Nova 8212-R How-To

HOW TO ATTACH YOUR
SUCTION CUP ASSIST BAR 12"
Item # 8212-R
Select a smooth, flat, non-porous
mounting surface with a completely
1
smooth 3.5" diameter area for both
suction sections. Clean the surface
with a damp cloth and dry thoroughly
(see figure 1).
2
Release suction levers by pulling them up
and away from the handle (see figure 2)
3
Firmly press the suction cups onto the mounting area and push the levers down.
Be sure the safety indicator fully shows green (see figure 3).
Figure 3
To Remove:
Flip both levers up and lift away from
4
the wall (see figure 2). Use suction
cups tabs to help release from
mountiong surface (see figure 5).
3.5"
3.5"
Figure 1
Figure 2
NOTE: Test suction strength by
pulling on the handle. If loose,
repeat steps 1-3 (see figure 4).
Figure 4
Suction Cups
Tabs
Figure 5
Quick No Tools
Required
Installation
