BroilVection

Model JF64-BG/JF64-2-BG

Natural Gas/LP

Owner's Manual

A P P R OVA L S :

F O R Y O U R S A F E T Y :

Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other

appliance.

W A R N I N G :

Improper installation, adjustment, alteration, maintenance can cause property damage, injury, or death.

Read the installation, operating and maintenance instructions thoroughly before installing or servicing

this equipment.

Broiler area must be kept free of combustible materials, and the flow of combustion and ventilation air

must not be obstructed. Operating personnel must not perform any maintenance or repair

functions. Contact your Nieco Authorized Dealer.

IMPORTANT: RETAIN THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE

™

Need help?

Do you have a question about the BroilVection JF64-BG and is the answer not in the manual?

Questions and answers

Summary of Contents for Nieco BroilVection JF64-BG

Page 1 Broiler area must be kept free of combustible materials, and the flow of combustion and ventilation air must not be obstructed. Operating personnel must not perform any maintenance or repair functions. Contact your Nieco Authorized Dealer. IMPORTANT: RETAIN THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE...
Page 2 G. specifications ..........34 Nieco Corporation - Model JF64-BG...
Page 3 Keep these instructions for future reference. If the unit changes ownership, be sure this manual accompanies the equipment. IMPoRTanT The nieco Corporation reserves the right to change specifications and product design. such revi- sions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
Page 4 Authorized Nieco Distributors and Service Agencies will void the warranty and may significantly alter the performance of your broiler. The use of non-Nieco parts is capable of affecting these criteria, and may affect broiler performance, parts longevity and food safety. Your local Authorized Nieco Distributor and Service Agent has been factory trained and has a complete supply of parts for your Nieco Automatic Broiler.
Page 5 Distributor for adjustment or repair. • Use only genuine Nieco replacement parts for your broiler. Failure to do so will void the warranty and may significantly alter the performance of your broiler. The use of non-Nieco parts is capable of affecting these criteria, and may affect broiler performance, parts longevity and food safety.
Page 6 12” (305 mm) 0” (0 mm) 0” (0 mm) Sides of broiler 12” (305 mm) 0” (0 mm) 0” (0 mm) Front of broiler 12” (305 mm) 0” (0 mm) 24” (610 mm) (Feed end) Nieco Corporation - Model JF64-BG...
Page 7 For easy movement of the appliance, the connector should be installed with a "lazy" loop for minimum tension. note: Gas appliances should be disconnected prior to maximum movement. (Minimal movement is possible to connect hose.) Nieco Corporation - Model JF64-BG...
Page 8 Disconnect power before servicing. b.10 Pre-operation Check Be sure that all parts are installed in the proper location: Ventilation is turned on Broiler is plugged in Gas line is connected Nieco Corporation - Model JF64-BG...
Page 9 6. Bun Platen Temperature Control - Used to control the temperature of the bun platen. 7.Belt Reverse Button - Push and hold to reverse the direction of the belt to help clear a belt jam. Nieco Corporation - Model JF64-BG...
Page 10 2. PRODUCT SELECTION BUTTONS - Press to select different presets for different products. 3. ADJUSTMENT BUTTONS - Use to adjust product cook times, element settings and product names. 4. SELECTION INDICATOR LIGHT - Lights up to show which button is selected. Nieco Corporation - Model JF64-BG...
Page 11 1. Remove the discharge awning. Turn the MaIn PoWeR sWITCH on. Hold a lighter/match to the first upper burner on the discharge end until the burner lights. Once the first burner is lit, verify that all burners have ignited. Nieco Corporation - Model JF64-BG...
Page 12 Your Nieco Automatic Broiler is designed to automatically stop gas flow to the broiler in the event of power failure, gas pressure loss or any other related incident. No attempt to operate this appliance should be made in the event of a power failure.
Page 13 The control will then display the new set point for a few seconds, then display the actual tempera- ture. Under normal operation, when the platen is warming up, the control will display ‘Lo’, then it will display ‘Rdy’ when it is ready for use. Nieco Corporation - Model JF64-BG...
Page 14 Adjust the levers up or down to increase or decrease the height of the bun platen for proper bun grilling. Nieco Corporation - Model JF64-BG...
Page 15 W a s h , r i n s e , a n d s a n i t i z e i n t h e 3 -compartment s i n k . Nieco Corporation - Model JF64-BG...
Page 16 Meat Guide(s) (If equipped) Clean: Every 4 hours Feed End Tools Scrub Pad 3-Compartment Sink Instructions 1. Lift the meat guides up and off the feeder. 2. Wash, rinse, and sanitize in the 3-compartment sink. Nieco Corporation - Model JF64-BG...
Page 17 Instructions 1. Pull the release pin. 2. Lift wire belt feeder bases up and off. 3. Wash, rinse, and sanitize in the 3-compartment sink. REASSEMBLY: Pull the release pin and place feeder base in position. Nieco Corporation - Model JF64-BG...
Page 18 Feeder Housing Clean: Daily Feed End Tools Scrub Pad 3-Compartment Sink Instructions 1. Lift and remove. 2. Wash, rinse, and sanitize in the 3-compartment sink. REASSEMBLY: Hang feeder housing on brackets. Nieco Corporation - Model JF64-BG...
Page 19 Tools Scrub Pad 3-Compartment Sink Instructions 1. Slide the sheet out from under the bun platen. 2. Using a clean, damp cloth, wipe the sheet clean. REASSEMBLY: Slide the sheet back under the bun platen. Nieco Corporation - Model JF64-BG...
Page 20 Feed End Tools Scrub Pad Heat Resistant Gloves Degreaser 3-Compartment Sink Instructions 1. Lift up and off. 2. Take to sink area and spray with degreaser. 3. Wash, rinse, and sanitize in the 3-compartment sink. Nieco Corporation - Model JF64-BG...
Page 21 Discharge End Tools Scrub Pad Heat Resistant Gloves Degreaser 3-Compartment Sink Instructions 1. Lift up and off. 2. Take to sink area and spray with degreaser. 3. Wash, rinse, and sanitize in the 3-compartment sink. Nieco Corporation - Model JF64-BG...
Page 22 Discharge End Tools Scrub Pad Heat Resistant Gloves Degreaser 3-Compartment Sink Instructions 1. Lift up and off. 2. Take to sink area and spray with degreaser. 3. Wash, rinse, and sanitize in the 3-compartment sink. Nieco Corporation - Model JF64-BG...
Page 23 Discharge End Tools Scrub Pad Heat Resistant Gloves Degreaser 3-Compartment Sink Instructions 1. Lift up and off. 2. Take to sink area and spray with degreaser. 3. Wash, rinse, and sanitize in the 3-compartment sink. Nieco Corporation - Model JF64-BG...
Page 24 4. If necessary, use a stiff toothbrush to clean any clogged burner holes. REASSEMBLY: Be sure the holes on the burner are facing up. Burner must be completely dry before reassembly. Dry with a paper towel. Nieco Corporation - Model JF64-BG...
Page 25 EXTREMELY HOT! Be careful not to burn yourself. 1. Lift cap from shroud collar. 2. Take to sink area and spray with degreaser. 3. Wash with a scrub pad, rinse, and sanitize in the 3-compartment sink. CAUTION: Extremely Hot Nieco Corporation - Model JF64-BG...
Page 26 EXTREMELY HOT! Be careful not to burn yourself. 1. Lift upper heat shield up and off. 2. Take to sink area and spray with degreaser. CAUTION: 3. Wash with a scrub pad, rinse, and sanitize in Extremely Hot the 3-compartment sink. Nieco Corporation - Model JF64-BG...
Page 27 Be sure that both air box assemblies are installed and sit flush on their brackets. Main Burner Orifices Clean: Monthly Side Tools Small Orifice Brush Instructions 1. Use a small brush to clean the main burner orifices. Nieco Corporation - Model JF64-BG...
Page 28 2. Remove the ceramic boot from the back of the flame sensor. 3. Loosen the wing nut holding the flame sensor in place. 4. Remove the flame sensor and clean the metal tip with a DRY, clean scrub pad. Nieco Corporation - Model JF64-BG...
Page 29 Inner Shield Clean: Monthly Tools Instructions 1. Use scraping tool to reach between belts and remove carbon deposits. Nieco Corporation - Model JF64-BG...
Page 30 2. Wipe shaft cleaning tool with a towel. Belt Adjustment As Needed Tools Instructions 1. Remove return slide and stripper bar. 2. Loosen slotted crossbar bracket with 7/16 wrench. 3. Pry on shaft to adjust belt. 4. Tighten bolts. Nieco Corporation - Model JF64-BG...
Page 31 Check cookout temperature (undercooking). CooKInG PRobleMs Burgers under or over cooked. Adjust conveyor belt speed. Clean burners and orifices. Excessive flaming in broiler. Clean the catalyst if equipped. Check the hood for proper operation. Check product for overcooking. Nieco Corporation - Model JF64-BG...
Page 32 WIRInG DIaGRaM M ot or R ever se Sw i t ch P/ N 13579 Nieco Corporation - Model JF64-BG...
Page 33 WIRInG DIaGRaM Nieco Corporation - Model JF64-BG...
Page 34 CaUTIon Do not operate the broiler at gas pressures other than those stated here. Doing so will affect the opera- tion of your broiler. Nieco Corporation - Model JF64-BG...
Page 35 This page is intentionally left blank. Nieco Corporation - Model JF64-BG...
Page 36 Date Notes 3-11-2014 Released 7-23-2014 General Updates nieco Corporation 7950 Cameron Drive Windsor, CA 95492 (707) 284-7100 Office • (707) 284-7430 Fax www.nieco.com • e-mail: service@nieco.com Printed in the USA © 2011 Nieco Corporation All Rights Reserved Reorder P/N 99010...
