SMOKE ALARM USER MANUAL
MODEL NUMBER: EP-RANG-1
Thank you for choosing Emerald Alarms.
This leaflet contains important information on the correct
installation and operation of your smoke alarm.
Please read all the information before commencing
installation and retain for future reference.
This unit has been designed to meet the latest
safety standards demanded in Australia and
complies with the requirements of AS3786:2014.
MODEL NUMBER
DIMENSIONS
WEIGHT
WARRANTY
MOUNTING OPTIONS
POWER - BATTERY
INTERCONNECT
SENSOR
SOUND PATTERN
ALARM VOLUME
NORMAL OPERATING AND
STORAGE TEMPERATURE
NORMAL OPERATING AND
STORAGE HUMIDITY
PACK INCLUDES
DESCRIPTION
The unit is a photoelectric smoke alarm device. It is particularly sensitive for detecting visible
micro-particles (associated with smoldering fires) and reacts faster than ionization alarms.
An example of such smoldering fires is a cigarette burning in a couch or bedding, a common cause
of devastating blazes.
Please note this device does not detect flames, heat, carbon monoxide or other hazardous gases.
It has many advanced features and an extended operational life with the included battery.
EP-RANG-1
100.8 x 36.7mm
132g
10 years
Ceiling mount only
1 year replaceable 9V carbon zinc battery (Pairdeer 6F22)
None, stand alone unit
Photoelectric optical chamber
ISO 8201
>85dB(A) @ 3m
0°C to 40°C
≤93% relative humidity (non-condensing)
Smoke alarm, instruction manual, screw packs, battery and mounting plate
AS3786:2014
Advertisement
Related Manuals for emerald alarms EP-RANG-1
Summary of Contents for emerald alarms EP-RANG-1
- Page 1 SMOKE ALARM USER MANUAL MODEL NUMBER: EP-RANG-1 Thank you for choosing Emerald Alarms. This leaflet contains important information on the correct installation and operation of your smoke alarm. Please read all the information before commencing installation and retain for future reference.
- Page 2 INSTALLATION LOCATIONS POSITION OF SMOKE ALARMS OPTIMAL ALARM PLACEMENT Smoke will spread horizontally after rising to the ceiling so it’s advisable to install the smoke alarm in the centre of the ceiling For the highest level of protection, we strongly recommend where possible.
- Page 3 OPERATION AND TESTING BATTERY REPLACEMENT Smoke alarms are an important safety device in the home there- The power for the smoke alarm is supplied by a 9V battery. fore it is important to check them regularly to ensure they are The battery should last at least 1 year under normal operating operating correctly.
- Page 4 This warranty does not cover damage resulting from accident, misuse or abuse or lack of reasonable care of the product. In no case shall Emerald Alarms Pty Ltd be liable for any incidental or consequential damages for breach of this or any other warranty express or implied whatsoever.
