emerald alarms EP-HYB-240-10 User Manual

SMOKE ALARM USER MANUAL
MODEL NUMBER: EP-HYB-240-10
Thank you for choosing Emerald Alarms.
This leaflet contains important information on the correct
installation and operation of your smoke alarm.
Please read all the information before commencing
installation and retain for future reference.
This unit has been designed to meet the latest safety
standards demanded in Australia and complies with the
requirements of AS3786:2014.
POWER:
OPERATION CURRENT:
BATTERY LIFETIME:
ALARM VOLUME:
ALARM SENSITIVITY:
HUSH/SILENCE TIME:
INTERCONNECTION:
COMPLY WITH:
SOUND PATTERN:
WIRELESS INTERCONNECTION
ALARM SOUND PATTERN:
DESCRIPTION
The unit is a photoelectric 220~240V AC, with 3V DC battery back-up smoke alarm device. It is particularly
sensitive for detecting visible micro-particles (associated with smoldering fires) and reacts faster than
ionization alarms.
An example of such smoldering fires is a cigarette burning in a couch or bedding a common cause
of devastating blazes.
Please note this device does not detect flames, heat, carbon monoxide or other hazardous gases.
It has many advanced features and an extended operational life with the included battery.
To enable interconnection with other Emerald RF smoke alarms add an RF module (EP-HYB-RF-MOD).
220~240V AC 50-60Hz with 3V battery backup (non-replaceable battery)
<80mA
10 years
>85dB (A) at 3 meters
0.1-0.16dB/m
approx. 8 minutes
up to 24 smoke alarm/s, hardwired
AS3786: 2014
ISO8201 (Bl 0.5s - pause 0.5s - Bl 0.5s - pause 0.5s - Bl 0.5s - pause 1.5s,
with the red LED flash, repeat this alarm pattern
Bl - Bl - pause 0.5s, Bl - Bl - pause 0.5s, Bl - Bl - pause 1.5s,
without the red LED flash, repeat this alarm pattern
