TECH Sinum EH-01 Lite Quick Installation Manual page 7

1. After creating an account, you will be able to log in to the Central via Cloud access and local access using the same login and
password.
2. Log in to your account, go to Settings and update the software to the latest version. The update can also be performed by connecting
a Pendrive with the appropriate file to the USB port.
1. To start Recovery mode, press and hold the MODE button on the back of the device. Then, disconnect and reconnect the power
supply by holding the button for 5 seconds.
2. Active Recovery mode is indicated by the recovery mode control light
3. Launch your web browser* and go to https://www.techsterowniki.pl/sinum-2/sinumfind or download the Sinum application
on your phone to search for your Sinum central device.
4. Connect to the Sinum central device called „sinum-r".
5. The Recovery mode allows, among other things, to restore the factory settings or return to the previous version of the software by
changing the system partition.
1. If you have set up your account via the mobile app in the previous steps, skip this section. However, if you have not set up your
account via the mobile app, you can alternatively set up your Cloud account using a browser, e.g. on your computer.
2. To use remote access to the Sinum central device and devices cooperating with it, you must register in the Cloud service at
https://sinum.tech Follow the instructions on the screen.
3. Activate the Cloud account by clicking on the link sent to your e-mail.
4. Go to the Sinum central device Settings > Profile. Find the Cloud account section and click Connect.
5. Log in to your Cloud account. A message will be sent to you, asking you to add your Sinum central device to Cloud. Create a name
and optionally a description.
6. To take full advantage of the device capabilities, log in by entering your Sinum central device address in the browser.
* recommended browsers are Chrome/Firefox/Safari
Max. power consumption
Operation temperature
Acceptable ambient relative humidity
Operation frequency
Max. transmission power
Transmission IEEE 802.11 b/g/n
Technical specification
Power supply
Inputs
First step
Recovery mode
which goes steady on.
Cloud service
9-30V DC typ.24V DC
1x USB2.0, Micro SD
2x RS-485 (1x MODBUS; 1x SBUS)
1x RJ-45 Ethernet, 1x RS Tech
DC 5.5/2.5mm
6W
5 ÷ 50°C
<80%REL.H
868MHz
25 mW
