INSTALLATION GUIDELINES
IMPORTANT:
➢
To ensure this product is installed properly, you must read and follow these guidelines.
➢
The owner/user of this product must keep this information for future reference.
➢
Install adequate blocking or position over a stud to properly secure the fixture.
➢
Inspect this product, upon receiving, to ensure it is the correct model and you have all parts
required for proper installation.
➢
Slab top, fittings, and lavatory sold separately.
➢
This product must be installed by a professional licensed contractor. Be sure your installation
conforms to all federal, state, and local codes.
➢
Take all necessary precautions to ensure that this product is protected during installation.
➢
Ensure the floor is level and the weight of this product will be adequately supported.
➢
The use of certain plumber's putty may stain stone or tile surfaces.
PRODUCT SUPPORT | 800.927.2120 | WATERWORKS.COM
TECHNICAL DETAILS:
DETAIL
ADJUSTABLE LEVELERS/FEET
LEG MATERIAL
RECOMMENDED ROUGH-IN SUPPLY HEIGHT
RECOMMENDED ROUGH-IN SUPPLY SPREAD
RECOMMENDED ROUGH-IN WASTE HEIGHT
STORAGE CAPACITY
TOP ATTACHMENT METHOD
WEIGHT
X
UNWS22 UNWS28
30" 28"
X
[762mm] [711mm]
21" 19 5/16"
Y
[533mm] [506mm]
32 3/4" 31 1/2"
Z
[832mm] [800mm]
26 3/4" 25 3/4"
X1
[680mm] [629mm]
19 3/8" 18 5/16"
Y1
[492mm] [465mm]
Universal Metal Round 2 Leg Washstand
UNWS22 - 30" x 21" x 32 "
3/4
UNWS28 - 28" x 19 " x 31
15/16
SPECIFICATION
21" [534mm]
9" [229mm]
19" [483mm]
16 LBS [7.25kg]
Y
Z
X
1
Y
1
PAGE 1 OF 2 | UPDATED ON 5.31.2023
"
1/2
YES
BRASS
None
Silicone
