- Page 1 LR95 Behind The Mirror Soap Dispenser...
- Page 2 content Box contents Technical drawing Technical data + user serviceable parts Before you install How to install Power supply variations How to refil soap dispenser Remote settings Battery replacement Operation + maintenance Warranty Contact 2 + LR95 Behind The Mirror Soap Dispenser...
- Page 3 box contents Note: Screws are not included Pump with Bottle Support, Plate with spout and soap tank IP 67 Battery I Box for 6xD Alkaline Batteries Transformer Mounting screw x 4 (5mm Screws Not Supplied) 3 + LR95 Behind The Mirror Soap Dispenser...
- Page 4 Behind mirror Soap Dispenser B - 280210 Behind mirror Soap Dispenser E - 280200 4 + LR95 Behind The Mirror Soap Dispenser...
- Page 5 technical data Capacity 1 Liter \ 33.8 oz. Power Supply: IP 67 Battery Box for 6xD Alkaline batteries \ Transformer Soap Viscocity 100 – 3800 cPs Standard discharge: 0.8cc, Adjustable Sensor range: 30-100 mm +/- 10 mm (Adjustable by remote control). user serviceable parts Sensor kit Soap tank 1L...
- Page 6 before you install Check Contents - Separate all parts from the packaging and check each part with the “Pack contents” section. Make sure all parts are accounted for before discarding any packaging material. If any parts are missing, do not attempt to install your touch free soap dispenser until you obtain the missing parts.
- Page 7 how to install Cut a hole in the bottom of the mirror Place the soap dispenser assembly inside the compartment for the soap dispenser sensor mirror compartment with the spout sticking out and spout both. And remove sticker. The of the hole. recommended hole size should be 30x50mm.
- Page 8 power supply variation For battery versions: Install the battery box at the wall in the mir- ror compartment and connect the battery connector. For transformer versions: Plug the transformer into the electricity socket and make sure the transformer con- nector is connected. Wait about 10 seconds before you put your hands within the sensor range about 10 seconds...
- Page 9 refiling soap dispenser Unscrew the soap Unscrew the soap tank from the pump tank from the pump assembly. assembly. Insert the bottle Screw the soap with the tube inside tank back to the the bottle support pump assembly. Make sure the tank is secured firlmy in place Press the refil but-...
- Page 10 settings adjustment with remote If desired, use the remote control to adjust the soap dispenser settings. Hold the remote control straight in front of the sensor in a distance of about 4-6” (10-15cm). Attention: Holding the soap dispenser remote control out of the recommended range (too close or too far)may interfere with the remote’s activation.
- Page 11 battery replacement Battery models only When the battery weakens, the red indicator light will blink at a constant rate when the user’s hands are within the sensor range. The battery must be replaced within two weeks. To replace the battery in battery models: Carefully open the battery box place within the mirror compartment, using 2.5 mm Allen key Remove the old batteries Replace the used batteries with new D batteries...
- Page 12 operation + maintenance maintenance Care and cleaning of chrome and special finishes DO NOT use steel wool or cleansing agents containing alcohol, acid, abrasives, or the like. Use of any prohibited cleaning or maintenance products or substances could damage the surface of the soap dis-penser.
- Page 13 LR95 Behind The Mirror Soap Dispenser - 1 Year Limited Warranty If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replace- ment part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty.
- Page 14 contact General information info.uk@thesplashlab.com +44 (0)161 482 7000 Unit 34, Meadow Industrial Estate, Water Street Stockport SK1 2BU United Kingdom Technical support info.uk@thesplashlab.com For further information visit: www.thesplashlab.com/uk 14 + LR95 Behind The Mirror Soap Dispenser...
