  • Page 1 Z-Amp 4.250T Mixer Amplifier...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 31.10.2024, ID: 575416 (V2)
  • Page 3 Table of contents Table of contents General information......................5 1.1 Symbols and signal words................... 5 Safety instructions......................... 6 Features............................8 Installation and starting up....................9 4.1 Pin assignment......................... 9 4.2 Screw terminal strips....................10 Connections and controls....................11 Technical specifications....................14 Cleaning............................
  • Page 4 Z-Amp 4.250T Mixer Amplifier...
  • Page 5 Our products and documentation are subject to a process of continuous develop‐ ment. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
  • Page 6 Safety instructions Safety instructions Intended use This device is intended to be used for amplification, mixing and playback of signals from musical instruments and microphones. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 7 Safety instructions NOTICE! Damage to the device if operated in unsuitable ambient conditions! The device can be damaged if it is operated in unsuitable ambient conditions. Only operate the device indoors within the ambient conditions specified in the “Technical specifications” chapter of this user manual. Avoid operating it in environments with direct sunlight, heavy dirt and strong vibrations.
  • Page 8 Features Features 4-zone amplifier Class D amplifier Volume control on the front Zone selection 4 microphone/line inputs Media player for playing back audio files via USB or Bluetooth 18 V phantom voltage input Priority control Input for connecting an external audio device Screw terminals for connecting speakers, phone systems or amplifiers Includes 19-inch kit for rack mounting Z-Amp 4.250T...
  • Page 9 Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 10 Installation and starting up 4.2 Screw terminal strips All speaker units and a phone system are connected via a screw terminal strip on the back of the device. First detach the covers of the screw terminal strips using a suitable screwdriver. Loosen the required screw terminals (see connection diagram) and attach the neces‐...
  • Page 11 Connections and controls Connections and controls Front ö & INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 ZONE 1 ZONE 2 OUTDOOR OUTDOOR INDOOR INDOOR Z-Amp 4.250T VOLUME VOLUME TREBLE TREBLE TREBLE TREBLE TREBLE POWER BASS BASS BASS BASS BASS ZONE 3...
  • Page 12 Connections and controls Back 4 5 6 7 [GND] | Connection screw for the ground cable Rubber panel plug with fuse holder for the power supply [ZONE 1]…[ZONE 4] | Screw terminal strips for connecting the speaker system(s) [INPUT 5] | Cinch input sockets for connecting an external audio device [LINE/MIC/PHANTOM] | Signal level switch for inputs [INPUT 1]…[INPUT 4] [INPUT 1]…[INPUT 4] | Inputs 1 to 4, designed as XLR/jack combination sockets [Monitor Line Out] | Screw terminals for connecting an amplifier, recorder etc.
  • Page 13 Connections and controls Media player Button Action Bluetooth Press briefly USB on Bluetooth on /[MENU] Press and USB off Bluetooth off hold MP3-BT Press briefly Play/pause Play/pause Press briefly Search for file No function MENU MENU Press briefly Repeat file (4 modes) No function Press briefly Previous file...
  • Page 14 Technical specifications Technical specifications 449 mm 370 mm INPUT 1 INPUT 2 INPUT 3 INPUT 4 INPUT 5 ZONE 1 ZONE 2 OUTDOOR OUTDOOR Z-Amp 4.250T INDOOR INDOOR VOLUME VOLUME TREBLE TREBLE TREBLE TREBLE TREBLE POWER BASS BASS BASS BASS BASS ZONE 3 ZONE 4...
  • Page 15 Technical specifications Power consumption, max. 1,500 W Rated power 1,100 W Fuse 220 - 240 V: 5 mm x 20 mm, 6.3 A, 250 V, slow blow Dimensions (W × H × D) 449 mm × 134 mm × 370 mm (without rack angle) 484 mm ×...
  • Page 16 Cleaning Cleaning Components Clean the externally accessible parts of the device regularly. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty sur‐ roundings can cause more dirt to accumulate on the device parts. Clean with a soft dry cloth. Stubborn stains may be removed with a slightly damp cloth.
  • Page 17 You can also return your old device to Tho‐ mann GmbH at no charge. Check the current conditions on www.thomann.de. Proper disposal protects the environment as well as the health of your fellow human beings.
  • Page 18 Notes Z-Amp 4.250T Mixer Amplifier...
