Assembly Instructions
Tumbl Trak
Thank you for purchasing the Original Tumbl Trak
After opening the boxes, please check the parts list to
make sure all pieces have arrived in good condition. If
you have any questions during this assembly process,
please call Customer Service.
Parts List
per 10-ft section
A. (2) 10-ft Rails
B. (2) Legs
C. (100) Springs
D. 60-in wide Tumbl Trak Bed
E. (4) 5-ft Pads
F. (24-ft) Loop Fastener
G. Spring Tool*
H. (4) End Caps
Per Additional 10-ft Section:
I. (2) Bolts
®
A.
E.
Any questions or problems, please call Tumbl Trak at (800) 331-4362
.
®
B.
C.
F.
G.
*Spring Tool is packed inside of the box
containing the Tumbl Trak Bed.
Scan QR code for
Video Assembly Instructions
D.
H.
I.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Original Tumbl Trak and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tumbl Trak Original Tumbl Trak

  • Page 1 F. (24-ft) Loop Fastener G. Spring Tool* H. (4) End Caps Per Additional 10-ft Section: I. (2) Bolts *Spring Tool is packed inside of the box containing the Tumbl Trak Bed. Any questions or problems, please call Tumbl Trak at (800) 331-4362...
  • Page 2 If you purchased a Tumbl Trak in a 5-ft increment, please see further instructions on page 4. 4. Repeat steps 1-3 for remaining 10-ft sections of your Tumbl Trak. Springing the Bed 1. Prepare the bed by laying it out flat within the frame with the logo facing up.
  • Page 3 If you skip a frame hole, make sure to skip the same frame hole on the opposite side to make a smooth, wrinkle-free bed. Never skip a D-Ring on the Tumbl Trak bed. 7. Allow the first person to stay 7-10 springs ahead of the second person using the spring tool.
  • Page 4 2. Once the loop fastener is applied, match the hook fastener strip on the pads with the loop fastener on the frame. 3. Secure the pad to the Tumbl Trak rail. Make sure the springs, frame, and bed flaps are covered by the pads.
  • Page 5 If you purchased a folding ramp with your Tumbl Trak, you may want to attach a strip of loop Velcro to the bed of the Tumbl Trak. The flap on the ramp will fasten to this Velcro strip, securing the ramp to the Tumbl Trak.
  • Page 6 Tumbl Trak. • We suggest that the Tumbl Trak be set up with a dismount mat that is 18-in thick at the end. Tumbl Trak can supply a 7-ft x 14-ft x 18-in thick mat with a connecting device so that the mat is attached to the frame.
