HEAT ALARM USER MANUAL
MODEL NUMBER: EP-HA-RF-10
Thank you for choosing Emerald Alarms.
This leaflet contains important information on the correct
installation and operation of your heat alarm.
Please read all the information before commencing
installation and retain for future reference.
This unit has been designed to meet the latest safety
standards demanded in Australia and complies with the
requirements of AS 1603.3:2018.
DIMENSIONS
WEIGHT
WARRANTY
MOUNTING OPTIONS
POWER - BATTERY
INTERCONNECT
WIRELESS DISTANCE
SENSOR
SOUND PATTERN
ALARM VOLUME
ALARM SENSITIVITY
HUSH/SILENCE TIME
NORMAL OPERATING &
STORAGE TEMPERATURE
NORMAL OPERATING &
STORAGE HUMIDITY
PACK INCLUDES
IMPORTANT
NOTE: Not suitable as a fire safety device unless interconnected to one or more smoke alarms.
WARNING: The battery in this unit is intended to last it's 10 year service life and cannot be replaced. It will 'chirp' every 54 seconds
indicating a fault such as a low battery. Replace heat alarm immediately.
Φ120 x 46.5mm
128.7g
10 years
Ceiling mount only
10 year non-replaceable 3V lithium battery (CR17450)
Built-in wireless radio frequency (RF) technology
Connects with up to 40 Emerald RF enabled alarms
>20m (100m outside)
Thermistor technology
ISO 8201
>85dB(A) @ 3m
54°C to 65°C
approx. 8 minutes
0°C to 40°C
<93% relative humidity (non-condensing)
Alarm, instruction manual, wall dog screws, and mounting plate
AS1603.3:2018
Advertisement
Related Manuals for emerald alarms EP-HA-RF-10
Summary of Contents for emerald alarms EP-HA-RF-10
- Page 1 HEAT ALARM USER MANUAL MODEL NUMBER: EP-HA-RF-10 Thank you for choosing Emerald Alarms. This leaflet contains important information on the correct installation and operation of your heat alarm. Please read all the information before commencing installation and retain for future reference.
- Page 2 INSTALLATION LOCATIONS LOCATIONS TO AVOID 1. Mount the heat alarm on the ceiling, preferably in the centre of DO NOT place heat alarms in the following locations: the room. 1. In areas with turbulent air from fans, heaters, doors, or windows. 2.
- Page 3 OPERATION AND TESTING WIRELESS INTERCONNECTING FUNCTION It is important to check heat alarms regularly to ensure they are For the best results we advise you first choose the central alarm and operating correctly. then connect other alarms to your central alarm. Regular Mode: Under normal conditions, the red LED should flash once every 54 SETTING UP WIRELESS CONNECTION:...
- Page 4 This warranty does not cover damage resulting from accident, misuse or abuse or lack of reasonable care of the product. In no case shall Emerald Alarms Pty Ltd be liable for any incidental or consequential damages for breach of this or any other warranty express or implied whatsoever.
