emerald alarms EP-VC-240-10 User Manual

SMOKE ALARM USER MANUAL
MODEL NUMBER: EP-VC-240-10
Thank you for choosing Emerald Alarms.
This leaflet contains important information on the correct
installation and operation of your smoke alarm.
Please read all the information before commencing
installation and retain for future reference.
This unit has been designed to meet the latest
safety standards demanded in Australia and
complies with the requirements of AS3786:2014.
MODEL NUMBER
DIMENSIONS
WEIGHT
WARRANTY
MOUNTING OPTIONS
POWER - BATTERY
INTERCONNECT
WIRELESS DISTANCE
SENSOR
SOUND PATTERN
ALARM VOLUME
NORMAL OPERATING AND
STORAGE TEMPERATURE
NORMAL OPERATING AND
STORAGE HUMIDITY
PACK INCLUDES
DESCRIPTION
The unit is a photoelectric 220~240V AC, 9V DC battery back-up smoke alarm device. It is particularly
sensitive for detecting visible micro-particles (associated with smoldering fires) and reacts faster than
ionization alarms.
An example of such smoldering fires is a cigarette burning in a couch or bedding a common cause
of devastating blazes.
Please note this device does not detect flames, heat, carbon monoxide or other hazardous gases.
It has many advanced features and an extended operational life with the included battery.
To enable interconnection with other Emerald RF smoke alarms add an RF module (EP-VC-RF-MOD).
EP-VC-240-10
140 x 44.9mm
281.1g
10 years
Ceiling mount only
10 year replaceable 9V lithium maganeses dioxide battery (EVE CR9V-P)
Connects with up to 40 Emerald 240V alarms when hardwired
Optional wireless radio frequency (RF) technology connects with up to 40 Emerald RF enabled alarms
>20m (100m outside)
Photoelectric optical chamber
ISO 8201
>85dB(A) @ 3m
0°C to 40°C
≤93% relative humidity (non-condensing)
Smoke alarm, instruction manual, screws, battery and mounting plate
AS3786:2014
