Graco 220107 Instructions-Parts List Manual

INSTRUCTIONS-PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
Dispenser Bar
Model 220107, Series A
900 psi (6.2 MPa, 62 bar) Maximum Fluid Working Pressure
Model 220107, Series A, with Meter Kit 239706
500 psi (3.4 MPa, 34 bar) Maximum Fluid Working Pressure
Table of Contents
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dispenser Bar Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dispensing Valve Service
Dispensing Valve Parts . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Phone Number . . . . . . . . . . . . . . . . . . . . . . . . . . .
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
. . . . . . . . . . . . . . . . . . . . . . .
ECOPYRIGHT 1985, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
First choice when
quality counts.t
2
3
4
5
6
7
7
8
8
307742
Rev. H
04203
Model 220107
Without Meter Kit
