Only for PhoneEasy105wr:
![]() | ![]() | ![]() | ![]() |
X 2 | 105wr | 100w | +1, +2,... |
Doro | Model: VT05EEU06045 / A318-060045W-EU1 | Model: VT05EEU06045 / A318-060045W-EU1 | Model: VT05EEU06045 / A318-060045W-EU1 |
UK only: VT05EUK06045/ A318-060045W-UK1 | UK only: VT05EUK06045/ A318-060045W-UK1 | UK only: VT05EUK06045/ A318-060045W-UK1 | |
AAA | ![]() | ![]() | ![]() |
1.2 V | 6 VDC | 6 VDC | 6 VDC |
500 mAh | 450 mA | 450 mA | 450 mA |
Ni-MH, GPI:50AAAHC CORUN HIGHPOWER | ø 3,5 | ø 3,5 | ø 5,5 |
Use only original battery and original power adapter.
This device is intended for the analogue telephone network lines in AT, BE, BG, CH, CY, CZ, DE, DK, EE, ES, FI, FR, GB, GR, HU, IE, IS, IT, LV, LT, LU, MT, NL, NO, PL, PT, RO, SI, SK, SE.
Disconnect the telephone line from the equipment before open the battery door.
Please note!
Use the telephone line cord supplied, an existing line cord from a previous phone may not be compatible.
If the PhoneEasy 105wr base unit's display is showing -- the answering machine is disconnected, or time/date is not set.
The format of date/time can also be adjusted. See Settings, clock.
Please note!
You need to set the correct date and time to gain full functionality of the Call log and the answering machine (only PhoneEasy 105wr).
The telephone's range depends on whether or not the radio waves carrying the call are restricted by obstacles in their path, and is usually between 50 and 300 metres. Coverage can be improved by turning one's head so that the handset is aligned with the base unit. Sound quality declines as the limit is reached until the call is finally interrupted.
The symbol is shown when the phone is within range and goes out/flashes when it is out of range.
Eco Functionality
We have introduced the ECO FUNCTIONALITY label to help customers identify products within our assortment having a lower impact on the enviornment. Products carrying this label feature:
When the batteries are relatively new (less than 6 months) and fully charged (10 hours) they will last for approx 100 hours standby time or approx 10 hours call time. Full battery capacity will not be reached until the batteries have been charged 4–5 times. It is not possible to overcharge or damage the batteries by charging them for too long. It may take up to 10 minutes charging before display illuminates, if batteries are totally empty.
Risk of explosion if battery is replaced by an incorrect type. Use only original batteries. The use of non-original batteries may be dangerous and may invalidate the phone's guarantee.
Note!
When the battery is low or when there is too great a distance to the base unit the telephone will be unable to connect to a line. Do not place the base unit close to other electrical equipment, in direct sunlight or other heat sources! This is to minimize the risk of any interference. It is normal for the device to become warm during charging and this is not dangerous. Dispose of used batteries according to the instructions.
Battery LED
When the batteries are running low, will flash and a warning tone will be heard when a call is in progress.
The warning tone is optional, see Handset settings, tone.
Please note that the complete battery indicator in the display will flash as long as the handset is charging.
The handset has a built-in hearing loop for those who wish to use their hearing aids while using the telephone. Select the T mode on your hearing aid to enable this feature.
Icon | Function | Icon | Function |
![]() | Battery charge indicator | ![]() | New TAM message / new call received |
![]() | Shown when in range of base unit | ![]() | Ringer signal de-activated |
![]() | During calls. Flashes when there is an incoming call | ![]() | Alarm activated |
![]() | During intercom call. Flashes when there is an incoming internal call or an internal call put on hold. | ![]() | Keypad lock activated |
![]() | Speaker on | ![]() | Message indication* |
Only PhoneEasy 105wr:
Icon | Function |
![]() | Answer machine on. Flashes when new TAM message received. |
* Only functions in certain countries. To remove the message indicator: Press and then hold down
.
In order to save the batteries, the display is very dark on standby, press once to illuminate. During calls, use M1 or M2.
Please note!
To switch between handset/speaker press . Please remember that in speaker mode, it is only possible for one person at a time to talk. When batteries are low the speaker mode and backlight will not work in order to save the batteries.
Speed dial (M1,M2)
This telephone has 2 speed dial memories (M1 and M2). Once a number has been saved in a memory location, you only need to press and hold one key to make the call, see Handset settings, MEM KEY.
On incoming calls, the LED indicator (number 13) on the handset will flash.
If the Auto answer function is enabled, just pick up the handset from the base unit to answer. See Settings/Auto ans.
During a call the display will show a timer HH-MM-SS, indicating the call duration.
When someone calls, you can press C to turn off the handset ring signal.
Press and hold in standby to turn on/off the handset ring signal.
Press . Scroll among the 5 most recently dialled numbers with
. If the number is already in the phone book, the corresponding name will also be displayed.
Press to call the displayed entry,
or C to return to the main menu, or
for the submenu. Please refer to, Phonebook.
Press on the base unit to page the handset/s. The handset/s will ring and PAGING is displayed. To cancel, press
again, or press
or
on the handset.
Press and hold in standby to power on/off the handset.
The microphone can be switched on/off during a call with C.
Incoming calls is shown on the display. Only the first 8 digits (including area code) is shown. Press to toggle to the last digits of the number.
Press and hold to activate/deactivate the keypad lock. Incoming calls can be answered by pressing
even if the keypad is locked. During the call, the keypad is unlocked.
When the call is ended or rejected, the keypad is locked again.
Please note!
The emergency numbers 999, 112 and 911 can be dialled without unlocking the keypad.
During a normal or speakerphone call, press on the side of the handset, to adjust the sound volume of the handset or speaker. Alternatively use
.
The volume level is indicated on the display. When you end the call, the setting will remain at the last selected level.
Press Boost on the side of the handset, to activate/ deactivate audio boost. When Boost is On the LED indicator (number 13) on the handset illuminates. The boost is deactivated at the end of each call to avoid harming people with normal hearing.
The maximum handset volume can be very loud. Boost should only be used by persons with impaired hearing.
You can save 20 numbers/names. If you subscribe to a caller ID service, the name allocated to the caller in the phonebook will be shown for incoming calls. It is possible to choose between various ringers for the numbers saved in the Phonebook *only functions if you subscribe to a caller ID service. Phonebook entries are stored alphabetically by name.
Press each numerical key repeatedly until the desired character is displayed, then wait a few seconds before entering the next character.
Press C to delete. Press and hold C to delete the entire text string.
Here you can check how many phonebook entries that are stored and available storage capacity.
Once a number has been saved as FASTDIAL you only need to press one button to make the call.
Please note!
The contact must be stored in the phonebook before assigning a fast dial key.
To dial a fast dial number press and hold the equivalent key until the phone number is displayed.
(Incoming numbers/Caller ID)*
If Caller ID service is subscribed, the phone number of incoming calls is shown on the display. The last 10 incoming answered and unanswered calls are stored along with the date and time of the calls. CALLS will be shown in standby mode and in the list indicates a missed call.
*This function requires a subscription from your service provider.
Please note!
As default the last 10 incoming answered and unanswered calls are stored along with the date and time of the calls. To save memory storage you can select to save only MISSED calls (unanswered).
In addition to number display, the following messages will be shown occasionally:
OUT AREA | Unknown number, e.g. international call. |
WITHHELD | Information about the number is blocked. Number cannot be shown. |
![]() | MSG indication from your network operator*. |
* Only functions in certain countries.
To remove the message indicator: Press and then hold down
System PIN is 0000 on delivery.
RINGER | The base unit's ringer melody can be adjusted. RING 1, 2, 3, 4 or 5. |
RING VOL | The base unit's ringer volume 1 =lowest, 2, 3, 4, 5=highest or OFF. |
DEL HS | De-register a handset.
|
FLASH | Recall time. LONG=New Zealand. MEDIUM=France/Portugal. SHORT=others incl. UK/AUS. |
CHG PIN | The PIN-code (default code is 0000) can be changed. |
RINGER | The handset's ringer melody. INT RING=internal call (10 selectable melodies) EXT RING=external call (10 selectable melodies) RING VOL=the handset's ringer volume. 1 =lowest, 2, 3, 4, 5=highest, or OFF |
Please note! RING 6 - RING 10 will continue for up to 9 seconds if the call is answered in another phone. Select 1 - 5 if you want to avoid this. | |
TONE | Any of the following warning tones can be disabled: KEY TONE, LOW BATT and OUTRANGE. Select ON or OFF to enable/disable. |
EQLIZER | NATURAL, BASS, TREBLE. Natural is default. |
SEL BASE | Only used in systems with more than one base unit. |
LANGUAGE | The language of the display texts. |
HS NAME | The text/name shown in standby mode. |
DISPLAY | Choose to display time or handset name in standby. |
AUTO ANS ON | ON = the call is answered when the handset is lifted from the base. OFF = the call is answered by pressing ![]() |
MEM KEY | Scroll to M1. Press ![]() Enter the telephone number, including the area code. Delete if necessary with C . Press ![]() Repeat to save information for M2. |
MAILBOX | (Voice mail) Only functions in certain countries. If voice messaging services are subscribed through the network operator, a indication ![]() Press ![]() ![]() |
Please note!
Current setting is indicated with an asterisk at the rightmost of the display.
CLOCK
ALARM
When the alarm is activated will be shown in standby mode.
Please note!
When the alarm goes off, a signal will be heard for 45 seconds. The signal can be turned off with any key. If SNOOZE is activated the alarm will go off again approx. 7 minutes later. Turn the alarm off via the menu or by holding down for a few seconds. The volume is determined by the handset ringer volume. If the handset ringer is set to OFF, the alarm still sounds at VOLUME 1 level.
All handsets included in the package are already registered to the base unit. Only for separate handsets/service measures. You can register up to 5 handsets to one base unit.
Please note!
This model is GAP (Generic Access Profile) compatible, which means that the handset and the base unit can both be used with most other GAP compatible units irrespective of manufacturer. However the GAP protocol cannot guarantee that all functions may be accessed.
You can reset the phone to default settings. Select DEFAULT and press . Enter the PIN-code (default code is 0000) and press
. Press
again to confirm.
(Two or more handsets e.g. duo, trio..)
The call number for internal calls will be shown in the display in standby mode. The base unit should be positioned centrally so that the coverage area is roughly equal for all handsets.
A tone will be heard if an external call comes in while an internal call is in progress. End the internal call with and then answer the external call with
.
(only PhoneEasy 105wr)
When the answering machine is switched on calls are answered after a set number of rings, your outgoing message is heard and the caller can leave a message. Total memory capacity is up to 15 minutes. Most functions can be accessed from both base unit and handset.
Please note!
You need to set the correct date and time to gain full functionality of the answering machine. See Settings, clock.
Press to switch the answering machine on/off. If the base unit's display is flashing/showing - - the answering machine is disconnected, or time/date is not set.
If the handset's display shows with a steady light the answering machine is switched on. If there are new messages, the indicator will flash whether the answering machine is off or on.
Please note!
Even when answering machine is OFF it will still answer after 10 rings, see Remote activation.
*TAM = Telephone Answering Machine
The outgoing message OGM SET (max 3 min) is heard by incoming callers. There are two separate outgoing messages, one for Answer only ANSONLY (callers cannot leave a message) and one for normal answering function ANS&REC. Please also select desired answer mode ANS MODE. See Answering machine settings (handset).
Do not press or C during playback. The message is not saved until the message has been played back to you.
Repeat the above to change.
Please note!
A pre-recorded message is used until you make your own recording, and that message can also be restored if required. To restore this, press C during playback of outgoing message.
The numbers on the 7-segment LED on the base unit will flash when there are new messages (01-59 messages).
Icon | Function |
![]() | Start playback |
![]() | Stop playback |
![]() | Skip to previous/Skip forward |
X | Delete current message |
+ / - | Increase/decrease volume |
Delete all old messages
After playback: Hold down X until you hear a beep.
Screening
Incoming messages will be heard on the loudspeaker of the base unit as they are received. If nothing can be heard, check that the volume is turned up and that the function has been activated, see Answering machine settings, (handset). You can also press on the handset while recording is in progress. The call can be intercepted by pressing
or lifting the receiver of another telephone connected to the same line.
New messages are indicated by flashing in the display in standby mode. Playback always starts with new messages.
Icon | Function |
![]() | Delete current playback |
![]() | Skip to previous |
![]() | Stop playback |
![]() | Skip forward |
![]() | Speaker OFF/ON |
![]() | (side keys) Volume control |
Delete all old messages
Personal message (Memo)
Do not press or C during playback. The message is not saved until the message has been played back to you.
Out of memory
The memory has room for up to 59 messages (including the outgoing message) max. 15 minutes. When TAM FULL is shown or the base unit flashes FF, no new messages can be recorded until the old ones have been played back and deleted. In that case, the telephone answering machine responds with the outgoing message for Answer Only.
Please note!
Remember to delete messages regularly!
(handset)
ANS MODE | Choose between ANSWER&REC and ANSONLY (caller cannot leave message). |
LANGUAGE | Select language for pre-recorded outgoing message. To activate this, press C during playback of outgoing message. |
OGM SET | Record/listen to outgoing message. |
ANS DLAY | Select after how many rings (2,4,6,8, TS=time saver*) the call will be answered. |
REC TIME | Select maximum recording time for each message. |
REMOTE | Select remote access ON/OFF. ON = access your answering machine remotely from another phone. |
CHG PIN | Change remote access PIN code (default code is 0000). For security reasons, it is recommended that you change the PIN code. |
Please note!
The Time Saver (TS) function answers calls after six ring signals, until the first new message has been registered - then the answering machine switches to answering after approximately two signals. This is useful when using remote access; if you call up the answering machine and there is no reply after four rings that means there are no messages recorded and you can hang up before you are charged for the call.
The answering machine can be activated via the remote access functions.
Please note!
When the answering machine is set to OFF, calls will be answered after approximately 10 rings and the answer only message will be played to your callers. They will not be able to leave you a message.
The unit can be remotely accessed using an ordinary tone dialling telephone.
![]() | Delete current message |
![]() | Press once to repeat current message. Press twice to skip to previous message. |
![]() | Playback of messages. (During playback ![]() |
![]() | Skip forward |
![]() | Turn the answering machine ON |
![]() | Turn the answering machine OFF |
Please note!
Using a PIN code prevents other people from accessing your machine without permission. For security reasons, it is recommended that you change the PIN code from the default setting of 0000. See Answering machine settings, Chg pin.
Check that the telephone cord is undamaged and properly plugged in.
Disconnect any additional equipment, extension cords and other phones. If the problem is resolved, the fault is with some other equipment.
Test the equipment on a known working line (e.g. at a neighbour's house).
If the equipment works there the fault is probably with your telephone line.
Please report this to your network operator.
If the telephone still does not work, please contact the place of purchase for service. Don't forget the receipt or a copy of the invoice.
Only use batteries, mains adapter and accessories approved for use with this particular model.
Connecting other accessories may be dangerous and may invalidate the phone's type approval and guarantee.
Disconnect the telephone line from the equipment before opening the battery door.
The mains adapter is the disconnect device between the product and mains power. The mains socket outlet must be close to the equipment and easily accessible.
Equipment is only suitable for mounting at heights below 2 meters.
To maintain the compliance with the RF exposure requirement, the Base Unit shall be installed and used such that parts of user's body other than hands are maintained at a distance of 20 cm or more.
Your unit is a technically advanced product and should be treated with the greatest care. Negligence may void the warranty.
The advice above applies to the unit, battery and other accessories. If the unit is not working as it should, please contact the place of purchase for service. Don't forget the receipt or a copy of the invoice.
Avoid using battery in following conditions:
The applied nameplate is located at the bottom or rear of the product.
