Nova 8800 Quick Assembly Manual

ASSEMBLE YOUR
SHOWER CHAIR/COMMODE
WITH WHEELS & BACK
Item # 8800
Capacity not to exceed 250 lb
a.
1
fig.1
2
Slide backrest upholstery onto backrest starting from
the bottom opening of the upholstery.
3

HOW TO USE YOUR SHOWER CHAIR/COMMODE

1
Before using the chair, lock all wheels by depressing the hanging end
of lever above the wheel. Once the user is seated and stable, unlock the
wheels by depressing the raised end of lever, and roll the commode to
the desired location.
NOTE: Be especially careful and do not move too quickly over any
threshold, mat/carpet, or other uneven surfaces to avoid tipping the user forward.
2
Lock the wheels before the user seated in
the chair attempts to stand up.
HOW TO
a. (1) Frame
b. (1) Bucket & Lid
b.
On the back end of the chair where the arms slope at an
angle, locate 4 holes, 2 on each side of the frame. Slide the 4
screws through the backrest and frame as shown in figure 1.
On the threaded end of the screw, slide on all 4 washers and
tighten all 4 nuts as shown in figure 2.
fig.2
While facing the front of the chair, slide the bucket
under the seat through the left hand side until the
bucket hits the rubber bumper on the other end of the
seat. The lip of the bucket must slide in between the
front and rear brackets and the bucket handle should
face either the front or rear of seat, as shown.
WHAT'S IN THE BOX
c. (1) Backrest
d. (1) Backrest upholstery
e. (4) Sets of screws, nuts, & washers
c.
3
QUICK ASSEMBLY
Follow these
SIMPLE STEPS
TOOLS
NEEDED
10mm wrench
d.
After use, remove the bucket,
discard waste and sanitize.
Revised March 13, 2018
Phillips
screwdriver
e.
