- Page 1 RMS 1A USER MANUAL Article No: RGB-RD-UM-RMS 1A E000 Revision No: V1.0...
- Page 2 Chapter 2 Instal Your Product........................11 2.1 Install Table Stand..........................11 2.2 19 Inch Bracket..........................12 Chapter 4 Order Codes...........................13 4.1 Product.............................13 4.2 Accessories............................13 Chapter 4 Support............................14 Chapter 5 Appendix............................15 5.1 Specification.............................15 5.2 Terms & Definitions......................... 16 5.3 Revision History..........................20 RMS 1A User Manual...
- Page 3 RGBlink. If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.
- Page 4 Installation Safety Summary Safety Precautions For all RMS 1A processor installation procedures, please observe the following important safety and handling rules to avoid damage to yourself and the equipment. To protect users from electric shock, ensure that the chassis connects to earth via the ground wire provided in the AC power Cord.
- Page 5 Unpacking and Inspection Before opening RMS 1A processor shipping box, inspect it for damage. If you find any damage, notify the shipping carrier immediately for all claims adjustments. As you open the box, compare its contents against the packing slip. If you find any shortages, contact your sales representative.
- Page 6 Chapter 1: Your Product Chapter 1 Your Product 1.1 In the Box AC Power Cord Note: the power adapter is plug interchangeable RMS 1A User Manual...
- Page 7 Each RMS 1A is board with 1x DVI In, compatible with VGA and CVBS via adapter, 1 x DVI Loop which offers signal exactly the same as IN, 1 x USB which allows to preview media files from USB disk.
- Page 8 Chapter 1: Your Product System Connection RGBlink video processing solutions provide a range of flexible configuration options for professional applications. RMS 1A System Connection Diagram RMS 1A User Manual...
- Page 9 Chapter 1: Your Product 1.2.1 Back Panel USB Port DVI+VGA IN connect to the output of media device or processor DVI+VGA LOOP Connect to the input of processor or next RMS 1A 12V DC Power connector Cooling Fan RMS 1A User Manual...
- Page 10 Chapter 1: Your Product 1.2.2 Front Panel LCD Screen RMS 1A User Manual...
- Page 11 Chapter 1: Your Product Dimension 1.2.3 Following is the dimension of RMS 1A for your reference: RMS 1A User Manual...
- Page 12 Mount to a camera bracket 1 .Insert the T-type nylon gasket② into the stand③hole. 2. Mount RMS 1A①to the table stand. 3. Insert the gasket ④and tighten the inclination screw⑤ 4. You can mount the table stand to a traditional camera.
- Page 13 1.Use the M4*8 screws to attach the handle ① and the rack ③ 2. Connect 2 RMS 1A by means of the attachment bracket ⑥ on top and the bottom. Use the screws M4*8 ⑦and M3*5 ⑧ to fix the bracket.
- Page 14 Chapter 4 Order Codes 4.1 Product 410-8424-01-0 RMS1A 410-8424-02-0 2pcs RMS1A in 19inch rack accessory 410-8424-03-0 RMS1A with Desktop Accessory 4.2 Accessories 410-8424-04-0 Dual monitor rack set 410-8424-05-0 Single monitor desktop set RMS 1A User Manual...
- Page 15 Chapter 4 Support RMS 1A User Manual...
- Page 16 VESA 640x480@60 | 800x600@60 | 1024x768@60 |1280x1204@60 | 1600x1200@60 |1920x1200@60 Single Link Supported Standard UXGA Extras Input Voltage DC 12V Max Power Temperature 0°C~40°C Humidity 10% to 85% Product Warranty 3 years parts and labor warranty RMS 1A User Manual...
- Page 17 Color burst is 3.58 MHz for NTSC and 4.43 MHz for PAL. “Color temperature”: The color quality, expressed in degrees Kelvin(K), of a light source. The higher the color temperature, the bluer the light. The lower the temperature, the RMS 1A User Manual...
- Page 18 JPEG typically achieves 10:1 compression with little perceptible loss in image quality. Produces blocking artifacts. “MPEG”: Motion Picture Expect Group. A standard committee under the auspices of the RMS 1A User Manual...
- Page 19 Low saturation is like adding white to the color. For example, a low-saturated red looks pink. “Scaling”: A conversion of a video or computer graphic signal from a starting resolution to a new resolution. Scaling from one resolution to another is typically done to optimize the RMS 1A User Manual...
- Page 20 640×480 with a color palette of 16 bits and 256,000 colors. “YCrCb”: Used to describe the color space for interlaced component video. “YPbPr”: Used to describe the color space for progressive-scan (non-interlaced) component video. RMS 1A User Manual...
- Page 21 Chapter 6: Appendix 5.3 Revision History The table below lists the changes to the Video Processor User Manual. Format Time ECO# Description Principal V 1.0 2019-08-01 0000 Release Fanny RMS 1A User Manual...
