- Page 1 Monolith L & L+ Series Basin System...
-
Page 2: Table Of Contents
contents Monolith S & S+ Series Components List Technical Data Before you Install 8-11 Installation Operation & Maintenance Cleaning & Repairs Damage Prevention Warranty MONOLITH L & L+ SERIES MANUAL... -
Page 3: Monolith S & S+ Series
Monolith L & L+ Series Monolith L & L+ Series The Splash Lab Monolith L & L+ Series are multi-user basins, constructed from solid surface material, well suited to commercial and public washrooms. MONOLITH L & L+ SERIES MANUAL... -
Page 4: Components List
Please check that all components are included and advise The Splash Lab if any parts are missing. Fixings are not included for fastening the brackets to the wall as each location is different. The Splash Lab recommend that you consult a fixings specialist for advice on the most appropriate fixing method for your project. -
Page 5: Technical Data
Monolith L & L+ Series technical data 1800mm 1800 FINISHED FLOOR LEVEL 3600mm 600mm 1200mm 1800mm 2400mm 3000mm Material Solid Surface Solid Surface Solid Surface Solid Surface Solid Surface Solid Surface Weight (kg) Overall Dimensions (mm) 600x600x150 1200x600x150 1800x600x150 2400x600x150 3000x600x150 3600x600x150 Waste Connections Bottle traps not included. -
Page 6: Before You Install
The studwork should be set out to suit the suggested spacing of the brackets (see table on page 28) The Splash Lab recommend that a void of at least 100mm is included behind the fixing wall for ease of access to the plumbing connections. It is also recommended that access panels are created as part of the wall construction to allow for initial installation and maintenance of the plumbing fittings. - Page 7 Monolith L & L+ Series before you install 1800mm 32mm (1-1/4") Bottle Trap (TSL.650) T.M.V. (TSLP.120033) Hot Feed Cold Feed Waste Water MONOLITH L & L+ SERIES MANUAL...
-
Page 8: Installation
Monolith L & L+ Series installation The brackets are to be installed with an appropriate fixing, depending on the substrate of the wall the Slim Monolith is to be mounted to. The recommended fixing centres and heights are given in the table below Length No of Suggested Bracket... - Page 9 Monolith L & L+ Series installation Mark the bracket fixing points on the wall. Drill the wall to accept the appropriate fixings FIXING POINT A FIXING POINT C FIXING POINT B Attach the brackets through fixing point A using the Ensure all the brackets are level along their length height adjustment to ensure that all the brackets are so that there will not be a gap between the Monolith...
- Page 10 Monolith L & L + Series installation With the Monolith placed face-down, fit the waste Lift Monolith over the front of the mounting funnel to the funnel adapter plate on the underside tabs onto the wall brackets of the basin. Ensure that the sealing gasket is correctly fitted into the recess on the funnel and tighten the 4 fixing bolts.
- Page 11 Monolith L & L + Series installation Fit waste trap (TSL.650) to drain funnel and connect to waste pipe previously installed. MONOLITH L & L+ SERIES MANUAL...
- Page 12 operation The user is to activate the tap, either an automatic sensor tap or a manual tap, allow the water to flow and wash their hands in the normal manner. maintenance The Monolith should be periodically inspected for any damage. Also, the Monolith should be tested to ensure that the water drains out of the basin, and that the drainage waterways are not blocked with any debris.
- Page 13 The Splash Lab Monoliths are finished in a matt / satin finish, unless otherwise specified at manufacture. The surface can be cleaned with a mild solution of soapy water, ammonia-based cleaners or most commercially available solid-surface cleaners. These will remove most dirt and other residue from the surface.
-
Page 14: Damage Prevention
Some chemicals are not compatible with The Splash Lab solid surface. Contact should be avoided with the following chemicals: Strong chlorinated solvents Chloroform Ketones Methylene chloride (paint removers) Very strong acids such as concentrated sulphuric and hydrochloric acids Acid drain cleaners should not be used. -
Page 15: Warranty
10 years for manufactured product; 10 years for material used If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. - Page 16 contact General information info.uk@thesplashlab.com +44 (0) 161 482 7000 Meadow Industrial Estate, 34 Water Street Stockport SK1 2BU Technical support technical@thesplashlab.com For further contact information visit: www.thesplashlab.com...
