Ecodan EHPT17X-UKHLEWS Installation Manual page 10

Fig. 2b - Dimensions and EU Product Fiche - 22 mm Standard Models
C & E
J
KEY
A OVERALL HEIGHT
B SECONDARY RETURN TAPPING (NOT FITTED TO EHPT15X-UKHEWS/ EHPT17X-UKHEWS)
C HEAT PUMP FLOW CONNECTION (22 mm O/D COPPER)
D TUNDISH OUTLET CONNECTION (22 mm COMPRESSION)
E HEAT PUMP RETURN CONNECTION (22 mm O/D COPPER)
F HEATING ZONE 1 CIRCUIT FLOW CONNECTION (22 mm O/D COPPER)
G HEATING ZONE 1 CIRCUIT RETURN CONNECTION (22 mm O/D COPPER)
H COLD WATER INLET CONNECTION (22 mm COMPRESSION)
I HOT WATER OUTLET CONNECTION (22 mm COMPRESSION/3/4 " BSP M)
J THW5A SENSOR POCKET
K Wi-Fi ADAPTOR (INCLUDED, INSTALLER TO LOCATE AND MOUNT)
CAPACITY
A
B
C
D
E
F
G
J
K
MODEL
Energy efficiency
class
Standing loss in W
Storage volume V in
Litres
Technical parameters in accordance with European Commission regulations 814/2013 and 812/2013
10
579
I
C E
G
F
150 170
1131 1257
Not fitted Not fitted
1122 1122
505 630
1122 1122
194 194
350 350
675 815
Installer to locate and mount
EHPT15X-UKHEWS EHPT17X-UKHEWS
B
47.9
150
H
B A
K
D
210
1509
1050
1122
880
1122
194
350
925
EHPT21X-UKHEWS
B C
51.2 63.7
170 210
730
