Industrial Box PC
Operations Manual
IPC2400A Series
Your Industrial Control Solutions Source
Maple Systems, Inc. | 808 134
_____________________
www.maplesystems.com
th
St. SW, Suite 120, Everett, WA 98204 | 425.745.3229
For use with the following:
• IPC2410A Industrial Box PC
• IPC2411A Industrial Box PC
Advertisement
Table of Contents
Related Manuals for Maple Systems IPC2400A Series
Summary of Contents for Maple Systems IPC2400A Series
- Page 1 Operations Manual IPC2400A Series Your Industrial Control Solutions Source _____________________ www.maplesystems.com For use with the following: • IPC2410A Industrial Box PC • IPC2411A Industrial Box PC Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
-
Page 2: Table Of Contents
Industrial Box PC Operations Manual: IPC2400A Series TABLE OF CONTENTS COPYRIGHT NOTICE.................3 WARRANTY ..................3 TECHNICAL SUPPORT ..............3 UNPACKING THE UNIT..............3 SAFETY PRECAUTIONS..............4 OVERVIEW OF IPC2400A SERIES ............5 SPECIFICATIONS AND DIMENSIONS ..........6 SPECIFICATIONS – IPC2410A............6 DIMENSIONS – IPC2410A ............7 SPECIFICATIONS – IPC2411A............8 DIMENSIONS –... -
Page 3: Copyright Notice
Industrial Box PC Operations Manual: IPC2400A Series COPYRIGHT NOTICE This manual is a publication of Maple Systems, Inc., and is provided for use by its customers only. The contents of the manual are copyrighted by Maple Systems, Inc.; reproduction in whole or in part, for use other than in support of Maple Systems equipment is prohibited without the specific written permission of Maple Systems. -
Page 4: Safety Precautions
Industrial Box PC Operations Manual: IPC2400A Series SAFETY PRECAUTIONS Please observe the following precautions when installing the Box PC Series. Failure to comply with these restrictions could result in loss of life, serious personal injury, or equipment damage. Warning: Disconnect this equipment from any power before cleaning. Do not use liquid or spray detergents for cleaning. -
Page 5: Overview Of Ipc2400A Series
DDR4 SODIMM RAM. Solid State Drive options include sizes from 64 GB to 1 TB (Other options may be available; contact Maple Systems for details). IPC2400A Series units feature I/O ports on both the front and rear panels. The front panel provides +12~24V DC input connector, a momentary type power switch, one DE-9P Serial COM port (RS232/485/422 configurable), one SIM Card Slot (for optional 4G/LTE data network usage –... -
Page 6: Specifications And Dimensions
Ubuntu Server 22.04 LTS ® * To use SIM Card slot, 4G/LTE Module must be purchased and installed by Maple Systems. 4G/LTE connectivity not guaranteed, and applies to select Network Providers only (T-Mobile, AT&T, Verizon). 4G/LTE signal strength, network connectivity and data transmission speeds subject to network and installation limitations and are not guaranteed. -
Page 7: Dimensions - Ipc2410A
Industrial Box PC Operations Manual: IPC2400A Series DIMENSIONS – IPC2410A Antenna Fixture (Optional) Digital I/O Terminal Block USB 2.0 Host Port x2 Serial DE-9P COM1 Wall Mount Brackets VESA 75x75mm M4 Mount Holes DC Power Input Illuminated Power Button Micro-SIM Card Slot (Optional) Serial DE-9P COM2 3.5mm Line-Out... -
Page 8: Specifications - Ipc2411A
Industrial Box PC Operations Manual: IPC2400A Series SPECIFICATIONS – IPC2411A Intel Quad-Core Atom x6425RE @ 1.9 GHz ® ® System Chipset System CPU Graphics Intel UHD Graphics System Memory Options 1 x DDR4 260-pin SO-DIMM RAM (4, 8, 16, 32 GB) -
Page 9: Dimensions - Ipc2411A
Industrial Box PC Operations Manual: IPC2400A Series DIMENSIONS – IPC2411A Antenna Fixture (Optional) Digital I/O Terminal Block USB 2.0 Host Port x2 POE+ LAN RJ45 Output x2 Wall Mount Brackets VESA 75x75mm M4 Mount Holes DC Power Input Illuminated Power Button... -
Page 10: Input Power And Operating Temperature
INPUT POWER AND OPERATING TEMPERATURE 12, 24 VDC INPUT POWER IPC2400A Series units are configured to operate with +12V or +24V DC voltage, (±10%). Your Industrial Box PC comes with a 3-pin Terminal Block connector. Connect the cable leads from the DC Output of your power supply to the appropriate + and –... -
Page 11: External Monitors
Since the Industrial Box PC units run the Microsoft Windows family of Operating Systems (Linux ® ® Ubuntu OS options are also available – contact Maple Systems for more details), users will see a familiar operating environment and usage. Windows ® allows for many customizable viewing options;... -
Page 12: Industrial Box Pc Mounting
(included with your Industrial Box PC but not installed by default). Maple Systems provides four (4) threaded bolts for installation of the mounting kit to the rear panel; please note that wall mounting hardware is not included. Use mounting hardware appropriate to and suitable for the application;... -
Page 13: I/O Ports
+VDC -GND POWER BUTTON Momentary-style pushbutton SIM CARD Micro-SIM Card slot (OPTIONAL on IPC2410A only – must use Maple Systems installed 4G/LTE Module) SERIAL DE-9P (COM1) Pinout Configuration RS-232 by default, RS422/RS485 configurable in BIOS, COM2 Pin # RS232 (Default) - Page 14 Industrial Box PC Operations Manual: IPC2400A Series LINE-OUT 3.5mm Audio Jack LAN1, LAN2: Standard 2.5 Gigabit RJ-45 Ethernet ports DISPLAYPORT High Definition 4K resolution Output - Maximum resolution of 4096 x 2160 pixels @60 Hz HDMI 2.0 High Definition 4K resolution Output - Maximum resolution of 4096 x 2160 pixels @60 Hz USB 3.0 x2...
-
Page 15: Rear Panel - Ipc2410A
Industrial Box PC Operations Manual: IPC2400A Series REAR PANEL – IPC2410A Serial DIO 16-Pin Terminal Block Pin # Assignment Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Output 1 Output 2 Output 3... -
Page 16: Rear Panel - Ipc2411A
Industrial Box PC Operations Manual: IPC2400A Series REAR PANEL – IPC2411A Serial DIO 16-Pin Terminal Block Pin # Assignment Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Output 1 Output 2 Output 3... -
Page 17: Setting Serial Com Function
Industrial Box PC Operations Manual: IPC2400A Series SETTING SERIAL COM FUNCTION The IPC2400A Series’ COM1 (and COM2, IPC2410A) Serial Port is configured by default for RS232 operation but can be configured for RS422 (4-wire) and RS485 (2-wire) operation if so desired. COM port configuration is managed through the BIOS;... - Page 18 Industrial Box PC Operations Manual: IPC2400A Series 3. Select the F81967 Super IO Configuration menu. 4. Select the serial port which you are looking to configure and press the Enter key. Industrial Box PC Operations Manual: IPC2400A Series...
- Page 19 Industrial Box PC Operations Manual: IPC2400A Series 5. Scroll down to Mode and press Enter. Select the [RS232], [RS485], or [RS422] option, depending on your desired port configuration and press the Enter key. 6. Press the F4 key to save and exit.
-
Page 20: Operating System Options
Industrial Box PC Operations Manual: IPC2400A Series OPERATING SYSTEM OPTIONS The IPC2400A series Box PCs can be purchased with the following operating systems pre-installed: • Windows IoT Enterprise (Windows 10 LTSC or Windows 11 GAC) • Windows IoT Enterprise Embedded (Windows 10 LTSC or Windows 11 GAC ) •... -
Page 21: Linux ® / Ubuntu ® Quick Start
This section is not meant as a detailed guide to the intricacies of the Linux ® Operating System. The scope of this section is for initial setup purposes of your new Maple Systems Industrial Box PC unit. INITIAL SETUP To complete the setup requires the following: 1. -
Page 22: Software Updates
Industrial Box PC Operations Manual: IPC2400A Series SETTING THE PC HOSTNAME The hostname is set to bpc, to update this run: $ sudo hostnamectl set-hostname <new hostname> To print the updated hostname run: $ hostnamectl You will need to logout and back in to see the new name on the terminal. -
Page 23: Troubleshooting
Systems only), simply connect the Box PC to the Internet and run the Windows Update utility. In the unlikely event of a system failure requiring reinstallation of the Windows Operating System, you can reinstall Windows as it arrived to you from Maple Systems. For OS recovery installation media, please contact your Maple Systems Sales Engineer. - Page 24 Your Industrial Control Solutions Source _____________________ www.maplesystems.com 1010-1147 rev 01 Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
