate MSpa after-sales service center.
Page 11 Inflating the Spa Air Bladder 1. Open the inflation valve and insert the inflation hose into the valve. 2. Slide the pump piston up and down to inflate until it is firm to the touch but not hard. 3. Disconnect the inflation hose from the valve, then close and push in the inflation valve. NOTE: If you need to add some air to the spa tub wall or air bladder after they have been set up, please see the “Inflating the spa tub wall”...
Page 12 SPA SETUP: TUSCANY ASSEMBLY - TUSCANY Spa Tub Assembly 1. Take out the foam mat and spread it over the cleared area. 2. Place the ‘open-end panel’ towards the corner where you intend to install your external control box. 3. Connect two panel pieces together by sliding a corner beam between them and then do the same with the remaining panels. 4.
Page 13 Inflating the Spa Air Bladder 1. Screw the inflation adaptor to the control box. 2. Open the inflation valve on the bladder and insert the inflation hose into the valve. 3. Press Bubble button to start inflating the bladder. When the bladder is firm to the touch but not hard, stop inflating by long press Bubble button for over 3 seconds.
Page 14 Lock Unlock ALL-IN-ONE CONTROL PANEL LED display Heater Button Filter Button Timer Button Bubble Button - Adjust the bubble level by pressing the button (L1:300W, L2: 500W, L3:720W) UVC Button Ozonator Button Down Button Up Button LED display °C °F Once powered-up, press the RESET on the PRCD.
Page 15 BUBBLE MASSAGE BUBBLE Press the BUBBLE button to turn the function on; hold down the BUBBLE button for 3 seconds to turn the function off. BUBBLE The bubble setting can be adjusted to three different levels. The default setting is at level 2 (500W).
Page 16 WATER MAINTENANCE AND CHEMICALS CAUTION: ALWAYS ENSURE THE SPA IS UNPLUGGED BEFORE BEGINNING ANY MAINTENANCE WORK TO AVOID THE RISK OF INJURY OR DEATH. FILTER CARTRIDGE MAINTENANCE 1. Inspect and clean the filter cartridge gently after each use. Follow the steps below: NOTE: Change the filter cartridge every 3-5 days, or if the filter cartridge remains soiled and discolored.
Page 17 Water Treatment: ● It is good practice with an existing spa to keep all air jets open and valves closed to allow chemically treated water to flush through all pipework. ● Always follow the chemical manufacturer’s directions, and the health and hazard warning. ●...
Page 18 Cleaning The Spa Tub If dirt is visible in the water or if the water becomes cloudy and the correct water chemistry does not clear it up, change the water and clean the spa tub. See the “Spa tub drainage” section on how to drain the spa. While empty, clean and/or replace the filter cartridge. Use a sponge and mild soap solution to wipe away any soil or stains on the inside of the spa wall.
Page 19 B. Re-install or replace the valve 1. Completely deflate your spa 2. Remove the dust cap, insert the valve wrench into the valve and turn counter-clockwise to remove the valve Rubber Ring 3. Check the rubber ring to make sure that it is in the correct position, secured tightly around the valve, and check that there is no debris in the way...
Page 20 SPA LEAKING Drainage valve is not closed completely Close the drainage valve. Contact the MSpa Service Center, if spa is still leaking Water leaks from the spa pool body Repair the leaking hole/split with the repair kit material...
Page 21 2. The corresponding service provider will be displayed. * You can find the contact information of local service center on the back of the warranty card. CONTACT YOUR LOCAL MSPA DEALER OR SERVICE CENTER FOR ANY PRODUCT-RELATED QUESTIONS OR PROBLEMS.
Page 22 Where the cost of repairs or replacement is not covered by this warranty, MSpa will advise the owners and the cost shall be charged to the owner.

This manual is also suitable for:

F-mo082w mono F-du062w duet F-tu062w tuscany
