- Page 1 INSTRUCTION MANUAL Cordless Auto Feed Screwdriver DFR452 DFR453 DFR551 DFR552 Read before use.
- Page 2 SPECIFICATIONS Model: DFR452 DFR453 DFR551 DFR552 Screw strip ø3.5 mm x 20 mm - ø4.2 mm x ø3.5 mm x 25 mm - ø4.2 mm x 41 mm 55 mm No load speed 0 - 6,000 min 0 - 4,500 min 0 - 6,000 min 0 - 4,500 min Overall length...
- Page 3 Keep children and bystanders away while Vibration operating a power tool. Distractions can cause you to lose control. The vibration total value (tri-axial vector sum) deter- Electrical safety mined according to EN62841-2-2: Power tool plugs must match the outlet. Never Work mode: screwdriving without impact modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power Model Vibration emis-...
- Page 4 If devices are provided for the connection of Use the power tool, accessories and tool bits dust extraction and collection facilities, ensure etc. in accordance with these instructions, tak- these are connected and properly used. Use of ing into account the working conditions and the work to be performed.
- Page 5 It may result in loss of your eyesight. CAUTION: Only use genuine Makita batteries. Do not short the battery cartridge: Use of non-genuine Makita batteries, or batteries that (1) Do not touch the terminals with any con- have been altered, may result in the battery bursting ductive material. causing fires, personal injury and damage. It will...
- Page 6 Charge the battery(ies) or replace it/them with battery cartridge with the groove in the housing and slip recharged battery(ies). it into place. Insert it all the way until it locks in place Let the tool and battery(ies) cool down. with a little click. If you can see the red indicator as shown in the figure, it is not locked completely. If no improvement can be found by restoring protection system, then contact your local Makita Service Center. To remove the battery cartridge, slide it from the tool while sliding the button on the front of the cartridge. Alert indicator The indicator lamp on the push drive mode selector raises an alert with flashing red lights when the tool works in the following operating conditions. Fig.1 ► 1 . Red indicator 2. Button 3. Battery cartridge...
- Page 7 Indicating the remaining battery Setting for desired screw lengths capacity For model DFR452 / DFR453 The tool provides 4 positive-lock screw length settings. Only for battery cartridges with the indicator Slide the stopper base out and in while depressing the Press the check button on the battery cartridge to indi- levers on the top surface of the stopper base so the cate the remaining battery capacity. The indicator lamps...
- Page 8 Switch action Numbers indicated on Screw length ranges the label 25 mm (1″) WARNING: Before installing the battery car- 25 mm - 30 mm (1″ - 1-3/16″) tridge into the tool, always check to see that the switch trigger actuates properly and returns to 30 mm - 35 mm (1-3/16″ - 1-3/8″) the "OFF" position when released. 35 mm - 40 mm (1-3/8″ - 1-9/16″) To start the tool, pull the switch trigger.
- Page 9 Installing driver bit Push drive mode To install a driver bit, place it into the spindle hole In push drive mode, the driver bit only rotates by apply- as far as it will go while pushing and holding the spin- ing pressure onto the driving surface with the stopper dle into the gear housing. Then release the spindle to base, allowing the tool to cut off power to the motor to secure the driver bit.
- Page 10 Removing driver bit Installing screw strip Press and hold the release buttons on each side of the casing, and then pull the casing apart. CAUTION: Always switch off and remove the battery cartridge when cutting the screw strip. Insert a screw strip through the screw strip guide on the casing, and then insert it through the screw loading guide in the feeder box.
- Page 11 Removing screw strip CAUTION: Always remove the screw strip before removing the attachment. To remove the screw strip, pull it upwards out of the feeder box. Fig.18 ► 1 . Groove 2. Hook 3. Screw The hook is convenient for temporarily hanging the tool. This can be installed on either side of the tool. To install the hook, insert it into a groove in the tool housing on either side and then secure it with a screw.
- Page 12 Depress the lock button while pulling the switch OPERATION trigger, and then release the switch trigger. Driving operation NOTICE: Always check the driver bit carefully for wear before driving operations. Replace a worn driver bit or poor fastening may result. NOTICE: Always hold the tool squarely against the driving surface. Holding it at an angle may dam- age the screw heads and cause wear on the driver bit. This may also lead to poor fastening.
- Page 13 Press and hold the release buttons on each side Driving in corner of the casing, and then pull the casing apart. CAUTION: Driving at a position closer than 15 mm to the wall or driving with the stopper base in contact with the wall may damage the screw heads and cause wear on the driver bit. This may also lead to poor fastening of screws and malfunction of the tool.
- Page 14 Centers, always using Makita replacement parts. After use Wipe off the tool using a dry cloth or cloth slightly moist- ened with soapy water at regular intervals. OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center.
- Page 16 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885A60-223 20231120...
