BPTA-WDPGT502
Bitspower Sedna GT502 for ASUS TUF Gaming GT502 Case
Accessories
1
M4x8 Screw
BPTA-WDPGT502
Drain
2
4 PCS
BPTA-EFW-GS
Digital RGB PIN on
Fill
1
motherboard
Both the front and the back side of the reservoir have a
fill or drain hole, choose the one that suits you.
3
1 PCS
Fitting + soft tube
1
motherboard or
2
2
BPTA-DRGBMFC
DRGB Multi Function Controller
(Not included)
EN ver.3
1 PCS
other equipment.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BPTA-WDPGT502 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bitspower BPTA-WDPGT502

  • Page 1 EN ver.3 BPTA-WDPGT502 Bitspower Sedna GT502 for ASUS TUF Gaming GT502 Case Accessories M4x8 Screw 4 PCS BPTA-EFW-GS 1 PCS Fitting + soft tube 1 PCS BPTA-WDPGT502 Digital RGB PIN on motherboard or other equipment. Fill BPTA-DRGBMFC motherboard DRGB Multi Function Controller...
  • Page 2 As such, if you feel uncomfortable with the steps involved in installing this product, please reach out to our customer support for assistance. We recommend the use of a leak tester, such as our Bitspower Digital Leak Detector, after completing the assembly of your liquid cooling loop to make sure there are no leaks prior to filling up your loop with coolant.
  • Page 3 Power Supply and Pump SPECIFICATION Rated voltage:12V DC Power consumption:15W Maximum flow:11±15% L/min Noise:≤ 40dBA PWM:Yes MTBF:15000 hours Warranty:2 years Dimension: 62 x 62 x 46.7mm Maximum lift of the water pump: 5.5±0.5m If need be All tube connect hole sare G 1/4 threaded holes.
  • Page 4 Water Choose your desired dye color and mix it with pure distilled water. Pour the water mix into the reservoir via the water filling hole. Once the reservoir is 90% full, turn on the power supply for the pump to run and let the air exit the loop.
  • Page 5 Assembly steps step 1 step 2 Use M4x8 Screw fixed [ 5 ]...
  • Page 6 Recommended installation method Accessories(additional purchases) BPN-NLS360-F2PB BP-NCCLT16AC-L500 BPTA-F60 BPTA-CPUMS-SKI BPTA-90RE BPTA-F61 BPTA-FX1812NT-3 GPU Water Block BP-DG14AALPI BPTA-DOTFH1622 BPTA-F95 BPTA-F63 Connect the third radiator to the rear. Three radiators installation methods, it is recommended to use m-ATX motherboard. [ 6 ]...
