SMOKE ALARM USER MANUAL
MODEL NUMBER: EP-HYB-240-RF-10
Thank you for choosing Emerald Alarms.
This leaflet contains important information on the correct
installation and operation of your smoke alarm.
Please read all the information before commencing
installation and retain for future reference.
This unit has been designed to meet the latest safety
standards demanded in Australia and complies with the
requirements of AS3786:2014.
DIMENSIONS
WEIGHT
WARRANTY
MOUNTING OPTIONS
POWER
INTERCONNECT
WIRELESS DISTANCE
SENSOR
SOUND PATTERN
ALARM VOLUME
ALARM SENSITIVITY
HUSH/SILENCE TIME
NORMAL OPERATING &
STORAGE TEMPERATURE
NORMAL OPERATING &
STORAGE HUMIDITY
PACK INCLUDES
DESCRIPTION
The unit is a photoelectric smoke alarm device. It is particularly sensitive for detecting visible micro-particles (associated with
smoldering fires) and reacts faster than ionization alarms. An example of such smoldering fires is a cigarette burning in a couch or
bedding a common cause of devastating blazes.
Please note this device does not detect flames, heat, carbon monoxide or other hazardous gases. It has many advanced features
and an extended operational life with the included battery.
140 x 45mm
264.9g
10 years
Ceiling or wall mount
10 year non-replaceable 3V lithium battery (EVE CR17450)
OR 220~240V AC 50-60Hz with 10 year non-replaceable 3V lithium battery back-up (EVE CR17450)
Connects with up to 24 Emerald alarms when hardwired
Built-in wireless radio frequency (RF) technology Connects with up to 40 Emerald RF enabled alarms
>20m (100m outside)
Photoelectric optical chamber
ISO 8201
>85dB(A) @ 3m
0.1-0.16dB/m
approx. 8 minutes
0° to 40°
≤93% relative humidity (non-condensing)
Smoke alarm, instruction manual, wall dog screws, and mounting plate
AS3786:2014
Advertisement
Related Manuals for emerald alarms EP-HYB-240-RF-10
Summary of Contents for emerald alarms EP-HYB-240-RF-10
- Page 1 OR 220~240V AC 50-60Hz with 10 year non-replaceable 3V lithium battery back-up (EVE CR17450) INTERCONNECT Connects with up to 24 Emerald alarms when hardwired Built-in wireless radio frequency (RF) technology Connects with up to 40 Emerald RF enabled alarms WIRELESS DISTANCE >20m (100m outside)
- Page 2 INSTALLATION LOCATIONS POSITION OF SMOKE ALARMS OPTIMAL ALARM PLACEMENT Smoke will spread horizontally after rising to the ceiling so it’s advisable to install the smoke alarm in the centre of the ceiling For the highest level of protection, we strongly recommend where possible.
- Page 3 WIRELESS INTERCONNECTING FUNCTION OPERATION AND TESTING Smoke alarms are an important safety device in the home. It is For the best results we advise you first choose the central alarm important to check them regularly to ensure they are operating and then connect other alarms to your central alarm.
- Page 4 This warranty does not cover damage resulting from accident, misuse or abuse or lack of reasonable care of the product. In no case shall Emerald Alarms Pty Ltd be liable for any incidental or consequential damages for breach of this or any other warranty express or implied whatsoever.
