- Page 1 Smart Toilet wiss adison INSTALLATION INSTRUCTIONS ® @SwissMadison #WellMadeForever www.swissmadison.com | 1-434-623-4766 | info@swissmadison.com...
- Page 2 · · The step-by-step guidelines in the installation instructions are a general reference. Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss Madison products by hiring a licensed professional. · Read installation and maintenance instructions thoroughly before installing. Be sure to use proper tools and always wear proper personal safety accessories for your protection.
- Page 3 ONE-PIECE TOILET INSTALLATION INSTRUCTIONS 1. Turn Off Water Supply 2. Rough-In the Toilet · Close toilet supply valve and flush tank · Measure the wall from behind the toilet to the completely, use towel to remove excess water. middle of the closet bolt. Your rough-in ·...
- Page 4 · · The step-by-step guidelines in the installation instructions are a general reference. Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss Madison products by hiring a licensed professional. · Read installation and maintenance instructions thoroughly before installing. Be sure to use proper tools and always wear proper personal safety accessories for your protection.
- Page 5 SMART SEAT BIDET IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed: 1. The appliance is not to be used by persons (including children) with reduced physical, sensory, mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
- Page 6 SMART SEAT BIDET IMPORTANT SAFETY INSTRUCTIONS CAUTION - Failure to follow the instructions may cause body injury or property damage. 1. Do not install or use the product in wet places such as a steam room etc. 2. It is recommended to use a water-proof electrical outlet which should be installed in a place where it cannot easily get wet. 3.
- Page 7 SMART SEAT BIDET TECHNICAL SPECIFICATION Rating pressure 110-120V, 50/60Hz Rating power 1050-1250W Main Unit Minimum water pressure 0.07MPa (20L/min. flowing pressure) Water pressure range Maximum water pressure 0.8MPa (Hydrostatic pressure) Electrical wire Length is about 1.8 m Container capacity 600 mL Heating power 1000 W Water temperature...
- Page 8 SMART SEAT BIDET PACKAGING LIST The appearance and function of Remote Control the remote control are subject to Panel Parts the actual product 1. Base plate 2. Bolt (2 pcs.) 3. Flat washer (2pcs.) Base Plate Parts 4. Plastic plate (2pcs.) 5.
- Page 9 SMART SEAT BIDET MAIN UNIT IDENTIFICATION Water inlet connector Water discharging cover Side receiving Main unit window disassembly button Main unit button Socket Remote control receiving window Power indicator Energy saving indicator Wand Seat Hole for rear cleaning Drying device Base plate Night light Hold for front cleaning...
- Page 10 SMART SEAT BIDET INSTALLATION INSTRUCTIONS Installation Dimensions NOTE: Please check if the installation dimensions match the user’s toilet. 15 ³⁄16” 5 ¹⁄8” - 6 ¹⁄2” 20 ¹⁄4” 17 ¹¹⁄16” - 19 ¹⁄2” 11 ¹³⁄16” 7 7⁄8” Installation of Mounting Plate Press the expansion nuts into the installation holes in the toilet, then install the base plate, plastic plates, flat washers and bolts as per the drawing and tighten the bolts.
- Page 11 SMART SEAT BIDET INSTALLATION INSTRUCTIONS Installation and Disassembly of Main Unit Disassembly: Installation Press the “removal button” Push the washlet back on washlet, until a “click” is onto the base plate until a heard, and pull it out. “click” is heard. CLICK CLICK NOTE: Before pulling out the washlet, release hand from “removal button”.
- Page 12 SMART SEAT BIDET PACKAGING LIST Checking the Power and Water Supply Connect the water supply hose and turn on the Insert power plug into power socket. angle valve. Check for any leakage. Indicator light Electric leakage test button Protection switch Press protection switch...
- Page 13 SMART SEAT BIDET PACKAGING LIST Function Illustration of Keys in Main Unit and Actuator 1. Long press “Power” button to enter standby mode and then quick press “Power” button to restore functional mode. 2. When people sit, press “Power” button to stop the function of rear, front cleaning or drying.
- Page 14 SMART SEAT BIDET DAILY MAINTENANCE Main Unit Maintenance 1. Shut off power supply before maintenance. 2. Open the seat, press down the button located on the right side of the main unit and pull out the seat. Wipe with a soft damp cloth. 3.
- Page 15 SMART SEAT BIDET DAILY MAINTENANCE Inlet Filter Cleaning 1. Pull out electrical plug, then shut off water supply valve and remove water supply hose. 2. Remove the filter. Use the brush to clean the filter. 3. Put the filter back into inlet after cleaning. Then connect the water supply pipe. Remove the filter Use the brush to...
- Page 16 SMART SEAT BIDET TROUBLESHOOTING GUIDE Problem Cause Solution Water supply hose buckling causes Solve the buckling block No flushing Fill valve is off Turn on the fill valve Water supply is cut off Connect water supply and wait for the water Water supply hose buckling causes Solve the buckling partial block...
- Page 17 · · The step-by-step guidelines in the installation instructions are a general reference. Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss Madison products by hiring a licensed professional. · Read installation and maintenance instructions thoroughly before installing. Be sure to use proper tools and always wear proper personal safety accessories for your protection.
- Page 18 SMART SEAT BIDET REMOTE CONTENTS Installation Preparation 1. Remote control installation Usage Instruction 1. Remote control illustration 2. Rear/Front cleaning operation 3. Dry operation 4. Massage operation 5. Spray nozzle position adjustment 6. Water pressure adjustment 7. Energy saver 8. Full flush 9.
- Page 19 SMART SEAT BIDET REMOTE REMOTE INSTALLATION 1. Drill a 6 mm diameter hole on the wall with a 2. Remove the adhesive’s protective film on depth of 35 mm. Make sure the placement the back of the hanger. is reachable from the toilet seat. 3.
- Page 20 SMART SEAT BIDET REMOTE USAGE INSTRUCTIONS Signal instruction User code User code Front cleaning Rear cleaning Drying Massage Water pressure Spray nozzle position Stop Seat temperature Dry temperature Energy saver Nozzle cleaning Flush button Water temperature Load settings user 2 Lid close/seat close Lid open/seat open Hardware...
- Page 21 SMART SEAT BIDET REMOTE USAGE INSTRUCTIONS Rear/Front Cleaning Press “REAR/FRONT” button, the water comes out of the wand to clean the rear/front portion of body. It will automatically stop after a cycle of cleaning. Pressing “STOP” will stop the function immediately. Drying Operation Press “DRY”...
- Page 22 SMART SEAT BIDET REMOTE USAGE INSTRUCTIONS Massage Press “MASSAGE” button to activate massage function, the nozzle moves forward and back to extend the cleaning scope; Press “MASSAGE” button again to stop the function. Spray Nozzle Position Adjustment During “REAR” or “FRONT”, press spray nozzle button of “ ”...
- Page 23 SMART SEAT BIDET REMOTE USAGE INSTRUCTIONS Energy Saver Press “ENERGY SAVER” button, LCD screen shows energy saver and figures. It shows three options of energy saver period as 3-6-9-off, which can be selected accordingly. For example, user can set from 9:00 to 15:00 as energy saver according to following operation.
- Page 24 SMART SEAT BIDET REMOTE USAGE INSTRUCTIONS Full Flush (only for toilets with auto flush function) Press “FLUSH” button to activate full flushing. FLUSH Nozzle Cleaning Self clean for 90 secs. NOZZLE CLEANING Nozzle Self-Cleaning by Quick Press: Nozzle Self-Cleaning by Long Press: The deodorization function starts to Long press “NOZZLE CLEANING”...
- Page 25 SMART SEAT BIDET REMOTE TEMPERATURE ADJUSTMENT Dry Temperature Adjustment: Press “DRY” button to adjust temperature for drying. The LCD display of 1 to 5 lines means level 1 to 5. No display means normal temperature. Adjust level by up and down buttons. Water Temperature Adjustment: Press “WATER”...
- Page 26 SMART SEAT BIDET REMOTE USAGE INSTRUCTIONS User Code (only for toilets with User Code function) Long press “USER 1” or “USER 2” button to save the parameters including current pressure, nozzle position, dry temperature, water temperature, seat temperature and massage status. Quick press “USER 1”...
- Page 27 SMART SEAT BIDET REMOTE USAGE INSTRUCTIONS Auto Function (only for toilets with Auto Flush function) Full-automatic function can be achieved by three ‘”AUTO” buttons, convenient and practical. User can pre-set the suitable nozzle position, water pressure and temperature and save the setting. Full-automatic function will be activated by pressing the related function button when using afterwards.
- Page 28 SMART SEAT BIDET REMOTE USER INSTRUCTIONS Combination Button Night Light Press “STOP” button, then “DRY” button, night light will be in the off state; Repeat the process, night light will switch to non-intelligent state. Repeat above process constantly, the night light will switch between off state and intelligent state.
- Page 29 SMART SEAT BIDET REMOTE AUTOMATIC FUNCTION Set Automatic Rear Cleaning Function The default setting of the automatic water pressure, nozzle position, water temperature, wind temperature and seat temperature are on level three, the massage function is in the off state. User can reset based on personal preference.
- Page 30 SMART SEAT BIDET REMOTE AUTOMATIC FUNCTION Set Automatic Front Cleaning Function 1. Press spray nozzle position adjustment button to adjust nozzle to suitable position; Press “+”, “-” to adjust water pressure; set temperature level; open/close massage function. 2. Press “ ”...
- Page 31 SMART SEAT BIDET REMOTE AUTOMATIC FUNCTION Set Automatic Rear and Front Cleaning Combination Function NOTE: During using toilet, user can find the suitable level and temperature after comparing repeatedly. Please set the automatic Rear and Front cleaning combination function during toilet usage. The First Stage: Rear Cleaning 1.
- Page 32 (including, without limitation, costs associated with ‘professionals’ or ‘experts’, investigations, audits, analyses, attorneys and any other professional/hired services). The Swiss Madison® warranty is a comprehensive and explicit limit of liability. All items not disclosed within the warranty are not addressable within the responsibility of Swiss Madison®. Certain states have variances regarding implied warranties;...
