MSP 227
USER MANUAL
Article No: RGB-RD-UM-MSP 227 E001
Revision No: V1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the MSP 227 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RGBlink MSP 227

Summary of Contents for RGBlink MSP 227

  • Page 1 MSP 227 USER MANUAL Article No: RGB-RD-UM-MSP 227 E001 Revision No: V1.0...
  • Page 2 Chapter 4 Ordering Codes ........................... 22 4.1 Product ............................22 Chapter 5 Support ............................23 5.1 Contact Us ............................. 23 Chapter 6 Appendix ............................. 24 6.1 Specification ..........................24 6.2 Terms & Definitions ........................25 6.3 Revision History ..........................29 MSP 227 User Manual...
  • Page 3 RGBlink. If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.
  • Page 4 Installation Safety Summary Safety Precautions For all MSP 227 processor installation procedures, please observe the following important safety and handling rules to avoid damage to yourself and the equipment. To protect users from electric shock, ensure that the chassis connects to earth via the ground wire provided in the AC power Cord.
  • Page 5 Site Preparation The environment in which you install your MSP 227 should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components.
  • Page 6 Chapter 1 Your Product 1.1 In the Box AC Power Cord Adapter Adapter Adapter DVI-HDMI DVI-VGA DVI-YPbPr/AV MSP 227 User Manual...
  • Page 7 Chapter 1: Your Product 1.2 Product Overview  MSP 227 converts any input of AV/YPbPr/VGA/DVI/HDMI to any output of AV/YPbPr/VGA/ DVI/HDMI.  Buttons on the front panel to setup and configure the MSP 227.  When no Menu on the screen, “Enter/Output” button works as Output to select output port, such as AV, YPbPr, VGA, DVI or HDMI.
  • Page 8 This button used for selecting the left option. RIGHT Button This button used for selecting the right option. ENTER/OUTPUT Button This button used for confirmation. When no Menu on the screen, “Enter/Output” button works as Output to select output port. MSP 227 User Manual...
  • Page 9 DVI to VGA/HDMI/YPbPr adapter. Output Connectors DVI-I – DVI Connect to the monitor or LED display which has DVI interface. (This connector does not support hotplug). Power Connection Power Input Standard 12V/3A power supply. MSP 227 User Manual...
  • Page 10 Chapter 1: Your Product 1.2.3 Bottom Panel and Dial Switch Dial Switch Dial Switch Used to set the output format. Please refer to the graph instruction on the bottom panel for specific operation. Bottom Panel MSP 227 User Manual...
  • Page 11 Chapter 1: Your Product Dimension 1.2.4 Following is the dimension of MSP 227 for your reference: MSP 227 User Manual...
  • Page 12 2.2 Plugging in Main Power Connect AC power cord to device and plug into wall socket. 2.3 Turning on Your Product Turn on power at wall socket and the device will get into working status. MSP 227 User Manual...
  • Page 13 3.1 Using the MENU Button 1. Connect one end of the DVI cable to the DVI output of MSP 227, and the other end to the DVI input of the display, turn on the power for the display and MSP 227.
  • Page 14 Chapter 3: Using Your Product 3.2 Understanding the MENU Structure The MENU structure is shown in the figure below: MSP 227 User Manual...
  • Page 15 There are 6 menu items in the main menu, and display in 1 page. Push the [UP/DOWN] button to select the menu items, and push the [ENTER/OUTPUT] button to confirm. If push the [MENU] button, the OLED display will return to the last level menu. 3.3.2 Picture Mode MSP 227 User Manual...
  • Page 16 Default Contrast 50, Brightness 55, Color 50, Sharpness 0 and Tint 50 in standard mode. No setup required. Picture Mode Mild Default Contrast 48, Brightness 48, Color 50, Sharpness 0 and Tint 50 in mild mode. No setup required. User MSP 227 User Manual...
  • Page 17 Default Color 50, Sharpness 0 and Tint 50 in user mode. User can set the Contrast and Brightness. Dynamic Default Contrast 55, Brightness 48, Color 55, Sharpness 0 and Tint 50 in dynamic mode. No setup required. 3.3.3 Color Temperature MSP 227 User Manual...
  • Page 18 Default Red 70, Green 38 and Blue 50 if select warm. No setup required. Color Temperature User User can set Red, Green and Blue if select user mode. Cool Default Red 50, Green 38 and Blue 70 if select Cool. No setup required. MSP 227 User Manual...
  • Page 19 Level 1, default setting. Level 2, Zoom out 2%. Level 3, Zoom out 6%. Zoom Out Level 4, Zoom out 10%. *: Only available when AV output. Note: MSP 227 V1.0 can not support this function. MSP 227 User Manual...
  • Page 20 Vertical Pos. Push the [UP/DOWN] button to increase or decrease the vertical position value. Size Push the [UP/DOWN] button to increase or decrease the size. Phase Push the [UP/DOWN] button to increase or decrease the phase. MSP 227 User Manual...
  • Page 21 Chapter 3: Using Your Product 3.3.7 Language/菜单语言 Language/菜单语言 Select Chinese or English. MSP 227 User Manual...
  • Page 22 Chapter 3 : Using Your Product 3.4 System Connection Besides standard DVI, the MSP 227 also supports HDMI with DVI-HDMI adapter, VGA with DVI-VGA adapter, YPbPr/AV with DVI-YPbPr adapter. Adapters DVI-HDMI DVI-YPbPr/AV DVI-VGA Connection YPbPr video connection AV Video Connection...
  • Page 23 Chapter 4 Ordering Codes 4.1 Product 601-0227-01-0 MSP 227 DVI Cross Converter MSP 227 User Manual...
  • Page 24 Chapter 5 Support 5.1 Contact Us MSP 227 User Manual...
  • Page 25 VGA: Up to 1920x1080P@60Hz YPbPr: Up to 1920x1080P@60Hz AV: PAL / NTSC Extras Power Standard 12V/3A Operating Temperature 0°C~40°C Storage Temperature -20°C~60°C Main Unit Weight 0.35kg Main Unit Dimensions 142mm×89.7mm×23.5mm Product Warranty 3 years parts and labor warranty MSP 227 User Manual...
  • Page 26 Color burst is 3.58 MHz for NTSC and 4.43 MHz for PAL.  “Color temperature”: The color quality, expressed in degrees Kelvin(K), of a light source. The higher the color temperature, the bluer the light. The lower the temperature, the MSP 227 User Manual...
  • Page 27 JPEG typically achieves 10:1 compression with little perceptible loss in image quality. Produces blocking artifacts.  “MPEG”: Motion Picture Expect Group. A standard committee under the auspices of the MSP 227 User Manual...
  • Page 28 Low saturation is like adding white to the color. For example, a low-saturated red looks pink.  “Scaling”: A conversion of a video or computer graphic signal from a starting resolution to a new resolution. Scaling from one resolution to another is typically done to optimize the MSP 227 User Manual...
  • Page 29 640×480 with a color palette of 16 bits and 256,000 colors.  “YCrCb”: Used to describe the color space for interlaced component video.  “YPbPr”: Used to describe the color space for progressive-scan (non-interlaced) component video. MSP 227 User Manual...
  • Page 30 Chapter 6: Appendix 6.3 Revision History The table below lists the changes to the Video Processor User Manual. Format Time ECO# Description Principal V1.0 2016-12-07 0000# Vira Release MSP 227 User Manual...
