The Splash Lab TSL.465 Installation & Maintenance

Wall-mounted soap dispenser
Hide thumbs

Advertisement

Quick Links

Download this manual
TSL.465
wall-mounted soap dispenser

Advertisement

loading
Need help?

Need help?

Do you have a question about the TSL.465 and is the answer not in the manual?

Questions and answers

Related Manuals for The Splash Lab TSL.465

Summary of Contents for The Splash Lab TSL.465

  • Page 1 TSL.465 wall-mounted soap dispenser...

  • Page 2: Table Of Contents

    Safety and Warnings Box Contents Technical Data Before You Install How to Install Commissioning Operation Maintenance Cleaning Troubleshooting Diagram Warranty Back Cover Contact Details TSL.465 SOAP DISPENSER MANUAL...
  • Page 3 If in doubt, consult an electrician. General information 310 410 5008 Warehouse + Offices: 20809 Higgins Court, Torrance CA 90501 Showroom: 8745 Washington Boulevard, Studio D, Culver City CA 90232 Technical support info@thesplashlabusa.com For further contact information visit: www.thesplashlabusa.com TSL.465 SOAP DISPENSER MANUAL...
  • Page 4 Dispenser head assembly Anti-rotation washer Jam nut Soap foaming chamber pipe-set Soap supply pipe – 10 feet Soap reservoir – 1 liters Hex wrench Soap foamer pump unit Power supply unit Power cord Soap foamer mounting bracket TSL.465 SOAP DISPENSER MANUAL...

  • Page 5: Technical Data

    Min range 2 3/8” – Max range 16” Security cut-off time 30 seconds Recommended soap viscosity Foam soap up to 100cPs. Not suitable for liquid soaps, alcohol gels or hand sanitizers Approvals CE, RoHS Warranty 1 year parts + labor TSL.465 SOAP DISPENSER MANUAL...

  • Page 6: Before You Install

    Spacing Basins If the soap dispenser is installed with other units from our range, these should Use of a The Splash Lab Monolith basin be fitted at 5 1/2” centers. is recommended for use with TSL's range of fixtures. TSL.465 SOAP DISPENSER MANUAL...
  • Page 7 SIDE ½” min FRONT 1 7/16” max 2 ¼” 4 11/16” 1/8” 5/8” 7/8” 1 9/16” ¼” 118” tube length Power Supply TSL.465 SOAP DISPENSER MANUAL...

  • Page 8: How To Install

    Drill hole 15/16 - 1” diameter in wall, if Fit anti-rotation washer from behind wall not already cut. TSL.465 SOAP DISPENSER MANUAL...
  • Page 9 Mark wall in desired location for pump Fit jam nut, and secure using wrench. mounting bracket . TSL.465 SOAP DISPENSER MANUAL...
  • Page 10 Fit the pump bracket using appropriate Fit the soap foamer pump unit to the fixings. bracket TSL.465 SOAP DISPENSER MANUAL...
  • Page 11 Connect the soap foamer pipeset to the dispenser head to the corresponding dispenser head, and the two inlet pipes cables from the soap foamer pump, and to 2 pipe fittings on the top of the soap the power supply cables. foamer unit. TSL.465 SOAP DISPENSER MANUAL...
  • Page 12 Connect the soap pick-up pipe to the bottom of the soap foamer unit, and fit the opposite end of the pipe to the soap reservoir. TSL.465 SOAP DISPENSER MANUAL...

  • Page 13: Commissioning

    You should see a flashing red seconds and reconnect the power. light. When you see the light position your hand within (2”) of the tap. If you do not see the light, repeat from step 2. TSL.465 SOAP DISPENSER MANUAL...
  • Page 14 Resetting the sensor can lead to errors in the system with unnecessary activations or poor sensitivity. If you are considering altering the pre-set sensor settings, we recommend calling The Splash Lab for assistance (see back page). TSL.465 SOAP DISPENSER MANUAL...

  • Page 15: Operation

    Isolate the unit from the power supply before any servicing or maintenance work is carried out. The dispenser should be activated at least once a day to ensure that soap does not congeal in the pipework. TSL.465 SOAP DISPENSER MANUAL...

  • Page 16: Cleaning

    If further information is required, contact The Splash Lab team for more detailed stainless steel care guidelines. TSL.465 SOAP DISPENSER MANUAL...

  • Page 17: Troubleshooting

    If this is not possible, the sensor range can be adjusted as described in ‘Resetting the sensor’ We are always looking to improve. If these steps did not solve your problem please contact us and we will endeavor to help. Tel: 310 410 5008 Email: info@thesplashlabusa.com TSL.465 SOAP DISPENSER MANUAL...

  • Page 18: Diagram

    Dispenser head assembly Soap foaming chamber pipe-set Soap supply pipe - 10 feet Soap reservoir - 1 liter Soap foamer pump unit Power supply unit TSL.465 SOAP DISPENSER MANUAL...
  • Page 19 1 year parts & labor TSL.465 Wall-Mounted Soap Dispenser: If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning will void the warranty.
  • Page 20 contact General information 310 410 5008 Warehouse + Offices: 20809 Higgins Court, Torrance CA 90501 Showroom: 8745 Washington Boulevard, Studio D, Culver City CA 90232 Technical support info@thesplashlabusa.com For further contact information visit: www.thesplashlabusa.com...
