BPTA-WDPO11DEVO-REV
Bitspower Sedna O11D EVO-R for LIAN LI O11 Dynamic EVO
Series (Reverse Mode Ver.)
Accessories
1
M4x13 Screw
2
BPTA-WDPO11DEVO-REV
2 PCS
1 PCS
Fill
Digital RGB PIN on
1
motherboard
Drain
Both the front and the back side of the reservoir have a fill or
drain hole, choose the one that suits you.
1
2
motherboard or
2
BPTA-DRGBMFC
DRGB Multi Function Controller
(Not included)
EN ver.8
other equipment.
Advertisement
Related Manuals for Bitspower BPTA-WDPO11DEVO-REV
Summary of Contents for Bitspower BPTA-WDPO11DEVO-REV
- Page 1 EN ver.8 BPTA-WDPO11DEVO-REV Bitspower Sedna O11D EVO-R for LIAN LI O11 Dynamic EVO Series (Reverse Mode Ver.) Accessories M4x13 Screw 2 PCS BPTA-WDPO11DEVO-REV 1 PCS Fill Digital RGB PIN on motherboard or other equipment. BPTA-DRGBMFC motherboard DRGB Multi Function Controller...
- Page 2 As such, if you feel uncomfortable with the steps involved in installing this product, please reach out to our customer support for assistance. We recommend the use of a leak tester, such as our Bitspower Digital Leak Detector, after completing the assembly of your liquid cooling loop to make sure there are no leaks prior to filling up your loop with coolant.
- Page 3 Power Supply and Pump SPECIFICATION Rated voltage：12V DC Power consumption：15W Maximum flow：11±15% L/min Noise：≤ 40dBA PWM：Yes MTBF：15000 hours Warranty：2 years Dimension: 62 x 62 x 46.7mm Maximum lift of the water pump: 5.5±0.5m If need be ※ When installing the GPU, it is necessary to remove the conduit module, and then install the corresponding fittings.
- Page 4 Water Choose your desired dye color and mix it with pure distilled water. Pour the water mix into the reservoir via the water filling hole. Once the reservoir is 90% full, turn on the power supply for the pump to run and let the air exit the loop.
- Page 5 Assembly steps step 1 step 2 PC-O11 Dynamic EVO (Not included) step 3 step 4 Side plate M4x13 Screw Front plate BPTA-WDPO11DEVO-REV [ 5 ]...
- Page 6 Recommended installation method Accessories(additional purchases) BPN-NLS360-F2PB BPTA-CPUMS-SKI BPTA-FX1812 9PCS BPTA-DOTFH1622 8PCS BP-NCCLT16AC-L500 BPTA-DRGBMFC BP-PFANMFH [ 6 ]...
