WING RACK Quick Start Guide
WING RACK Overview
7. Firmware updates
The WING console firmware can be easily updated via USB. Download the firmware file from the product page on behringer.com and follow these steps:
1. Open the SETUP/GENERAL page and enable OS ACCESS.
2. Connect a USB cable to the rear panel port and to your computer.
3. A virtual drive will appear on your computer, similar to connecting a flash drive or external hard drive. Double click the drive to open.
4. Drag the new firmware file into the drive. Note, although WING will always boot using the most recent firmware in that drive, it is recommended to delete older
firmware files or move them to a subfolder.
If the console does not boot up normally, you can still update the firmware using this procedure:
1. With console powered off, connect a USB cable to the rear panel port and to your computer.
2. Press and hold SETUP, then power the console on
3. An OS and DATA drive will appear on your computer, similar to connecting a flash drive or external hard drive. Double click a drive to open.
4. Drag the new firmware file into the OS drive.
NOTE: WING will always boot using the most recent firmware in that drive.
5. After the file has transferred, eject the virtual drive. The console should reboot automatically with the new firmware installed. If it doesn't, power cycle the
console manually.
8. Shortcuts
PURPOSE ENTER MODE EFFECT
Disable the Main A small X is shown and touch operation of the main screen is disabled.
Hold CLR SOLO, SETUP,
Display touch A USB mouse can be used for GUI control. The display will be calibrated
UTILITY
control upon leaving the mode.
Hold SETUP and Resets the touch panel (might help to temporarily fix ghost touch issues
CLR SOLO for > 1.5s for some time)
Hold METERS and HOME
Touch UI >
for 5s while powering the
Ghost Click Test
console up
The console appears as two drives on the computer it is connected to, i.e.
Enable OS DRIVE and Hold SETUP while powering
WING OS for mixer operating firmware, and WING DATA for snapshot and
surface test mode on
clip files, etc. The correct operation of all surface controls can be tested.
Hold EFFECT and press HOME
Shutdown and
after initiating Shutdown Console will shut down safely and restart automatically
Restart
from Setup screen
Locks the console surface, while audio and remote control keep working
unaffected.
Surface Lock Hold the HOME button down Any combination of buttons (only those around the touch screen) that
for ~1.5s was held down while engaging the lock will be stored as "pass code"
for unlocking. You will need to press the same combination of buttons
when disengaging the Lock.
Initialize console
Same as using INITIALIZE (from the SETUP page) but before the console
(only temp storage, Hold CLR SOLO while
loads any saved state (in case the last loaded snapshot somehow crashes
no snapshots etc. powering the console up
the console leading to a boot loop)
will be erased)
Hold CLR SOLO then press Stores a bmp of the current screen on your USB drive. A folder called
Take screenshot
UTILITY 'screens' needs to be created in the root of the USB drive first.
Bypass automatic Hold LIBRARY while powering Does not load STARTUP*.snap, STARTUP*.snip and STARTUP*.show files
load of startup files the console up in the STARTUP directory during boot
Configuring
optional hardware,
Hold UTILITY for 5s while
i.e. internal AoIP Configuration dialog allows to specify the hardware options
powering on
modules for Dante
or WSG
27
Quick Start Guide
EXIT
Hold UTILITY and CLR SOLO until
the X disappears
Reboot console
Hold HOME button for ~1.5s
again together with the "pass
code" of buttons that were
pressed while locking,
OR
power-cycle the console
