Industrial Box PC

Operations Manual

IPC2600A Series

Your Industrial Control Solutions Source

_____________________

www.maplesystems.com

For use with the following:

• IPC2610A Industrial Box PC

Maple Systems, Inc. | 808 134

St. SW, Suite 120, Everett, WA 98204 | 425.745.3229

Need help?

Do you have a question about the IPC2600A Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Maple Systems IPC2600A Series

Page 1 Industrial Box PC Operations Manual IPC2600A Series Your Industrial Control Solutions Source _____________________ www.maplesystems.com For use with the following: • IPC2610A Industrial Box PC Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
Page 2 Industrial Box PC Operations Manual: IPC2600A Series TABLE OF CONTENTS COPYRIGHT NOTICE .............3 WARRANTY .................3 TECHNICAL SUPPORT............3 UNPACKING THE UNIT ............3 SAFETY PRECAUTIONS ............4 OVERVIEW OF IPC2600A SERIES..........5 SPECIFICATIONS AND DIMENSIONS ........6 SPECIFICATIONS – IPC2610A ...........6 DIMENSIONS – IPC2610A..........7 INPUT POWER AND OPERATING TEMPERATURE.....8 EXTERNAL MONITORS ............8...
Page 3 Industrial Box PC Operations Manual: IPC2600A Series COPYRIGHT NOTICE This manual is a publication of Maple Systems, Inc., and is provided for use by its customers only. The contents of the manual are copyrighted by Maple Systems, Inc.; reproduction in whole or in part, for use other than in support of Maple Systems equipment is prohibited without the specific written permission of Maple Systems.
Page 4 Industrial Box PC Operations Manual: IPC2600A Series SAFETY PRECAUTIONS Please observe the following precautions when installing the Box PC Series. Failure to comply with these restrictions could result in loss of life, serious personal injury, or equipment damage. Warning: Disconnect this equipment from any power before cleaning. Do not use liquid or spray detergents for cleaning.
Page 5 State Drive options include sizes from 128 GB to 512 GB (Other options may be available; contact Maple Systems for details). IPC2600A Series units feature I/O ports on both the front and side panels. The front panel provides +9~36V DC input connector, a momentary pushbutton power switch, four USB 3.0 Type A Host Ports, two 2.5GbE RJ45 LAN ports, one DisplayPort output (max 4K resolution @60Hz) and one DVI-I...
Page 6 Industrial Box PC Operations Manual: IPC2600A Series SPECIFICATIONS AND DIMENSIONS The following section contains the Specifications and Dimensions for the IPC2600A Series Box PCs. SPECIFICATIONS – IPC2610A Intel ® Quad-Core Atom ® x7-E3950 @ 1.6 GHz System Chipset CPU Graphics...
Page 7 Industrial Box PC Operations Manual: IPC2600A Series DIMENSIONS – IPC2610A DIN-Rail Mount Bracket Holes Wall Mount Brackets Antenna Fixture (Optional) 3.5mm Line-Out Serial COM DE-9P x2 Power Button DC Power Input USB 3.0 Host Port x4 GbE LAN RJ45 x2...
Page 8 / desktop extension, desktop rotation and more. Maple Systems offers several monitor options that seamlessly integrate with your Box PC – visit our website at www.maplesystems.com or contact your Maple Systems Sales Engineer for additional information.
Page 9 (included with your Industrial Box PC but not installed by default). Maple Systems provides four (4) threaded bolts for installation of the mounting kit to the rear panel; please note that wall mounting hardware is not included. Use mounting hardware appropriate to and suitable for the application;...
Page 10 Below are two views of the IPC2610A (with optional Wi-Fi kit installed) mounted to a standard 35mm DIN rail. If improperly mounted or installed, damage to the Box PC may result. Maple Systems is not responsible for damage to unit, mounting surface or any other components caused by improper mounting.
Page 11 Industrial Box PC Operations Manual: IPC2600A Series I/O PORTS FRONT PANEL DC INPUT POWER CONNECTOR 3-pin Terminal Block, +12~24 VDC Assignment Power Ground Case Ground +9~36VDC POWER BUTTON Momentary-style pushbutton USB 3.0 x4 USB 3.0 Type A Host Ports – Maximum transfer speed 5.0Gbps...
Page 12 Industrial Box PC Operations Manual: IPC2600A Series SIDE PANEL LINE-OUT 3.5mm Audio Jack (Stereo output) SERIAL DE-9P (COM1, COM2) Pinout Configuration RS-232 by default, RS422/RS485 configurable in BIOS RS422* RS485* Pin # RS232 (Default) (Optional) (Optional) Data- Data+ * Refer to “Setting Serial COM Function” section to set the communication mode.
Page 13 Industrial Box PC Operations Manual: IPC2600A Series SETTING SERIAL COM FUNCTION The IPC2600A Series’ COM1 and COM2 Serial Ports are configured by default for RS232 operation but can be configured for RS422 (4-wire) and RS485 (2-wire) operation if so desired. COM port configuration is managed through the BIOS;...
Page 14 Industrial Box PC Operations Manual: IPC2600A Series 3. Select the Fintek Super IO Configuration menu. 4. Select the Serial Port 1 Configuration or Serial Port 2 Configuration menu option, depending on the serial port you wish to configure. Industrial Box PC Operations Manual: IPC2600A Series...
Page 15 Industrial Box PC Operations Manual: IPC2600A Series 5. Select the Device Mode menu option, and then choose the [RS232], [RS485], or [RS422] option, depending on your desired port configuration and press the Enter key. 6. Press the F4 key to save and exit.
Page 16 Industrial Box PC Operations Manual: IPC2600A Series OPERATING SYSTEM OPTIONS The IPC2600A series Box PCs can be purchased with the following operating systems pre-installed: • Windows IoT Enterprise (Windows 10 LTSC) • Windows IoT Enterprise Embedded (Windows 10 LTSC) WINDOWS 10 IoT ENTERPRISE LTSC Windows IoT Enterprise is a full enterprise version of Windows 10 available on all Industrial Box PC models.
Page 17 In the unlikely event of a system failure requiring reinstallation of the Windows Operating System, you can reinstall Windows as it arrived to you from Maple Systems. For OS recovery installation media, please contact your Maple Systems Sales Engineer. After OS reinstallation, you will need to re- activate Windows using the Product Key located on the bottom panel of your PC, adjacent to the product label.
Page 18 Your Industrial Control Solutions Source _____________________ www.maplesystems.com 1010-1150 rev 01 Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
