INSTALLATION GUIDELINES
IMPORTANT:
To ensure this product is installed properly, you must read and follow these guidelines.

 The owner/user of this product must keep this information for future reference.
 Install adequate blocking or position over a stud to properly secure the fixture.
Inspect this product, upon receiving, to ensure it is the correct model and you have all parts

required for proper installation.
Slab top, fittings and Lavatory sold separately.

 This product must be installed by a professional licensed contractor. Be sure your installation
conforms to all federal, state, and local codes.
 Take all necessary precautions to ensure that this product is protected during installation.
Ensure the floor is level and the weight of this product will be adequately supported.

 The use of certain plumber's putty may stain stone or tile surfaces.
PRODUCT SUPPORT | 800.927.2120 | WATERWORKS.COM
TECHNICAL DETAILS:
DETAIL
ADJUSTABLE LEVELERS/FEET
DIAMETER OF LEGS/TUBES
PRIMARY MATERIAL
RECOMMENDED ROUGH-IN SUPPLY HEIGHT (for each basin)
RECOMMENDED ROUGH-IN SUPPLY SPREAD (for each basin)
RECOMMENDED ROUGH-IN WASTE HEIGHT (for each basin)
STORAGE CAPACITY
TOP ATTACHMENT METHOD
WEIGHT
54 " [1395mm]
15/16
Ø 3 " [78mm] [78mm]
1/16
51 " [1317mm]
7/8
[78mm]
53 " [1349mm]
1/8
[78mm]
STYLE No. HNWS03
Henry Metal Round 3 Leg Washstand
54 " x 20" x 31¾ "
15/16
SPECIFICATION
YES
1 ½ " [38mm]
Brass
21" [534mm]
9" [229mm]
19" [483mm]
Shelf Size Required
Silicone
24lbs
20" [508mm]
18 " [469mm]
1 "
7/8
Ø 1/2
[78mm]
[32mm]
PAGE 1 OF 2 | UPDATED ON 10.1.2018
