CORE HEALTH & FITNESS

JACOBS LADDER JL2

OWNER'S

MANUAL

CONTACT SUPPORT NOW

Need help?

Do you have a question about the JACOBS LADDER JL2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stairmaster JACOBS LADDER JL2

Page 1 CORE HEALTH & FITNESS JACOBS LADDER JL2 OWNER'S MANUAL CONTACT SUPPORT NOW...
Page 2 IMPORTANT LABEL LOCATIONS ........................6 JL2 CONSOLE ...........................8 CONSOLE FEATURES ..............8 ASSEMBLY ..........................10 REQUIRED TOOLS ..............10 ASSEMBLY PROCEDURE ..............11 MAINTENANCE ..........................14 TOOLS ..............14 MAINTENANCE SCHEDULE ..............15 REPLACEMENT PARTS ..........................16 9-5370-XXXXP0 - JACOBS LADDER JL2 ..............16 SUPPORT & SERVICE ..........................22 Page 2...
Page 3 Do not use attachments not recommended by Stairmaster. Never operate this machine if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water.
Page 4 It is the purchaser’s sole responsibility to properly instruct its end users and supervising personnel as to the proper operating procedures of all Stairmaster equipment. Use only replacement components supplied by Stairmaster. Substitutes are forbidden and will void all warranties. Page 4...
Page 5 PROPER USE INSTRUCTION WARNING Do not use the machine without wearing the Waist Belt. Set your height on the Height adjustment section of the Waist Belt. Attach the Waist Belt to your waist, placing the strap off the center of your back. Push START button to turn display on.
Page 6 IMPORTANT LABEL LOCATIONS This page shows the location of the warning labels and communication stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you find any stickers missing or damaged the replacement numbers are shown on the support site and following pages.
Page 7 WARNING Read the Owner’s Manual and follow all proper instruction prior to use. Lisez le manuel d instructions avant d utiliser cet appareil. Lesen Sie die Gebrauchsanweisung vor dem Gebrauch des THE IMPROPER USE OF THIS MACHINE CAN RESULT IN SERIOUS INJURY. Avant de débuter tout programme d'exercices, passez un Geräts Bitte holen Sie vor Beginn eines jeden 1.) Before beginning any tness program, you should have a complete physical examination by your...
Page 8 JL2 CONSOLE CONSOLE FEATURES WARNING Read the Owner’s Manual and follow all proper instruction prior to use. Lisez le manuel d instructions avant d utiliser cet appareil. Lesen Sie die Gebrauchsanweisung vor dem Gebrauch des THE IMPROPER USE OF THIS MACHINE CAN RESULT IN SERIOUS INJURY. Avant de débuter tout programme d'exercices, passez un Geräts Bitte holen Sie vor Beginn eines jeden examen médical.
Page 9 Description Function The reset sensor is an optic sensor located behind the faceplate. The user swiping their finger over the sensor triggers the reset sensor. When the display initially powers up, the user can change the default weight setting by swiping their finger over the sensor until the desired weight is reached. Reset If you miss the opportunity to enter your weight and want to go back, just hold your finger over the reset sensor for three seconds.
Page 10 ASSEMBLY REQUIRED TOOLS Fig. 5 9-5370 Parts In The Box Required Tools: Description • Torque Wrench JL2-05 ASSEMBLY MANUAL, JL2 • 3/16” Allen Key JLX-10 WAIST BELT, ACESSORIES, JLX • 4mm, 5mm, 8mm, 13mm Allen Socket JLX-26 AC ADAPTOR, POWER INPUT, JLX •...
Page 11 ASSEMBLY PROCEDURE 1. Remove wooden side skirting from pallet. 2. Remove the four Lag Bolts securing the unit to the pallet with a 1/2” wrench or socket wrench. Lag Bolts Fig. 5 3. Tip the unit up and carefully wheel it onto the floor. Note: Make sure unit is placed in final install location before proceeding.
Page 12 4. Remove two Nuts (N03-1035), four washers (120-3301), two Hex Bolts (UF10112220), and both Transport Wheels (JL-31- UF10112220 12). 120-3301 N03-1035 JL-31-12 Fig. 7 5. Align the Stabilizer Bars (JL- 37) with the Mounting Plates (JL-02) and secure using four UF10112220 JL-02 Hex Bolts (UF10112220) eight...
Page 13 Fig. 9 6. Assembly is complete. Page 13...
Page 14 MAINTENANCE TOOLS Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, we recommend having the tools listed available when performing maintenance. Tool Metric Allen Key Set Screwdriver Set, Phillips Multi-Meter Metric Open-Ended Wrench Set...
Page 15 MAINTENANCE SCHEDULE With durable, high performance components, this equipment is designed for heavy usage with minimal maintenance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines outlined below. The safety and integrity of this machine can only be maintained when the equipment is regularly examined for damage and wear and repaired.
Page 16 Replacement parts for this unit are available through SUPPORT & SERVICE. Parts listed are shown on the following pages and interactive drawings available on Core Connect. Listed parts may change, please check Core Connect for latest versions and other SKU’s covered by this manual: 9-5370-XXXXP0 - JACOBS LADDER JL2 Part Number Description...
Page 17 UE11201300 UW70082000 110-3098 UA10940320 JL-31-03-03 110-3478 UE11141500 UW70071616 110-3098 N03-1035 120-3301 110-3259 JL-31-03 JLX-01-03-03-02 120-3023 JL-31-03-01-03-01 731-0355 UN51110000 JL-34-06 JL-34-02 TR35000071 JL-34-04 JL-34-05 TP35000159 731-0512 JL-34-01 JL-34-03 110-3324 GB-T 93 8 110-3450 731-0355 UF11110160 JL-34-08 JL-34-07 Page 17...
Page 18 JL-34-10 PU43062900 JL-34-03 JL-34-04 110-3450 UF10112220 120-3301 731-6444 JL-31-12 JL-37 N03-1035 110-3450 UF11110160 JL-34-06 JL-34-05 731-0355 JL-34-09 110-3324 110-4419 JL-35 PC22003801E JL-35-02 TR35000071 Page 18...
Page 19 JL-31-02 JL-31-01-34 120-3301 UN50112000 UF30304060 UF34003024E JL-31-06 JLX-01-21 UN51304001 JL-47 PO10030212E JL-42 140-3463 JL2-03-02 UN51310000 GB-T 5287 5E UF22108030 JL-31-06 JL-31-05 110-3450 JL-31-07 JL-21 JL-43 731-0585 UF30304060 N03-1035 JL-31-04-05 UF10112180 JL-31-04 Page 19...
Page 20 JL-31-04-04 SMD-03-15-09 JL2-02 JLX-26 JL-31-03 JL-31-11 UF32306100 UN51306000 JL-31-10 HR-05E JL-31-08 UW70132401 N01-3070 Page 20...
Page 21 110-3450 JL2-03-01 JL-32-02 711-4207 JLX-10 AJ01258500 731-0587 140-3790 UA10953830 JL-36 110-0575 UA12060380 JL-07 731-0373 110-3098 Page 21...
Page 22 SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •...
Page 23 PART NUMBER 637-8979, REV B All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.

This manual is also suitable for:

9-5370
